Part Number: 0638248400
Status: Active
Overview: Application Tooling
Description: Extraction Tool for 2.50mm Pitch Mini-Lock Wire-to-Board Female Terminal
Documents:
RoHS Certificate of Compliance (PDF)
General
Product Family Application Tooling
Series 207122
Comments See Tooling Specification (PDF) Above
Function Extraction
Geographic Area Global
Level of Automation Manual
More Detailed Tech Information applicationtooling@molex.com
Overview Application Tooling
Product Name Mini-Lock
Tool Type Press-Fit Insertion Tool
UPC 193264349135
Warranty Disclaimer CAUTION: Molex tooling crimp specifications are
valid only when used with Molex terminals and tooling
manufactured by Molex and sold by Molex or authorized
distributors ("Molex Tooling"). When using tooling
other than Molex Tooling with Molex specific connector
systems listed in our ATS documents, the Molex tooling
qualification does not apply and the responsibility for
full qualification of the connector system is that of the
customer. Molex accepts no liability for connector
performance or tooling support where tooling other
than Molex Tooling is used or where Molex Tooling is
modified.
Material Info
Reference - Drawing Numbers
Application Tooling Documents 638248400-000
Series image - Reference only
EU ELV
Not Reviewed
EU RoHS China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
For more information, please visit Contact US
China ROHS Not Reviewed
ELV Not Reviewed
RoHS Phthalates Not Reviewed
Search Parts in this Series
207122 Series
Application Tooling | FAQ
Description Product #
2.50mm Pitch, Mini-
Lock Female Crimp
Terminal, Matte Tin
Plating, 20-22 AWG,
Reel
507528200
2.50mm Pitch, Mini-
Lock Female Crimp
Terminal, Matte Tin
Plating, 24-26 AWG,
Reel
507528400
