1658613-4 | ||
|---|---|---|
Digi-Key Part Number | AMR09B-ND | |
Manufacturer | ||
Manufacturer Product Number | 1658613-4 | |
Description | CONN D-SUB PLUG 9POS IDC | |
Manufacturer Standard Lead Time | 16 Weeks | |
Detailed Description | 9 Position D-Sub Plug, Male Pins Connector | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | 1658613-4 Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Bulk | |
Product Status | Active | |
Connector Style | ||
Connector Type | Plug, Male Pins | |
Number of Positions | ||
Number of Rows | 2 | |
Mounting Type | ||
Shell Size, Connector Layout | 1 (DE, E) | |
Contact Type | Signal | |
Flange Feature | Housing/Shell (Unthreaded) | |
Termination | IDC, Ribbon Cable | |
Shell Material, Finish | Steel, Tin Plated | |
Contact Finish | Gold | |
Contact Finish Thickness | - | |
Ingress Protection | - | |
Material Flammability Rating | UL94 V-0 | |
Current Rating (Amps) | 1.25A | |
Backset Spacing | - | |
Features | Feed Through, Grounding Indents | |
Voltage Rating | - | |
Color | Black | |
Contact Form | - | |
Dielectric Material | Thermoplastic | |
Wire Gauge | 26-28 AWG, Stranded or Solid | |
Contact Material | Phosphor Bronze | |
Operating Temperature | -55°C ~ 105°C | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | 1658613-4 |
| Environmental Information | 1658613-4 Statement of Compliance |
| PCN Assembly/Origin | Multiple Devices Location 06/Jan/2017 |
| EDA Models | 1658613-4 Models |
| 3D Drawings | 1658613-4.pdf |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | Vendor Undefined |
| ECCN | EAR99 |
| HTSUS | 8536.69.4051 |
Quantity
All prices are in CHF
Bulk
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | Fr.6.08000 | Fr.6.08 |
| 10 | Fr.5.29900 | Fr.52.99 |
| 25 | Fr.5.16000 | Fr.129.00 |
| 50 | Fr.5.02040 | Fr.251.02 |
| 100 | Fr.4.71350 | Fr.471.35 |
| 250 | Fr.4.68564 | Fr.1,171.41 |
| 500 | Fr.4.40674 | Fr.2,203.37 |
| 1,000 | Fr.3.93261 | Fr.3,932.61 |
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 2266-1658613-4 -1658613-4-SI 16586134 AMR09B |
| Standard Package | 40 |
