Type 12 Mild Steel Junction Box (1414 SC Series) - Hammond Mfg.
https://www.hammfg.com/electrical/products/industrial/1414sc
1/2
Additional Inner Panels Terminal Kit Assemblies
Climate Control General Accessories
Type 12 Mild Steel Junction Box 1414 SC Series
Lift-Off Cover with Screws
Application
Designed for use as instrument enclosures, electric, hydraulic or pneumatic control
housings, electrical junction boxes or terminal wiring enclosures.
Provides a degree of protection from falling dirt, dust, oil and water.
Standards
UL 508A Type 12 and 13
CSA Type 12 and 13
Complies with
NEMA Type 12 and 13
IEC 60529, IP54
Construction
Body formed from 16 gauge or 14 gauge steel. Covers are formed from 14 gauge steel.
Smooth, continuously welded seams without knockouts, cutouts or holes.
Welded brackets provide for enclosure mounting.
Cover is secured with captive, plated steel screws, threaded into sealed wells.
Oil resistant gaskets are permanently secured.
Models larger than 4" x 4" include a removable 14 gauge inner panel.
Internal threaded weld studs are provided for mounting inner panels.
A bonding stud is provided on the door and a grounding stud is provided on the
enclosure.
Finish
Cover and enclosure are phosphatized and finished in ANSI 61 gray recoatable powder
coating.
Removable inner panel is finished in white powder coating.
Accessories
Enclosure Panel
Part No. H W D H W
Quality Products. Service Excellence.
3/5/2921 Type 12 Mild Steel Junction Box (1A1A so series) - Hammond Mfg. Data sub/est to change Without notice https://www.hammfg.com/electrical/products/industrial/1414sc 2/2
8/6/2021
Type 12 Mild Steel Junction Box (1414 SC Series) - Hammond Mfg.
https://www.hammfg.com/electrical/products/industrial/1414sc
2/2
Data subject to change without notice
Enclosure Panel
Part No. H W D H W
1414SCA 4.00 4.00 3.00 no panel
1414SCC 6.00 4.00 3.00 4.87 2.87
1414SCG 8.00 6.00 3.50 6.75 4.87
1414SCE 6.00 6.00 4.00 4.87 4.87
1414SCI 10.00 8.00 4.00 8.75 6.87
1414SCK 12.00 10.00 5.00 10.75 8.87
1414SCM6 14.00 12.00 6.00 12.75 10.87
1414SCO6 16.00 14.00 6.00 14.75 12.87
1414SCM8 14.00 12.00 8.00 12.75 10.87
1414SCO10 16.00 14.00 10.00 14.75 12.87
