CY7B923/CY7B933

HOTLink® Transmitter/Receiver

Cypress Semiconductor Corporation • 198 Champion Court • San Jose,CA 95134-1709 • 408-943-2600

Document Number: 38-02017 Rev. *K Revised November 7, 2017

Features

■Fibre Channel-compliant

■IBM ESCON-compliant

■DVB-ASI-compliant

■ATM-compliant

■8B/10B-coded or 10-bit unencoded

■Standard HOTLink: 160 to 330 Mbps

■High-speed HOTLink: 160 to 400 Mbps for high-speed

applications

■Transistor-transistor logic (TTL)-synchronous I/O

■No external phase locked-loop (PLL) components

■Triple positive emitter coupled logic (PECL) 100 K serial

outputs

■Dual PECL 100 K serial inputs

■Low-power: 350 mW (Tx), 650 mW (Rx)

■Compatible with fiber-optic modules, coaxial cable, and twisted

pair media

■Built-in self-test (BIST)

■Single +5-V supply

■28-pin small outline integrated circuit (SOIC)/plastic leaded

chip carrier (PLCC)

■Pb-free packages available

■0.8- bipolar complementary metal oxide semiconductor

(BiCMOS)

Functional Description

The CY7B923 HOTLink‚ transmitter and CY7B933 HOTLink

receiver are point-to-point communications building blocks that

transfer data over high-speed serial links (fiber, coax, and twisted

pair). Standard HOTLink data rates range from 160 to 330 Mbps.

Higher speed HOTLink is also available for high-speed applica-

tions (160 to 400 Mbits/second). Figure 1 illustrates typical

connections to host systems or controllers.

Eight bits of user data or protocol information are loaded into the

HOTLink transmitter and are encoded. Serial data is shifted out

of the three differential PECL serial ports at the bit rate (which is

ten times the byte rate).

The HOTLink receiver accepts the serial bit stream at its differ-

ential line receiver inputs and, using a completely integrated PLL

clock synchronizer, recovers the timing information necessary

for data reconstruction. The bit stream is deserialized, decoded,

and checked for transmission errors. Recovered bytes are

presented in parallel to the receiving host along with a byte-rate

clock.

The 8B/10B encoder/decoder can be disabled in systems that

already encode or scramble the transmitted data. I/O signals are

available to create a seamless interface with both asynchronous

FIFOs (that is, CY7C42X) and clocked FIFOs (that is,

CY7C44X). A BIST pattern generator and checker allows testing

of the transmitter, receiver, and the connecting link as a part of a

system diagnostic check.

HOTLink devices are ideal for a variety of applications where a

parallel interface can be replaced with a high-speed

point-to-point serial link. Applications include interconnecting

workstations, servers, mass storage, and video transmission

equipment.

CY7B923 Transmitter Block Diagram

EMPRESS ' manna: mmmw RF—i FRAMER AIE \NA. \NA7 magma.) DNA smnsx W7 90 "L CLOCK ‘— m axsvm— LOG‘C 1L}! cm wov

Document Number: 38-02017 Rev. *K Page 2 of 42

CY7B923/CY7B933

CY7B933 Receiver Block Diagram

Figure 1. HOTLink System Connections

PROTOCOL

LOGIC

HOST

TRANSMIT

MESSAGE

BUFFER

7B923

TRANSMITTER

SERIAL LINK

7B933

RECEIVER

RECEIVE

MESSAGE

BUFFER

PROTOCOL

LOGIC

HOST

nnnnnnnnnnnnnnnnnnn Charla

Document Number: 38-02017 Rev. *K Page 3 of 42

CY7B923/CY7B933

Contents

Pin Configurations ...........................................................4

Pin Descriptions ...............................................................6

CY7B923 HOTLink Transmitter

Block Diagram Description ..............................................8

Input Register .............................................................. 8

Encoder .......................................................................8

Shifter .......................................................................... 8

OutA, OutB, OutC ........................................................ 8

Clock Generator .......................................................... 8

Test Logic .................................................................... 9

CY7B933 HOTLink Receiver

Block Diagram Description ..............................................9

Serial Data Inputs ........................................................ 9

PECL-TTL Translator ..................................................9

Clock Synchronization .................................................9

Framer .........................................................................9

Shifter .......................................................................... 9

Decode Register .......................................................... 9

Decoder ..................................................................... 10

Output Register .........................................................10

Test Logic .................................................................. 10

HOTLink CY7B923 Transmitter and CY7B933

Receiver Operation .........................................................10

CY7B923 HOTLink Transmitter

Operating Mode Description .........................................11

Encoded Mode Operation ......................................... 12

Bypass Mode Operation ............................................13

PECL Output Functional and Connection Options .... 13

Transmitter Serial Data Characteristics ....................... 13

Transmitter Test Mode Description .............................. 13

BIST Mode ................................................................15

Test Mode .................................................................16

CY7B933 HOTLink Receiver

Operating Mode Description .........................................16

Encoded Mode Operation ......................................... 16

Bypass Mode Operation ............................................17

Parallel Output Function ............................................17

Receiver Serial Data Requirements .............................. 17

Receiver Test Mode Description ................................... 18

BIST Mode ................................................................ 18

Test Mode ................................................................. 18

X3.230 Codes and Notation Conventions .................... 18

Notation Conventions ................................................ 18

8B/10B Transmission Code ....................................... 19

Transmission Order ................................................... 19

Valid and Invalid Transmission Characters ............... 19

Using the Tables for

Generating Transmission Characters ............................... 20

Using the Tables for Checking the Validity of

Received Transmission Characters .................................. 20

Valid Data Characters (SC/D = LOW) ............................ 21

Valid Special Character Codes and Sequences

(SC/D = HIGH)[1, 2] ......................................................... 29

Maximum Ratings ........................................................... 30

Operating Range ............................................................. 30

CY7B923/CY7B933 Electrical Characteristics ............. 30

Capacitance[13] .............................................................. 31

Transmitter Switching Characteristics ......................... 32

Receiver Switching Characteristics .............................. 33

Switching Waveforms .................................................... 34

Ordering Information ...................................................... 37

Ordering Code Definitions ......................................... 37

Package Diagrams .......................................................... 38

Acronyms ........................................................................ 40

Document Conventions ................................................. 40

Units of Measure ....................................................... 40

Document History Page ................................................. 41

Sales, Solutions, and Legal Information ...................... 42

Worldwide Sales and Design Support ....................... 42

Products .................................................................... 42

PSoC® Solutions ...................................................... 42

Cypress Developer Community ................................. 42

Technical Support ..................................................... 42

CYPRESS ' EMIEuummlnNannaw Vccw mogg HHHHHHHHHHHHHH HHHHHHHHHHHHHH STEN GND MOQE

Document Number: 38-02017 Rev. *K Page 4 of 42

CY7B923/CY7B933

Pin Configurations

Figure 2. CY7B923 Transmitter Pin Configurations

SC/D(D a)

SVS(Dj)

OUTB

OUTC

OUTC+

VCCN

BISTEN

GND

MODE

VCCQ

(Dh)D

(Dg)D 6

(Df)D 5

(Di)D 4

OUTB+

OUTA+

OUTA

FOTO

ENN

ENA

VCCQ

CKW

GND

D0(Db)

D2(Dd)

D1(Dc)

D3(De)

43 12 28

1213 1514 16

PLCC/LCC

Top View

2726

1718

FOTO

ENN

ENA

VCCQ

CKW

GND

SC/D(D a)

BISTEN

GND

MODE

VCCQ

SVS(Dj)

(Dh)D 7

OUTC+

OUTC

OUTB+

OUTA+

OUTA

OUTB

SOIC

Top View

7B923

CCN

(D )

EEEEEEEEEEEEEE 32in]: uzmuzzﬂgzzzzqu i RN SW SW Em Rm Pu vim cm

Document Number: 38-02017 Rev. *K Page 5 of 42

CY7B923/CY7B933

Figure 3. CY7B933 Receiver Pin Configurations

SC/D (Qa)

INA

INA+

A/B

BISTEN

GND

RDY

GND

VCCN

RVS(Qj)

(Qh)Q

(Qg)Q

(Qf)Q

(Qi)Q

INB(INB+)

SI(INB)

MODE

REFCLK

VCCQ

CKR

VCCQ

GND

SC/D (Qa)

Q0(Qb)

Q2(Qd)

Q1(Qc)

Q3(Qe)

43 12 28

1213 1514 16

PLCC/LCC

Top View

2726

1718

REFCLK

VCCQ

CKR

VCCQ

GND

RDY

GND

VCCN

RVS(Qj)

(Qh)Q

BISTEN

A/B

INA+

INB (INB+)

SI (INB)

MODE

INA

SOIC

Top View

7B933

(Q )

' ‘CYPRESS' ENuEnnEn mmmw imc mo M 5% Spec when CK lransm pane er rial the 8 0077 Sen n symbol. If SVS is HIGH wn go lhe e parallel inpuls is ignoredl se or test mode, inis pin ove Vl MODE is HIGH (p DJ 00,7 Enab parallel dala. lf ENA is LOW on in ENNareHlGHJnedalainpulsa e of CKW. lhe da dlhe Transmule user dal HIGH/LOW co Enable parallel dala. If ENN i LOW, lh edge olC loaded ded, and senl.l ext risin of CK ored andl een us IGHILO OUTA: cc nes in lo Vcc ﬂoalin (OUT Vcc OW and ENA and ENN are HIGH. lhe lransmiller sends an allernal n either ENA or ENN is set LOW and Bi OW‘ lne lransm l allows lne Transm and Receive gelher lo lesl l e lhis input is held orwired lo eneralor ol be initialize required n b 0077 60%Q byle-rale puls lable f0 pulse in CY7C when de_Le iLin Vcco

Document Number: 38-02017 Rev. *K Page 6 of 42

CY7B923/CY7B933

Pin Descriptions

Table 1. CY7B923 HOTLink Transmitter

Name I/O Description

D07

(Db  h)

TTL In Parallel data input. Data is clocked into the Transmitter on the rising edge of CKW if ENA is LOW (or on

the next rising CKW with ENN LOW). If ENA and ENN are HIGH, a Null character (K28.5) is sent. When

MODE is HIGH, D0, 1, ...7 become Db, c,...h, respectively.

SC/D (Da)TTL In Special character/data select. A HIGH on SC/D when CKW rises causes the transmitter to encode the

pattern on D07 as a control code (Special Character), while a LOW causes the data to be coded using

the 8B/10B data alphabet. When MODE is HIGH, SC/D (Da) acts as Da input. SC/D has the same timing

as D07.

SVS

(Dj)

TTL In Send violation symbol. If SVS is HIGH when CKW rises, a Violation symbol is encoded and sent while

the data on the parallel inputs is ignored. If SVS is LOW, the state of D07 and SC/D determines the code

sent. In normal or test mode, this pin overrides the BIST generator and forces the transmission of a

Violation code. When MODE is HIGH (placing the transmitter in unencoded mode), SVS (Dj) acts as the

Dj input. SVS has the same timing as D07.

ENA TTL In Enable parallel data. If ENA is LOW on the rising edge of CKW, the data is loaded, encoded, and sent. If

ENA and ENN are HIGH, the data inputs are ignored and the Transmitter will insert a Null character (K28.5)

to fill the space between user data. ENA may be held HIGH/LOW continuously or it may be pulsed with

each data byte to be sent. If ENA is being used for data control, ENN will normally be strapped HIGH, but

can be used for BIST function control.

ENN TTL In Enable next parallel data. If ENN is LOW, the data appearing on D07 at the next rising edge of CKW is

loaded, encoded, and sent. If ENA and ENN are HIGH, the data appearing on D07 at the next rising edge

of CKW will be ignored and the Transmitter will insert a Null character to fill the space between user data.

ENN may be held HIGH/LOW continuously or it may be pulsed with each data byte sent. If ENN is being

used for data control, ENA will normally be strapped HIGH, but can be used for BIST function control.

CKW TTL In Clock write. CKW is both the clock frequency reference for the multiplying PLL that generates the

high-speed transmit clock, and the byte rate write signal that synchronizes the parallel data input. CKW

must be connected to a crystal controlled time base that runs within the specified frequency range of the

Transmitter and Receiver.

FOTO TTL In Fiber optic transmitter off. FOTO determines the function of two of the three PECL transmitter output pairs.

If FOTO is LOW, the data encoded by the Transmitter will appear at the outputs continuously. If FOTO is

HIGH, OUTA and OUTB are forced to their “logic zero” state (OUT+ = LOW and OUT = HIGH), causing

a fiber-optic transmit module to extinguish its light output. OUTC is unaffected by the level on FOTO, and

can be used as a loop-back signal source for board-level diagnostic testing.

OUTA

OUTB

OUTC

PECL Out Differential serial data outputs. These PECL 100 K outputs (+5 V referenced) are capable of driving

terminated transmission lines or commercial fiber optic transmitter modules. Unused pairs of outputs can

be left open, or wired to VCC to reduce power, if the output is not required. OUTA± and OUTB± are

controlled by the level on FOTO, and will remain at their “logical zero” states when FOTO is asserted.

OUTC± is unaffected by the level on FOTO. (OUTA+ and OUTB+ are used as a differential test clock input

while in Test mode, that is, MODE = UNCONNECTED or forced to VCC/2).

MODE Three-

Level In

Encoder mode select. The level on MODE determines the encoding method to be used. When wired to

GND, MODE selects 8B/10B encoding. When wired to VCC, data inputs bypass the encoder and the bit

pattern on Da–j goes directly to the shifter. When left floating (internal resistors hold the input at VCC/2)

the internal bit-clock generator is disabled and OUTA+/OUTB+ become the differential bit clock to be used

for factory test. In typical applications MODE is wired to VCC or GND.

BISTEN TTL In BIST enable. When BISTEN is LOW and ENA and ENN are HIGH, the transmitter sends an alternating

1–0 pattern (D10.2 or D21.5). When either ENA or ENN is set LOW and BISTEN is LOW, the transmitter

begins a repeating test sequence that allows the Transmitter and Receiver to work together to test the

function of the entire link. In normal use this input is held HIGH or wired to VCC. The BIST generator is a

free-running pattern generator that need not be initialized, but if required, the BIST sequence can be

initialized by momentarily asserting SVS while BISTEN is LOW. BISTEN has the same timing as D0-7.

RP TTL Out Read pulse. RP is a 60% LOW duty-cycle byte-rate pulse train suitable for the read pulse in CY7C42X

FIFOs. The frequency on RP is the same as CKW when enabled by ENA, and duty cycle is independent

of the CKW duty cycle. Pulse widths are set by logic internal to the transmitter. In BIST mode, RP will

remain HIGH for all but the last byte of a test loop. RP will pulse LOW one byte time per BIST loop.

VCCN Power for output drivers.

VCCQ Power for internal circuitry.

GND Ground.

‘CYPRESS' ' manna: mlanRRaw se‘ecl. 7 conlex: , LO arag ulse on that new data has ived Gala \s m Else 5 b daLy damﬁ al dam inpul erenha am;

Document Number: 38-02017 Rev. *K Page 7 of 42

CY7B923/CY7B933

Table 2. CY7B933 HOTLink Receiver

Name I/O Description

Q07

(Qb  h)

TTL Out Q0–7 parallel data output. Q0–7 contain the most recently received data. These outputs change synchro-

nously with CKR. When MODE is HIGH, Q0, 1, ...7 become Qb, c,...h, respectively.

SC/D(Qa)TTL Out Special character/data select. SC/D indicates the context of received data. HIGH indicates a Control

(Special Character) code, LOW indicates a Data character. When MODE is HIGH (placing the receiver

in Unencoded mode), SC/D acts as the Qa output. SC/D has the same timing as Q07.

RVS (Qj)TTL Out Received violation symbol. A HIGH on RVS indicates that a code rule violation has been detected in the

received data stream. A LOW shows that no error has been detected. In BIST mode, a LOW on RVS

indicates correct operation of the Transmitter, Receiver, and link on a byte-by-byte basis. When MODE

is HIGH (placing the receiver in Unencoded mode), RVS acts as the Qj output. RVS has the same timing

as Q07.

RDY TTL Out Data output ready. A LOW pulse on RDY indicates that new data has been received and is ready to be

delivered. A missing pulse on RDY shows that the received data is the Null character (normally inserted

by the transmitter as a pad between data inputs). In BIST mode RDY will remain LOW for all but the last

byte of a test loop and will pulse HIGH one byte time per BIST loop.

CKR TTL Out Clock read. This byte rate clock output is phase and frequency aligned to the incoming serial data stream.

RDY

, Q07, SC/D, and RVS all switch synchronously with the rising edge of this output.

A/B PECL in Serial data input select. This PECL 100K (+5V referenced) input selects INA or INB as the active data

input. If A/B is HIGH, INA is connected to the shifter and signals connected to INA will be decoded. If A/B

is LOW INB is selected.

INADiff In Serial data input A. The differential signal at the receiver end of the communication link may be connected

to the differential input pairs INA or INB. Either the INA pair or the INB pair can be used as the main

data input and the other can be used as a loopback channel or as an alternative data input selected by

the state of A/B. One input of an intentionally unused differential-pair (INA or INBshould be terminated

to VCC through a 15-K resistor to assure that no data transitions are accidentally created.

INB

(INB+)

PECL in

(Diff In)

Serial data input B. This pin is either a single-ended PECL data receiver (INB) or half of the INB differential

pair. If SO is wired to VCC, then INB can be used as differential line receiver interchangeably with INA.

If SO is normally connected and loaded, INB becomes a single-ended PECL 100K (+5 V referenced)

serial data input. INB is used as the test clock while in Test mode.

(INB)

PECL in

(Diff In)

Status input. This pin is either a single-ended PECL status monitor input (SI) or half of the INB differential

pair. If SO is wired to VCC, then INB can be used as differential line receiver interchangeably with INA.

If SO is normally connected and loaded, SI becomes a single-ended PECL 100K (+5V referenced) status

monitor input, which is translated into a TTL-level signal at the SO pin.

SO TTL Out Status out. SO is the TTL-translated output of SI. It is typically used to translate the carrier detect output

from a fiber-optic receiver connected to SI. When this pin is normally connected and loaded (without any

external pull-up resistor), SO will assume the same logical level as SI and INB will become a single-ended

PECL serial data input. If the status monitor translation is not desired, then SO may be wired to VCC and

the INB pair may be used as a differential serial data input.

RF TTL In Reframe enable. RF controls the Framer logic in the Receiver. When RF is held HIGH, each SYNC (K28.5)

symbol detected in the shifter will frame the data that follows. If it is HIGH for 2,048 consecutive bytes,

the internal framer switches to double-byte mode. When RF is held LOW, the reframing logic is disabled.

The incoming data stream is then continuously deserialized and decoded using byte boundaries set by

the internal byte counter. Bit errors in the data stream will not cause alias SYNC characters to reframe

the data erroneously.

REFCLK TTL In Reference clock. REFCLK is the clock frequency reference for the clock/data synchronizing PLL.

REFCLK sets the approximate center frequency for the internal PLL to track the incoming bit stream.

REFCLK must be connected to a crystal-controlled time base that runs within the frequency limits of the

Tx/Rx pair, and the frequency must be the same as the transmitter CKW frequency (within CKW 0.1%).

MODE Three-

Level In

Decoder mode select. The level on the MODE pin determines the decoding method to be used. When

wired to GND, MODE selects 8B/10B decoding. When wired to VCC, registered shifter contents bypass

the decoder and are sent to Qaj directly. When left floating (internal resistors hold the MODE pin at VCC/2)

the internal bit clock generator is disabled and INB becomes the bit rate test clock to be used for factory

test. In typical applications, MODE is wired to VCC or GND.

aCYPRESS' ' museum mlnnankaw wails a D00 (senl lunclionalily onh lest can BIST loo lhe The inpul register holds lhe dala lo be processed by lhe HOTLin lransminer and allows lhe inpul 9 lo be made consislemw slandard FIFOs, The inpul reg clogked by CKW and loaded with inhmlion on_lhe and SVS pins. Two enable inpuls (ENA and lo choose when dala is loaded in lhe re le, active LOW (ENA)caus “he—mad sleronlhe rism edge of CK is assened when CKW e nexl rising dgﬂc inpul dala held by lhe inpul r transmission on a serial inl by ANSI X3230 (Fibre C lable Valid Dala he eighl Um, d or_a speCial npul, l andj

Document Number: 38-02017 Rev. *K Page 8 of 42

CY7B923/CY7B933

CY7B923 HOTLink Transmitter Block

Diagram Description

Input Register

The input register holds the data to be processed by the HOTLink

transmitter and allows the input timing to be made consistent with

standard FIFOs. The input register is clocked by CKW and

loaded with information on the D0-7, SC/D, and SVS pins. Two

enable inputs (ENA and ENN) allow the user to choose when

data is loaded in the register. Asserting Enable, active LOW

(ENA) causes the inputs to be loaded in the register on the rising

edge of CKW. If ENN (Enable Next, active LOW) is asserted

when CKW rises, the data present on the inputs on the next rising

edge of CKW are loaded into the Input register. If neither ENA

nor ENN are asserted LOW on the rising edge of CKW, then a

SYNC (K28.5) character is sent. These two inputs allow proper

timing and function for compatibility with either asynchronous

FIFOs or clocked FIFOs without external logic, as shown in

Figure 6.

In BIST mode, the input register becomes the signature pattern

generator by logically converting the parallel input register into a

linear feedback shift register (LFSR). When enabled, this LFSR

generates a 511-byte sequence that includes all data and special

character codes, including the explicit violation symbols. This

pattern provides a predictable but pseudo-random sequence that

can be matched to an identical LFSR in the receiver.

Encoder

The encoder transforms the input data held by the input register

into a form more suitable for transmission on a serial interface

link. The code used is specified by ANSI X3.230 (Fibre Channel)

and the IBM ESCON channel (see the table Valid Data

Characters (SC/D = LOW) on page 21). The eight D0–7 data

inputs are converted to either a data symbol or a special

character, depending upon the state of the SC/D input. If SC/D

is HIGH, the data inputs represent a control code and are

encoded using the special character code table. If SC/D is LOW,

the data inputs are converted using the data code table. If a byte

time passes with the inputs disabled, the encoder outputs a

special character comma K28.5 (or SYNC) that maintains link

synchronization. SVS input forces the transmission of a specified

violation symbol to allow the user to check the error handling

system logic in the controller or for proprietary applications.

The 8B/10B coding function of the encoder can be bypassed for

systems that include an external coder or scrambler function as

part of the controller. This bypass is controlled by setting the

MODE select pin HIGH. When in bypass mode, Da-j (note that

the bit order is specified in the fibre channel 8B/10B code)

become the ten inputs to the shifter, with Da being the first bit to

be shifted out.

Shifter

The shifter accepts parallel data from the encoder after each byte

time and shifts it to the serial interface output buffers using a PLL

multiplied bit clock that runs at 10 times the byte clock rate.

Timing for the parallel transfer is controlled by the counter

included in the clock generator and is not affected by signal

levels or timing at the input pins.

OutA, OutB, OutC

The serial interface PECL output buffers (ECL100K referenced

to +5 V) are the drivers for the serial media. They are all

connected to the shifter and contain the same serial data. Two of

the output pairs (OUTA± and OUTB±) are controllable by the

FOTO input and can be disabled by the system controller to force

a logical zero (that is, “light off”) at the outputs. The third output

pair (OUTC±) is not affected by FOTO and supplies a continuous

data stream suitable for loopback testing of the subsystem.

OUTA± and OUTB± responds to FOTO input changes within a

few bit times. However, since FOTO is not synchronized with the

transmitter data stream, the outputs will be forced off or turned

on at arbitrary points in a transmitted byte. This function is

intended to augment an external laser safety controller and as

an aid for Receiver PLL testing.

In wire-based systems, control of the outputs may not be

required, and FOTO can be strapped LOW. The three outputs

are intended to add system and architectural flexibility by offering

identical serial bit streams with separate interfaces for redundant

connections or for multiple destinations. Unneeded outputs can

be wired to VCC to disable and power down the unused output

circuitry.

Clock Generator

The clock generator is an embedded PLL that takes a byte-rate

reference clock (CKW) and multiplies it by 10 to create a bit rate

clock for driving the serial shifter. The byte rate reference comes

from CKW, the rising edge of which clocks data into the input

that has a frequency between the minimum and maximum

specified for the HOTLink transmitter/receiver pair. Signals

controlled by this block form the bit clock and the timing signals

that control internal data transfers between the input register and

the shifter.

BISTEN TTL In Built-in self-test enable. When BISTEN is LOW the Receiver awaits a D0.0 (sent once per BIST loop)

character and begins a continuous test sequence that tests the functionality of the Transmitter, the

Receiver, and the link connecting them. In BIST mode the status of the test can be monitored with RDY

and RVS outputs. In normal use BISTEN is held HIGH or wired to VCC. BISTEN has the same timing as

Q0–7.

VCCN Power for output drivers.

VCCQ Power for internal circuitry.

GND Ground.

Table 2. CY7B933 HOTLink Receiver (continued)

Name I/O Description

:‘CYPRESS' Eminozn m lnmnnuw The read pulse n the PLL mult hase and pul chronous since p Two pairs of differential line reoe stream. INA: or INBt can elected with N3 HIG threshold of AIB is CL ﬁber optic used to sel e TTL (1 of INA 9 lo > m errors that occur in the serial data can I: terns into a bit paiiem ideniical lo a K28 erroneous data-framing error. The RF ng reiraming during times when n I. When RF is held LOW. the HOT coming data wwihout tming to en RF rises, RLi

Document Number: 38-02017 Rev. *K Page 9 of 42

CY7B923/CY7B933

The read pulse (RP) is derived from the feedback counter used

in the PLL multiplier. It is a byte-rate pulse stream with the proper

phase and pulse widths to allow transfer of data from an

asynchronous FIFO. Pulse width is independent of CKW duty

cycle, since proper phase and duty cycle is maintained by the

PLL. The RP pulse stream ensures correct data transfers

between asynchronous FIFOs and the transmitter input latch

with no external logic.

Test Logic

Test logic includes the initialization and control for the BIST

generator, the multiplexer for test mode clock distribution, and

control logic to properly select the data encoding. Test logic is

discussed in detail in CY7B923 HOTLink Transmitter Operating

Mode Description on page 11.

CY7B933 HOTLink Receiver Block Diagram

Description

Serial Data Inputs

Two pairs of differential line receivers are the inputs for the serial

data stream. INA± or INB± can be selected with the A/B input.

INA± is selected with A/B HIGH and INB± is selected with A/B

LOW. The threshold of A/B is compatible with the ECL 100K

signals from PECL fiber optic interface modules. TTL logic

elements can be used to select the A or B inputs by adding a

resistor pull-up to the TTL driver connected to A/B. The

differential threshold of INA± and INB± will accommodate wire

interconnect with filtering losses or transmission line attenuation

greater than 20 db (VDIF > 50 mv) or can be directly connected

to fiber optic interface modules (any ECL logic family, not limited

to ECL 100K). The common mode tolerance will accommodate

a wide range of signal termination voltages. The highest HIGH

input that can be tolerated is VIN = VCC, and the lowest LOW

input that can be interpreted correctly is VIN = GND+2.0V.

PECL-TTL Translator

The function of the INB(INB+) input and the SI(INB–) input is

defined by the connections on the SO output pin. If the

PECL/TTL translator function is not required, the SO output is

wired to VCC. A sensor circuit detects this connection and

causes the inputs to become INB± (a differential line-receiver

serial-data input). If the PECL/TTL translator function is required,

the SO output is connected to its normal TTL load (typically one

or more TTL inputs, but no pull-up resistor) and the INB+ input

becomes single-ended ECL 100K, serial data input (INB) and the

INB– input becomes single-ended, ECL 100K status input (SI).

This positive-referenced PECL-to-TTL translator is provided to

eliminate external logic between an PECL fiber-optic interface

module “carrier detect” output and the TTL input in the control

logic. The input threshold is compatible with ECL 100K levels

(+5-V referenced). It can also be used as part of the link status

indication logic for wire connected systems.

Clock Synchronization

The clock synchronization function is performed by an

embedded PLL that tracks the frequency of the incoming bit

stream and aligns the phase of its internal bit rate clock to the

serial data transitions. This block contains the logic to transfer

the data from the shifter to the decode register once every byte.

The counter that controls this transfer is initialized by the framer

logic. CKR is a buffered output derived from the bit counter used

to control the decode register and the output register transfers.

Clock output logic is designed so that when reframing causes the

counter sequence to be interrupted, the period and pulse width

of CKR is never less than normal. Reframing may stretch the

period of CKR by up to 90%, and either CKR Pulse Width HIGH

or Pulse Width LOW may be stretched, depending on when

reframe occurs.

The REFCLK input provides a byte-rate reference frequency to

improve PLL acquisition time and limit unlocked frequency

excursions of the CKR when no data is present at the serial

inputs. The frequency of REFCLK is required to be within ±0.1%

of the frequency of the clock that drives the transmitter CKW pin.

Framer

Framer logic checks the incoming bit stream for the pattern that

defines the byte boundaries. This combinatorial logic filter looks

for the X3.230 symbol defined as a Special Character Comma

(K28.5). When it is found, the free-running bit counter in the

Clock Synchronization block is synchronously reset to its initial

state, thus framing the data correctly on the correct byte bound-

aries.

Random errors that occur in the serial data can corrupt some

data patterns into a bit pattern identical to a K28.5, and thus

cause an erroneous data-framing error. The RF input prevents

this by inhibiting reframing during times when normal message

data is present. When RF is held LOW, the HOTLink receiver will

deserialize the incoming data without trying to reframe the data

to incoming patterns. When RF rises, RDY will be inhibited until

a K28.5 has been detected, after which RDY will resume its

normal function. While RF is HIGH, it is possible that an error

could cause misframing, after which all data will be corrupted.

Likewise, a K28.7 followed by D11.x, D20.x, or an SVS (C0.7)

followed by D11.x will create alias K28.5 characters and cause

erroneous framing. These sequences must be avoided while RF

is HIGH.

If RF remains HIGH for greater than 2048 bytes, the framer

converts to double-byte framing, requiring two K28.5 characters

aligned on the same byte boundary within 5 bytes in order to

reframe. Double-byte framing greatly reduces the possibility of

erroneously reframing to an aliased K28.5 character.

Shifter

The shifter accepts serial inputs from the serial data inputs one

bit at a time, as clocked by the clock synchronization logic. Data

is transferred to the framer on each bit, and to the decode

Decode Register

The decode register accepts data from the shifter once per byte

as determined by the logic in the clock synchronization block. It

is presented to the decoder and held until it is transferred to the

output latch.

CYPRESS' ' EMIEuummlnNannaw dala l5 lransformed from ANSl»speciﬁed X3 in the decoder. This bloc shown in Valid Dala C and Valid Special Ch IGH)[1,72] on page 2 larLd In BIST mode, lhe LFSR is inilialized b lhe lransminer BIST loop slan code Do op). Once lhe BIST loop h hern mismalches betw raled sequen occia The CY73923 Transmiher operaling wnh lhe CY7BQSS R form a general purpose dala communicalions subsysle capable ollransponing user dala al up lo 33 Mbyres pe 0 Moyles per second lor 4:00 devices) over severa rial inlerlace media. Figure 10 on page 34 illuslrale lalhrough lhe HOTLink CY78923lransmmerpip mm «wig lhe risi edge of C 551'“ mm Figure 5 illuslraleslhe dala llowlhrough lhe HO receiver pipeline. Ser dala is sampled by the let inpuls. The rece locks onlolhe se generales an inlerna clock, The oil s alized, decoded and nled al lhe p A oyle rale clock (o synchm dala is presented a lo LOW lo indicate receiver has a builHn byre lramer peline with incoming SYNC luslrales lhe HOTLink CY7 er is enabled when mo lhe receiveron characlers e und, lhe 33‘7“ When lhe RF pin is asserled ii normal mo foperalion and is asserled r searches ala slream for a K285 ch asm ized lo a K28!) charamer OW when lhe K285 cha he RDYp lllhen res The norm encoded mode is signal w Ms by p Low w Y % pulse pulse single

Document Number: 38-02017 Rev. *K Page 10 of 42

CY7B923/CY7B933

Decoder

Parallel data is transformed from ANSI-specified X3.230 8B/10B

codes back to ‘raw data’ in the decoder. This block uses the

standard decoder patterns shown in Valid Data Characters

(SC/D = LOW) on page 21 and Valid Special Character Codes

and Sequences (SC/D = HIGH)[1, 2] on page 29. Data patterns

are signaled by a LOW on the SC/D output and special character

patterns are signaled by a HIGH on the SC/D output. Unused

patterns or disparity errors are signaled as errors by a HIGH on

the RVS output and by specific special character codes.

Output Register

The output register holds the recovered data (Q0–7, SC/D, and

RVS) and aligns it with the recovered byte clock (CKR). This

synchronization insures proper timing to match a FIFO interface

or other logic that requires glitch-free and specified output

behavior. Outputs change synchronously with the rising edge of

CKR.

In BIST mode, this register becomes the signature pattern

generator and checker by logically converting itself into a linear

feedback shift register (LFSR) pattern generator. When enabled,

this LFSR generates a 511-byte sequence that includes all data

and special character codes, including the explicit violation

symbols. This pattern provides a predictable but pseudo-random

sequence that can be matched to an identical LFSR in the Trans-

mitter. When synchronized, it checks each byte in the Decoder

with each byte generated by the LFSR and shows errors at RVS.

Patterns generated by the LFSR are compared after being

buffered to the output pins and then fed back to the comparators,

allowing test of the entire receive function.

In BIST mode, the LFSR is initialized by the first occurrence of

the transmitter BIST loop start code D0.0 (D0.0 is sent only once

per BIST loop). Once the BIST loop has been started, RVS will

be HIGH for pattern mismatches between the received sequence

and the internally generated sequence. Code rule violations or

running disparity errors that occur as part of the BIST loop will

not cause an error indication. RDY will pulse HIGH once per

BIST loop and can be used to check test pattern progress. The

receiver BIST generator can be reinitialized by leaving and

re-entering BIST mode.

Test Logic

Test logic includes the initialization and control for the Built-In

Self-Test (BIST) generator, the multiplexer for Test mode clock

distribution, and control logic for the decoder. Test logic is

discussed in more detail in the CY7B933 HOTLink Receiver

Operating Mode Description.

HOTLink CY7B923 Transmitter and CY7B933

Receiver Operation

The CY7B923 Transmitter operating with the CY7B933 Receiver

form a general purpose data communications subsystem

capable of transporting user data at up to 33 Mbytes per second

(40 Mbytes per second for –400 devices) over several types of

serial interface media. Figure 10 on page 34 illustrates the flow

of data through the HOTLink CY7B923 transmitter pipeline. Data

is latched into the transmitter on the rising edge of CKW when

enabled by ENA or ENN. RP is asserted LOW with a 60%

LOW/40% HIGH duty cycle when ENA is LOW. RP may be used

as a read strobe for accessing data stored in a FIFO. The parallel

data flows through the encoder and is then shifted out of the

OUTx± PECL drivers. The bit-rate clock is generated internally

from a multiply-by-ten PLL clock generator. The latency through

the transmitter is approximately 21tB – 10 ns over the operating

range. A more complete description is found in the section

CY7B923 HOTLink Transmitter Operating Mode Description.

Figure 5 illustrates the data flow through the HOTLink CY7B933

receiver pipeline. Serial data is sampled by the receiver on the

INx± inputs. The receiver PLL locks onto the serial bit stream and

generates an internal bit rate clock. The bit stream is deseri-

alized, decoded and then presented at the parallel output pins.

A byte rate clock (bit clock  10) synchronous with the parallel

data is presented at the CKR pin. The RDY pin will be asserted

to LOW to indicate that data or control characters are present on

the outputs. RDY will not be asserted LOW in a field of K28.5s

except for any single K28.5 or the last one in a continuous series

of K28.5’s. The latency through the receiver is approximately

24tB + 10 ns over the operating range. A more complete

description of the receiver is in the section CY7B933 HOTLink

Receiver Operating Mode Description.

The HOTLink receiver has a built-in byte framer that synchro-

nizes the Receiver pipeline with incoming SYNC (K28.5)

characters. Figure 5 illustrates the HOTLink CY7B933 Receiver

framing operation. The Framer is enabled when the RF pin is

asserted HIGH. RF is latched into the receiver on the falling edge

of CKR. The framer looks for K28.5 characters embedded in the

serial data stream. When a K28.5 is found, the framer sets the

parallel byte boundary for subsequent data to the K28.5

boundary. While the framer is enabled, the RDY pin indicates the

status of the framing operation.

When the RF pin is asserted HIGH, RDY leaves it normal mode

of operation and is asserted HIGH while the framer searches the

data stream for a K28.5 character. After the framer has synchro-

nized to a K28.5 character, the Receiver will assert the RDY pin

LOW when the K28.5 character is present at the parallel output.

The RDY pin will then resume its normal operation as dictated by

the MODE and BISTEN pins.

The normal operation of the RDY pin in encoded mode is to

signal when parallel data is present at the output pins by pulsing

LOW with a 60% LOW/40% HIGH duty cycle. RDY does not

pulse LOW in a field of K28.5 characters; however, RDY does

pulse LOW for the last K28.5 character in the field or for any

single K28.5. In unencoded mode, the normal operation of the

RDY pin is to signal when any K28.5 is at the parallel output pins.

EMPRESS nnnnnnnnnnnnnnnnnn SERIAL DATA IN \(_ 4. XX XXX) XXX XXXXXXXXX XXXXX XXXX _\/‘+/\/\/\ /\/\/\ Jl \ ’7' X X X X X X X‘

Document Number: 38-02017 Rev. *K Page 11 of 42

CY7B923/CY7B933

Figure 4. CY7B933 Receiver Data Pipeline in Encoded Mode

The transmitter and receiver parallel interface timing and

functionality can be made to match the timing and functionality

of either an asynchronous FIFO or a clocked FIFO by appropri-

ately connecting signals (see Figure 6 on page 12). Proper

operation of the FIFO interface depends upon various

FIFO-specific access and response specifications.

The HOTLink transmitter and receiver serial interface provides a

seamless interface to various types of media. A minimal number

of external components are needed to properly terminate trans-

mission lines and provide PECL loads. For proper power supply

decoupling, a single 0.01 F for each device is all that is required

to bypass the VCC and GND pins. Figure 7 on page 14 illustrates

a HOTLink transmitter and receiver interface to fiber-optic and

copper media. More information on interfacing HOTLink to

various media can be found in the HOTLink Design Consider-

ations application note.

CY7B923 HOTLink Transmitter Operating

Mode Description

In normal operation, the transmitter can operate in either of two

modes. The encoded mode allows a user to send and receive

eight-bit data and control information without first converting it to

transmission characters. The bypass mode is used for systems

in which the encoding and decoding is performed in an external

protocol controller.

In either mode, data is loaded into the Input register of the Trans-

mitter on the rising edge of CKW. The input timing and functional

response of the Transmitter input can be made to match the

timing and functionality of either an asynchronous FIFO or a

clocked FIFO by an appropriate connection of input signals (see

Figure 6 on page 12). Proper operation of the FIFO interface

depends upon various FIFO-specific access and response

specifications.

Figure 5. CY7B933 Framing Operation in Encoded Mode

CKR

Q07,

SC/D,

RVS

RDY

INX

DATAK28.5

DATA

K28.5

SERIAL DATA IN

PARALLEL

DATA OUT

RDY IS HIGH IN FIELD OF K28.5S

RDY IS LOW FOR LAST K28.5

DATA

RDY IS LOW FOR DATA

RECEIVER LATENCY= 24tB+10ns

CKR

Q07,

SC/D,

RVS

RDY RDY IS HIGH WHILE WAITING FOR K28.5

RDY IS LOW

FOR K28.5

K28.5

DATADATADATADATADATA DATA DATA

RDY RESUMES

NORMAL

OPERATION

CKR STRETCHES AS

DATA BOUNDARY CHANGES

RF LATCHED ON

FALLING EDGE OF CKR

CYPRESS ' manna: mlanRRaw In rhe enc mode, rhe inpur d lg of dara (Du camex‘ comm diagnosric (SVS). If‘hg normal me dara shou described cog ‘—-> U“ \‘>\ able as special sling, as we“ link errors pan OJ

Document Number: 38-02017 Rev. *K Page 12 of 42

CY7B923/CY7B933

Encoded Mode Operation

In the encoded mode, the input data is interpreted as eight bits

of data (D0–D7), a context control bit (SC/D), and a system

diagnostic input bit (SVS). If the context of the data is to be

normal message data, the SC/D input should be LOW, and the

data should be encoded using the valid data character set

described in Valid Data Characters (SC/D = LOW) on page 21.

If the context of the data is to be control or protocol information,

the SC/D input is HIGH, and the data is encoded using the valid

special character set described in Valid Special Character Codes

and Sequences (SC/D = HIGH)[1, 2] on page 29. Special

characters include all protocol characters necessary to encode

packets for Fibre Channel, ESCON, proprietary systems, and

diagnostic purposes.

The diagnostic characters and sequences available as special

characters include those for Fibre Channel link testing, as well

as codes to be used for testing system response to link errors

and timing. A Violation symbol can be explicitly sent as part of a

user data packet (i.e., send C0.7; D7–0 = 111 00000 and SC/D =

1), or it can be sent in response to an external system using the

SVS input. This allows the system diagnostic logic to evaluate

the errors in an unambiguous manner, and does not require any

modification to the transmission interface to force transmission

errors for testing purposes.

Figure 6. Seamless FIFO Interface

7C42X/3X/6X/7X

CLOCKED FIFOASYNCHRONOUS FIFO

7C44X/5X

0–8 ENR CKR

7B923 7B923

ENA D0–7, SC/DCKW RP ENN CKW

FROM CONTROLLER

HOTLink TRANSMITTER

HOTLink RECEIVER

7B933 7B933

RDYCKRRDYCKR

WENW D0–8

CKW

7C42X/3X/6X/7X 7C44X/5X

CLOCKED FIFOASYNCHRONOUS FIFO

HOTLink RECEIVER

Q0–8

D0–7, SC/D

HOTLink TRANSMITTER

Q0–7, SC/D Q0–7, SC/D

D0–8

‘CYPRESS' ' EMIEnnzn m vmmw bypass either the encaded mode or bypass mm CM 5 when the inputs are not ena the encoder inserts a pad 0 to mainmin proper link proper sense cf runn ﬁrst pad character, ). This autamatic “(NJ mm

Document Number: 38-02017 Rev. *K Page 13 of 42

CY7B923/CY7B933

Bypass Mode Operation

In the bypass mode, the input data is interpreted as 10 bits

(Db–h), SC/D (Da), and SVS (Dj) of pre-encoded transmission

data to be serialized and sent over the link. This data can use

any encoding method suitable to the designer. The only restric-

tions upon the data encoding method is that it contain suitable

transition density for the receiver PLL data synchronizer (one per

10-bit byte), and that it be compatible with the transmission

media.

Data loaded into the Input register on the rising edge of CKW is

loaded into the shifter on the subsequent rising edges of CKW.

It will then be shifted to the outputs one bit at a time using the

internal clock generated by the clock generator. The first bit of

the transmission character (Da) appears at the output (OUTA±,

OUTB±, and OUTC±) after the next CKW edge.

While in either the encoded mode or bypass mode, if a CKW

edge arrives when the inputs are not enabled (ENA and ENN

both HIGH), the encoder inserts a pad character K28.5 (for

example, C5.0) to maintain proper link synchronization (in the

bypass mode the proper sense of running disparity cannot be

guaranteed for the first pad character, but is correct for all pad

characters that follow). This automatic insertion of pad

characters can be inhibited by insuring that the transmitter is

always enabled (that is, ENA or ENN is hard-wired LOW).

PECL Output Functional and Connection Options

The three pairs of PECL outputs all contain the same information

and are intended for use in systems with multiple connections.

Each output pair may be connected to a different serial media,

each of which may be a different length, link type, or interface

technology. For systems that do not require all three output pairs,

the unused pairs should be wired to VCC to minimize the power

dissipated by the output circuit, and to minimize unwanted noise

generation. An internal voltage comparator detects when an

output differential pair is wired to VCC, causing the current source

for that pair to be disabled. This results in a power savings of

around 5 mA for each unused pair.

In systems that require the outputs to be shut off during some

periods when link transmission is prohibited (for example, for

laser safety functions), the FOTO input can be asserted. While it

is possible to insure that the output state of the PECL drivers is

LOW (that is, light is off) by sending all 0s in bypass mode, it is

often inconvenient to insert this level of control into the data

transmission channel, and it is impossible in encoded mode.

FOTO is provided to simplify and augment this control function

(typically found in laser-based transmission systems). FOTO will

force OUTA+ and OUTB+ to go LOW, OUTA– and OUTB– to go

HIGH, while allowing OUTC± to continue to function normally

(OUTC is typically used as a diagnostic feedback and cannot be

disabled). This separation of function allows various system

configurations without undue load on the control function or data

channel logic.

Transmitter Serial Data Characteristics

The CY7B923 HOTLink transmitter serial output conforms to the

requirements of the Fibre Channel specification. The serial data

output is controlled by an internal PLL that multiplies the

frequency of CKW by 10 to maintain the proper bit clock

frequency. The jitter characteristics (including both PLL and logic

components) are as follows:

■Deterministic Jitter (Dj) < 35 ps (peak-peak). Typically

measured while sending a continuous K28.5 (C5.0).

■Random Jitter (Rj) < 175 ps (peak-peak). Typically measured

while sending a continuous K28.7 (C7.0).

Transmitter Test Mode Description

The CY7B923 transmitter offers two types of test mode

operation, BIST mode and Test mode. In a normal system appli-

cation, the BIST mode can be used to check the functionality of

the transmitter, the receiver, and the link connecting them. This

mode is available with minimal impact on user system logic, and

can be used as part of the normal system diagnostics. Typical

connections and timing are shown in Figure 8 on page 15.

Document Number: 38-02017 Rev. *K Page 14 of 42

CY7B923/CY7B933

Figure 7. HOTLink Connection Diagram

SIG

92421

VCC

Control

Config

and

Config

CY7B923

(Dj)

(Dh)

(Dg)

(Df)

(Di)

(De)

(Dd)

(Dc)

(Db)

(Da)

Transmitter

Coax or

Fiber

ESignal Det.

Optional

Fiber Optic

Twisted Pair

Coax or

Fiber Optic

PECL Load

Tx PECL Load

Transmission

Line

Termination

Status

Data

Status

Control

and

CY7B933

(Qa)

Receiver

(Qb)

(Qh)

(Qg)

(Qc)

(Qd)

(Qe)

(Qi)

(Qf)

(Qj)

0.01 F

922

RL/2

82 130

649

0.01 F

130

270

0.01 F

82 130

0.01 F

270

130

1500

VCC

GND

ENN

ENA

BISTEN

SVS

SC/D

OUTC–

OUTC+

OUTB–

OUTB+

OUTA–

OUTA+

MODE

FOTO

CKW

VCC

RX–

RX+

GND

VCC

TX–

TX+

GND

REFCLK

GND

RDY

BISTEN

SC/D

RVS

IB–

IB+

IA–

IA+

CKR

A/B

MODE

Unused Output Left

Open or Wired to VCC

270

to Minimize Power Dissipation

‘CYPRESS' ' manna: mlanRRaw WHH H H H l M l |—|_l'| (Q Q} HHW T Mode blsl loop, and can be used by an enema coumerto mon _ When uerlo run my

Document Number: 38-02017 Rev. *K Page 15 of 42

CY7B923/CY7B933

Figure 8. BIST Illustration

BIST Mode

The BIST mode functions as follows:

1. Set BISTEN LOW to begin test pattern generation. The trans-

mitter begins sending bit rate ...1010...

2. Set either ENA or ENN LOW to begin pattern sequence

generation (use of the Enable pin not being used for normal

FIFO or system interface can minimize logic delays between

the controller and transmitter).

3. Allow the transmitter to run through several BIST loops or until

the receiver test is complete. RP will pulse LOW once per

BIST loop, and can be used by an external counter to monitor

the number of test pattern loops.

4. When testing is completed, set BISTEN HIGH and ENA and

ENN HIGH and resume normal function.

Note: It may be advisable to send violation characters to test the

RVS output in the receiver. This can be done by explicitly

sending a violation with the SVS input, or allowing the transmitter

BIST loop to run while the receiver runs in normal mode. The

BIST loop includes deliberate violation symbols and will

adequately test the RVS function.

FOTO

MODE

CKW

SC/D

D0–7

SVS

ENA

ENN

BISTEN

REFCLK

MODE

CKR

SC/D

Q0–7

RVS

RDY

BISTEN

OUTA

OUTB

OUTC

DON'T CARE

INA

INB

A/B

CY7B923

CY7B933

BIST

START Tx

STOP

ERROR

TEST

START

TEST

END

BEGIN

LOOP

BIST

LOOP

TEST

LOW

DON'T CARE

LOW

WITHIN SPEC.

DON'T CARE

LOW

DON'T CARE

WITHIN SPEC.

DON'T CARE

HIGH

' ‘CYPRESS' 94:2an in lnmnnuw While in bypass way as in the en BISTEN = LOW e and beg The test mode cause mode, but with OutA input) as the bit rate PLL»generated bit c CKW and transiers timed the intern maint xedp pulse ieed gt reetransm byp “Le Since noise-induced erro corrupted, and because data can create an alia resynchronization of th hen the RF input is h bited until a K285 functioiD he violatio ta pache cause the incoming dat mbinations of error an option is included to The framer WM: riseﬂ lihput data is de_coded in trol bit (SC/D), and a pattern in the den rs table, the con_te d the SC/D the V in_te

Document Number: 38-02017 Rev. *K Page 16 of 42

CY7B923/CY7B933

BIST mode is intended to check the entire function of the trans-

mitter (except the transmitter input pins and the bypass function

in the Encoder), the serial link, and the receiver. It augments

normal factory ATE testing and provides the designer with a

rigorous test mechanism to check the link transmission system

without requiring any significant system overhead.

While in bypass mode, the BIST logic will function in the same

way as in the encoded mode. MODE = HIGH and

BISTEN = LOW causes the transmitter to switch to encoded

mode and begin sending the BIST pattern, as if MODE = LOW.

When BISTEN returns to HIGH, the Transmitter resumes normal

Bypass operation. In Test mode the BIST function works as in

the Normal mode. For more information on BIST, consult the

“HOTLink Built-In Self-Test” application note.

Test Mode

The MODE input pin selects between three transmitter functional

modes. When wired to VCC, the D(a–j) inputs bypass the encoder

and load directly from the input register into the shifter. When

wired to GND, the inputs D0–7, SVS, and SC/D are encoded

using the Fibre Channel 8B/10B codes and sequences (shown

at the end of this datasheet). Since the transmitter is usually

hardwired to encoded or bypass mode and not switched

between them, a third function is provided for the MODE pin. The

test mode is selected by floating the MODE pin (internal resistors

hold the MODE pin at VCC/2). Test mode is used for factory or

incoming device tests.

The test mode causes the transmitter to function in its encoded

mode, but with OutA+/OutB+ (used as a differential test clock

input) as the bit rate clock input instead of the internal

PLL-generated bit clock. In this mode, inputs are clocked by

CKW and transfers between the Input register and Shifter are

timed by the internal counters. The bit-clock and CKW must

maintain a fixed phase and divide-by-ten ratio. The phase and

pulse width of RP are controlled by phases of the bit counter (PLL

feedback counter) as in normal mode. Input and output patterns

can be synchronized with internal logic by observing the state of

RP or the device can be initialized to match an ATE test pattern

using the following technique:

1. With the MODE pin either HIGH or LOW, stop CKW and

bit-clock.

2. Force the MODE pin to MID (open or VCC/2) while the clocks

are stopped.

3. Start the bit-clock and let it run for at least two cycles.

4. Start the CKW clock at the bit-clock/10 rate.

Test mode is intended to allow logical, DC, and AC testing of the

transmitter without requiring that the tester check output data

patterns at the bit rate, or accommodate the PLL lock, tracking,

and frequency range characteristics that are required when the

HOTLink part operates in its normal mode. To use OutA+/OutB+

as the test clock input, the FOTO input is held HIGH while in Test

mode. This forces the two outputs to go to a ‘PECL LOW’ which

can be ignored while the test system creates a differential input

signal at some higher voltage.

CY7B933 HOTLink Receiver Operating Mode

Description

In normal user operation, the receiver can operate in either of

two modes. The encoded mode allows a user system to send

and receive eight-bit data and control information without first

converting it to transmission characters. The bypass mode is

used for systems in which the encoding and decoding is

performed by an external protocol controller.

In either mode, serial data is received at one of the differential

line receiver inputs and routed to the shifter and the clock

synchronization. The PLL in the clock synchronizer aligns the

internally generated bit rate clock with the incoming data stream

and clocks the data into the shifter. At the end of a byte time (ten

bit times), the data accumulated in the shifter is transferred to the

decode register.

To properly align the incoming bit stream to the intended byte

boundaries, the bit counter in the clock synchronizer must be

initialized. The framer logic block checks the incoming bit stream

for the unique pattern that defines the byte boundaries. This

combinatorial logic filter looks for the X3.230 symbol defined as

‘Special Character Comma’ (K28.5). After K28.5 is found, the

free running bit counter in the clock synchronizer block is

synchronously reset to its initial state, thus ‘framing’ the data to

the correct byte boundaries.

Since noise-induced errors can cause the incoming data to be

corrupted, and because many combinations of error and legal

data can create an alias K28.5, an option is included to disable

resynchronization of the bit counter. The framer will be inhibited

when the RF input is held LOW. When RF rises, RDY will be

inhibited until a K28.5 has been detected, and RDY will resume

its normal function. Data will continue to flow through the

Receiver while RDY is inhibited.

Encoded Mode Operation

In encoded mode the serial input data is decoded into eight bits

of data (Q0–Q7), a context control bit (SC/D), and a system

diagnostic output bit (RVS). If the pattern in the decode register

is found in the Valid Data Characters table, the context of the data

is decoded as normal message data and the SC/D output will be

LOW. If the incoming bit pattern is found in the Valid Special

Character Codes and Sequences table, it is interpreted as

‘control’ or ‘protocol information’, and the SC/D output will be

HIGH. Special characters include all protocol characters defined

for use in packets for Fibre Channel, ESCON, and other propri-

etary and diagnostic purposes.

The violation symbol that can be explicitly sent as part of a user

data packet (that is, transmitter sending C0.7; D7–0 = 111 00000

and SC/D = 1; or SVS = 1) will be decoded and indicated in

exactly the same way as a noise-induced error in the trans-

mission link. This function will allow system diagnostics to

evaluate the error in an unambiguous manner, and will not

require any modification to the receiver data interface for

error-testing purposes.

‘CYPRESS' ' Emma: m lnmnnaw Dala ouipuis can be clocked rising or falling egggof CKR, li CKR is used. RDY (23$ ogic. A LOW pul ived and is r LOW duly in asynch WM When lhe lransminer is disa charamers (K285), To assu with ihese dumm during lill slrings, ireceived dala. .55 all are de hen new dal “mic“ As noled above, W can a correm iraming oi received receipt oi a Kzemm RF inhibiled.Wh n RDYresu iramedaind be decod HIGH, ulsﬁn ﬂm using eilher th ng edge oi R r ihe rece hame l coniinuously send pad reieive FIFO will not RDY pulse ouipui is ouipuis Will refleci change, sinceg 0&1 ,5 followed by anoiher lo pulse. Any K28 egal used as Ie the RVS scrE Qouis Name

Document Number: 38-02017 Rev. *K Page 17 of 42

CY7B923/CY7B933

Bypass Mode Operation

In bypass mode the serial input data is not decoded, and is trans-

ferred directly from the decode register to the output register’s

10 bits (Q(a–j). It is assumed that the data has been preencoded

prior to transmission, and will be decoded in subsequent logic

external to HOTLink. This data can use any encoding method

suitable to the designer. The only restrictions upon the data

encoding method is that it contain suitable transition density for

the Receiver PLL data synchronizer (one per 10-bit byte) and

that it be compatible with the transmission media.

The framer function in bypass mode is identical to encoded

mode, so a K28.5 pattern can still be used to reframe the serial

bit stream.

Parallel Output Function

The 10 outputs (Q0–7, SC/D, and RVS) all transition simultane-

ously, and are aligned with RDY and CKR with timing allowances

to interface directly with either an asynchronous FIFO or a

clocked FIFO. Typical FIFO connections are shown in Figure 6

on page 12.

Data outputs can be clocked into the system using either the

rising or falling edge of CKR, or the rising or falling edge of RDY

If CKR is used, RDY can be used as an enable for the receiving

logic. A LOW pulse on RDY shows that new data has been

received and is ready to be delivered. The signal on RDY is a

60%-LOW duty cycle byte-rate pulse train suitable for the write

pulse in asynchronous FIFOs such as the CY7C42X, or the

enable write input on Clocked FIFOs such as the CY7C44X.

HIGH on RDY shows that the received data appearing at the

outputs is the null character (normally inserted by the transmitter

as a pad between data inputs) and should be ignored.

When the transmitter is disabled it will continuously send pad

characters (K28.5). To assure that the receive FIFO will not be

overfilled with these dummy bytes, the RDY pulse output is

inhibited during fill strings. Data at the Q0–7 outputs will reflect

the correct received data, but will not appear to change, since a

string of K28.5s all are decoded as Q7–0 =000 00101 and SC/D

= 1 (C5.0). When new data appears (not K28.5), the RDY output

will resume normal function. The “last” K28.5 will be accom-

panied by a normal RDY pulse.

Fill characters are defined as any K28.5 followed by another

K28.5. All fill characters will not cause RDY to pulse. Any K28.5

followed by any other character (including violation or illegal

characters) will be interpreted as usable data and will cause RDY

to pulse.

As noted above, RDY can also be used as an indication of

correct framing of received data. While the receiver is awaiting

receipt of a K28.5 with RF HIGH, the RDY outputs will be

inhibited. When RDY resumes, the received data will be properly

framed and will be decoded correctly. In Bypass mode with RF

HIGH, RDY will pulse once for each K28.5 received. For more

information on the RDY pin, consult the “HOTLink CY7B933

RDY Pin Description” application note.

Code rule violations and reception errors will be indicated as

follows:

RVS SC/DQouts Name

1. Good Data code received

with good running disparity (RD) 0 0 00-FFD0.0-31.7

2. Good Special Character

code received with good RD 0 1 00-0BC0.0-11.0

3. K28.7 immediately following

K28.1 (ESCON Connect_SOF) 0 1 27 C7.1

4. K28.7 immediately following

K28.5 (ESCON Passive_SOF) 0 1 47 C7.2

5. Unassigned code received 1 1 E0 C0.7

6. -K28.5+ received when

RD was + 1 1 E1 C1.7

7. +K28.5– received when

RD was – 1 1 E2 C2.7

8. Good code received

with wrong RD 1 1 E4 C4.7

Receiver Serial Data Requirements

The CY7B933 HOTLink Receiver serial input capability

conforms to the requirements of the Fibre Channel specification.

The serial data input is tracked by an internal PLL that is used to

recover the clock phase and to extract the data from the serial

bit stream. Jitter tolerance characteristics (including both PLL

and logic component requirements) are shown below:

■Deterministic Jitter Tolerance (Dj) > 40% of tB. Typically

measured while receiving data carried by a bandwidth-limited

channel (e.g., a coaxial transmission line) while maintaining a

Bit Error Rate (BER) < 10–12.

■Random Jitter Tolerance (Rj) > 90% of tB. Typically measured

while receiving data carried by a random-noise-limited channel

(e.g., a fiber-optic transmission system with low light levels)

while maintaining a Bit Error Rate (BER) < 10–12.

■Total Jitter Tolerance > 90% of tB. Total of Dj + Rj.

■PLL-acquisition time < 500-bit times from worst-case phase or

frequency change in the serial input data stream, to receiving

data within BER objective of 10–12. Stable power supplies

within specifications, stable REFCLK input frequency and

normal data framing protocols are assumed.

Note Acquisition time is measured from worst-case phase or

frequency change to zero phase and frequency error. As a

result of the receiver’s wide jitter tolerance, valid data appears

at the receiver’s outputs a few byte times after a worst-case

phase change.

' ‘CYPRESS' EMIEDDED m lnmnnuw M stm itcr RVS and check for any bﬂe lim ttem mismatches. RDY wil e used by an ege bypass mode, the BIST in the 53 the encoded mode. M the receivertc SWl received The MODE input pin selects betw modes. When wired to VCC, the eccder and go directly from the lthe output latch. When wired i ng the 83/103 codes showj

Document Number: 38-02017 Rev. *K Page 18 of 42

CY7B923/CY7B933

Receiver Test Mode Description

The CY7B933 receiver offers two types of test mode operation,

BIST mode and Test mode. In a normal system application, the

Built-In Self-Test (BIST) mode can be used to check the function-

ality of the transmitter, the receiver and the link connecting them.

This mode is available with minimal impact on user system logic,

and can be used as part of the normal system diagnostics.

Typical connections and timing are shown in Figure 8 on page 15.

BIST Mode

The BIST mode function is as follows:

1. Set BISTEN LOW to enable self-test generation and await

RDY LOW indicating that the initialization code has been re-

ceived.

2. Monitor RVS and check for any byte time with the pin HIGH

to detect pattern mismatches. RDY will pulse HIGH once per

BIST loop, and can be used by an external counter to monitor

test pattern progress. Q0–7 and SC/D will show the expected

pattern and may be useful for debug purposes.

3. When testing is completed, set BISTEN HIGH and resume

normal function.

Note A specific test of the RVS output may be required to assure

an adequate test. To perform this test, it is only necessary to have

the transmitter send violation (SVS = HIGH) for a few bytes

before beginning the BIST test sequence. Alternatively, the

receiver could enter BIST mode after the transmitter has begun

sending BIST loop data, or be removed before the transmitter

finishes sending BIST loops, each of which contain several delib-

erate violations and should cause RVS to pulse HIGH.

BIST mode is intended to check the entire function of the Trans-

mitter, serial link, and receiver. It augments normal factory ATE

testing and provides the user system with a rigorous test

mechanism to check the link transmission system, without

requiring any significant system overhead.

When in bypass mode, the BIST logic will function in the same

way as in the encoded mode. MODE = HIGH and BISTEN =

LOW causes the receiver to switch to encoded mode and begin

checking the decoded received data of the BIST pattern, as if

MODE = LOW. When BISTEN returns to HIGH, the receiver

resumes normal bypass operation. In test mode the BIST

function works as in the normal mode.

Test Mode

The MODE input pin selects between three receiver functional

modes. When wired to VCC, the shifter contents bypass the

decoder and go directly from the decoder latch to the Qa–j inputs

of the output latch. When wired to GND, the outputs are decoded

using the 8B/10B codes shown at the end of this datasheet and

become Q0–7, RVS, and SC/D. The third function is test mode,

used for factory or incoming device test. This mode can be

selected by leaving the MODE pin open (internal circuitry forces

the open pin to VCC/2).

Test mode causes the Receiver to function in its Encoded mode,

but with INB (INB+) as the bit rate Test clock instead of the

Internal PLL generated bit clock. In this mode, transfers between

the Shifter, Decoder register and Output register are controlled

by their normal logic, but with an external bit rate clock instead

of the PLL (the recovered bit clock). Internal logic and test pattern

inputs can be synchronized by sending a SYNC pattern and

allowing the Framer to align the logic to the bit stream. The flow

is as follows:

1. Assert Test mode for several test clock cycles to establish

normal counter sequence.

2. Assert RF to enable reframing.

3. Input a repeating sequence of bits representing K28.5 (Sync).

4. RDY falling shows the byte boundary established by the

K28.5 input pattern.

5. Proceed with pattern, voltage and timing tests as is conve-

nient for the test program and tester to be used.

(While in Test mode and in BIST mode with RF HIGH, the Q0–7,

RVS, and SC/D outputs reflect various internal logic states and

not the received data.)

Test mode is intended to allow logical, DC, and AC testing of the

Receiver without requiring that the tester generate input data at

the bit rate or accommodate the PLL lock, tracking and

frequency range characteristics that are required when the part

operates in its normal mode.

X3.230 Codes and Notation Conventions

Information to be transmitted over a serial link is encoded eight

bits at a time into a 10-bit Transmission Character and then sent

serially, bit by bit. Information received over a serial link is

collected ten bits at a time, and those Transmission Characters

that are used for data (Data Characters) are decoded into the

correct eight-bit codes. The 10-bit Transmission Code supports

all 256 8-bit combinations. Some of the remaining Transmission

Characters (Special Characters) are used for functions other

than data transmission.

The primary rationale for use of a Transmission Code is to

improve the transmission characteristics of a serial link. The

encoding defined by the Transmission Code ensures that suffi-

cient transitions are present in the serial bit stream to make clock

recovery possible at the Receiver. Such encoding also greatly

increases the likelihood of detecting any single or multiple bit

errors that may occur during transmission and reception of infor-

mation. In addition, some Special Characters of the Trans-

mission Code selected by Fibre Channel Standard consist of a

distinct and easily recognizable bit pattern (the Special Character

Comma) that assists a Receiver in achieving word alignment on

the incoming bit stream.

Notation Conventions

The documentation for the 8B/10B Transmission Code uses

letter notation for the bits in an 8-bit byte. Fibre Channel Standard

notation uses a bit notation of A, B, C, D, E, F, G, H for the 8-bit

byte for the raw 8-bit data, and the letters a, b, c, d, e, i, f, g, h, j

for encoded 10-bit data. There is a correspondence between bit

A and bit a, B and b, C and c, D and d, E and e, F and f, G and

g, and H and h. Bits i and j are derived, respectively, from

(A,B,C,D,E) and (F,G,H).

The bit labeled A in the description of the 8B/10B Transmission

Code corresponds to bit 0 in the numbering scheme of the FC-2

specification, B corresponds to bit 1, as shown below.

FC-2 bit designation—76543 21 0

HOTLink D/Q designation—76543210

8B/10B bit designation—HGFEDCBA

CYPRESS ' su-snm m man-w 7 654 32 10 ABCDEFGH abcdejfghj DB Transmis g conventi mission SCI_6

Document Number: 38-02017 Rev. *K Page 19 of 42

CY7B923/CY7B933

To clarify this correspondence, the following example shows the

conversion from an FC-2 Valid Data Byte to a Transmission

Character (using 8B/10B Transmission Code notation)

FC-2 45

Bits: 76543210

01000101

Converted to 8B/10B notation (note carefully that the order of bits

is reversed):

Data Byte NameD5.2

Bits: ABCDEFGH

10100010

Translated to a transmission Character in the 8B/10B Trans-

mission Code:

Bits: abcdeifghj

1010010101

Each valid Transmission Character of the 8B/10B Transmission

Code has been given a name using the following convention:

cxx.y, where c is used to show whether the Transmission

Character is a Data Character (c is set to D, and the SC/D pin is

LOW) or a Special Character (c is set to K, and the SC/D pin is

HIGH). When c is set to D, xx is the decimal value of the binary

number composed of the bits E, D, C, B, and A in that order, and

the y is the decimal value of the binary number composed of the

bits H, G, and F in that order. When c is set to K, xx and y are

derived by comparing the encoded bit patterns of the Special

Character to those patterns derived from encoded Valid Data

bytes and selecting the names of the patterns most similar to the

encoded bit patterns of the Special Character.

Under the above conventions, the Transmission Character used

for the examples above, is referred to by the name D5.2. The

Special Character K29.7 is so named because the first six bits

(abcdei) of this character make up a bit pattern similar to that

resulting from the encoding of the unencoded 11101 pattern (29),

and because the second four bits (fghj) make up a bit pattern

similar to that resulting from the encoding of the unencoded 111

pattern (7).

Note: This definition of the 10-bit Transmission Code is based

on (and is in basic agreement with) the following references,

which describe the same 10-bit transmission code.

A.X. Widmer and P.A. Franaszek. “A DC-Balanced, Parti-

tioned-Block, 8B/10B Transmission Code” IBM Journal of

Research and Development, 27, No. 5: 440-451 (September, 1983).

U.S. Patent 4, 486, 739. Peter A. Franaszek and Albert X.

Widmer. “Byte-Oriented DC Balanced (0.4) 8B/10B Partitioned

Block Transmission Code” (December 4, 1984).

Fibre Channel Physical and Signaling Interface (dpANS

X3.230-199X ANSI FC-PH Standard).

IBM Enterprise Systems Architecture/390 ESCON I/O Interface

(document number SA22-7202).

8B/10B Transmission Code

The following information describes how the tables shall be used

for both generating valid Transmission Characters (encoding)

and checking the validity of received Transmission Characters

(decoding). It also specifies the ordering rules to be followed

when transmitting the bits within a character and the characters

within the higher-level constructs specified by the standard.

Transmission Order

Within the definition of the 8B/10B Transmission Code, the bit

positions of the Transmission Characters are labeled a, b, c, d,

e, i, f, g, h, j. Bit “a” shall be transmitted first followed by bits b, c,

d, e, i, f, g, h, and j in that order. (Note that bit i shall be trans-

mitted between bit e and bit f, rather than in alphabetical order.)

Valid and Invalid Transmission Characters

The following tables define the valid Data Characters and valid

Special Characters (K characters), respectively. The tables are

used for both generating valid Transmission Characters

(encoding) and checking the validity of received Transmission

Characters (decoding). In the tables, each Valid-Data-byte or

Special-Character-code entry has two columns that represent

two (not necessarily different) Transmission Characters. The two

columns correspond to the current value of the running disparity

(“Current RD–” or “Current RD+”). Running disparity is a binary

parameter with either the value negative (–) or the value positive

(+).

After powering on, the Transmitter may assume either a positive

or negative value for its initial running disparity. Upon trans-

mission of any Transmission Character, the transmitter will select

the proper version of the Transmission Character based on the

current running disparity value, and the Transmitter shall

calculate a new value for its running disparity based on the

contents of the transmitted character. Special Character codes

C1.7 and C2.7 can be used to force the transmission of a specific

Special Character with a specific running disparity as required for

some special sequences in X3.230.

After powering on, the Receiver may assume either a positive or

negative value for its initial running disparity. Upon reception of

any Transmission Character, the Receiver shall decide whether

the Transmission Character is valid or invalid according to the

following rules and tables and shall calculate a new value for its

Running Disparity based on the contents of the received

character.

The following rules for running disparity shall be used to calculate

the new running-disparity value for Transmission Characters that

have been transmitted (Transmitter’s running disparity) and that

have been received (Receiver’s running disparity).

Running disparity for a Transmission Character shall be calcu-

lated from sub-blocks, where the first six bits (abcdei) form one

sub-block and the second four bits (fghj) form the other

sub-block. Running disparity at the beginning of the 6-bit

sub-block is the running disparity at the end of the previous

Transmission Character. Running disparity at the beginning of

the 4-bit sub-block is the running disparity at the end of the 6-bit

sub-block. Running disparity at the end of the Transmission

Character is the running disparity at the end of the 4-bit

sub-block.

Document Number: 38-02017 Rev. *K Page 20 of 42

CY7B923/CY7B933

Running disparity for the sub-blocks shall be calculated as

follows:

1. Running disparity at the end of any sub-block is positive if the

sub-block contains more ones than zeros. It is also positive at

the end of the 6-bit sub-block if the 6-bit sub-block is 000111,

and it is positive at the end of the 4-bit sub-block if the 4-bit

sub-block is 0011.

2. Running disparity at the end of any sub-block is negative if the

sub-block contains more zeros than ones. It is also negative

at the end of the 6-bit sub-block if the 6-bit sub-block is

111000, and it is negative at the end of the 4-bit sub-block if

the 4-bit sub-block is 1100.

3. Otherwise, running disparity at the end of the sub-block is the

same as at the beginning of the sub-block.

Using the Tables for Generating Transmission

Characters

The appropriate entry in the table shall be found for the valid data

byte or the special character byte for which a transmission

character is to be generated (encoded). The current value of the

transmitter’s running disparity shall be used to select the trans-

mission character from its corresponding column. For each

transmission character transmitted, a new value of the running

disparity shall be calculated. This new value shall be used as the

transmitter’s current running disparity for the next valid data byte

or special character byte to be encoded and transmitted. Tab l e 3

shows naming notations and examples of valid transmission

characters.

Using the Tables for Checking the Validity of Received

Transmission Characters

The column corresponding to the current value of the receiver’s

running disparity shall be searched for the received transmission

character. If the received transmission character is found in the

proper column, then the transmission character is valid and the

associated data byte or special character code is determined

(decoded). If the received transmission character is not found in

that column, then the transmission character is invalid. This is

called a code violation. Independent of the transmission

character’s validity, the received transmission character shall be

used to calculate a new value of running disparity. The new value

shall be used as the receiver’s current running disparity for the

next received transmission character.

Detection of a code violation does not necessarily show that the transmission character in which the code violation was detected is

in error. Code violations may result from a prior error that altered the running disparity of the bit stream which did not result in a

detectable error at the transmission character in which the error occurred. Table 4 shows an example of this behavior.

Table 3. Valid Transmission Characters

Data

Byte Name DIN or QOUT Hex Value

765 43210

D0.0 000 00000 00

D1.0 000 00001 01

D2.0 000 00010 02

D5.2 010 000101 45

D30.7 111 11110 FE

D31.7 111 11111 FF

Table 4. Code Violations Resulting from Prior Errors

Description RD Character RD Character RD Character RD

Transmitted data character –D21.1 –D10.2 –D23.5 +

Transmitted bit stream –101010 1001 –010101 0101 –111010 1010 +

Bit stream after error –101010 1011 +010101 0101 +111010 1010 +

Decoded data character –D21.0 +D10.2 +Code Violation +

Document Number: 38-02017 Rev. *K Page 21 of 42

CY7B923/CY7B933

Valid Data Characters (SC/D = LOW)

Data Byte

Name

Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

D0.0 000 00000 100111 0100 011000 1011

D1.0 000 00001 011101 0100 100010 1011

D2.0 000 00010 101101 0100 010010 1011

D3.0 000 00011 110001 1011 110001 0100

D4.0 000 00100 110101 0100 001010 1011

D5.0 000 00101 101001 1011 101001 0100

D6.0 000 00110 011001 1011 011001 0100

D7.0 000 00111 111000 1011 000111 0100

D8.0 000 01000 111001 0100 000110 1011

D9.0 000 01001 100101 1011 100101 0100

D10.0 000 01010 010101 1011 010101 0100

D11.0 000 01011 110100 1011 110100 0100

D12.0 000 01100 001101 1011 001101 0100

D13.0 000 01101 101100 1011 101100 0100

D14.0 000 01110 011100 1011 011100 0100

D15.0 000 01111 010111 0100 101000 1011

D16.0 000 10000 011011 0100 100100 1011

D17.0 000 10001 100011 1011 100011 0100

D18.0 000 10010 010011 1011 010011 0100

D19.0 000 10011 110010 1011 110010 0100

D20.0 000 10100 001011 1011 001011 0100

D21.0 000 10101 101010 1011 101010 0100

D22.0 000 10110 011010 1011 011010 0100

D23.0 000 10111 111010 0100 000101 1011

D24.0 000 11000 110011 0100 001100 1011

D25.0 000 11001 100110 1011 100110 0100

D26.0 000 11010 010110 1011 010110 0100

D27.0 000 11011 110110 0100 001001 1011

D28.0 000 11100 001110 1011 001110 0100

D29.0 000 11101 101110 0100 010001 1011

D30.0 000 11110 011110 0100 100001 1011

D31.0 000 11111 101011 0100 010100 1011

Document Number: 38-02017 Rev. *K Page 22 of 42

CY7B923/CY7B933

D0.1 001 00000 100111 1001 011000 1001

D1.1 001 00001 011101 1001 100010 1001

D2.1 001 00010 101101 1001 010010 1001

D3.1 001 00011 110001 1001 110001 1001

D4.1 001 00100 110101 1001 001010 1001

D5.1 001 00101 101001 1001 101001 1001

D6.1 001 00110 011001 1001 011001 1001

D7.1 001 00111 111000 1001 000111 1001

D8.1 001 01000 111001 1001 000110 1001

D9.1 001 01001 100101 1001 100101 1001

D10.1 001 01010 010101 1001 010101 1001

D11.1 001 01011 110100 1001 110100 1001

D12.1 001 01100 001101 1001 001101 1001

D13.1 001 01101 101100 1001 101100 1001

D14.1 001 01110 011100 1001 011100 1001

D15.1 001 01111 010111 1001 101000 1001

D16.1 001 10000 011011 1001 100100 1001

D17.1 001 10001 100011 1001 100011 1001

D18.1 001 10010 010011 1001 010011 1001

D19.1 001 10011 110010 1001 110010 1001

D20.1 001 10100 001011 1001 001011 1001

D21.1 001 10101 101010 1001 101010 1001

D22.1 001 10110 011010 1001 011010 1001

D23.1 001 10111 111010 1001 000101 1001

D24.1 001 11000 110011 1001 001100 1001

D25.1 001 11001 100110 1001 100110 1001

D26.1 001 11010 010110 1001 010110 1001

D27.1 001 11011 110110 1001 001001 1001

D28.1 001 11100 001110 1001 001110 1001

D29.1 001 11101 101110 1001 010001 1001

D30.1 001 11110 011110 1001 100001 1001

D31.1 001 11111 101011 1001 010100 1001

D0.2 010 00000 100111 0101 011000 0101

Valid Data Characters (SC/D = LOW) (continued)

Data Byte

Name

Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

Document Number: 38-02017 Rev. *K Page 23 of 42

CY7B923/CY7B933

D1.2 010 00001 011101 0101 100010 0101

D2.2 010 00010 101101 0101 010010 0101

D3.2 010 00011 110001 0101 110001 0101

D4.2 010 00100 110101 0101 001010 0101

D5.2 010 00101 101001 0101 101001 0101

D6.2 010 00110 011001 0101 011001 0101

D7.2 010 00111 111000 0101 000111 0101

D8.2 010 01000 111001 0101 000110 0101

D9.2 010 01001 100101 0101 100101 0101

D10.2 010 01010 010101 0101 010101 0101

D11.2 010 01011 110100 0101 110100 0101

D12.2 010 01100 001101 0101 001101 0101

D13.2 010 01101 101100 0101 101100 0101

D14.2 010 01110 011100 0101 011100 0101

D15.2 010 01111 010111 0101 101000 0101

D16.2 010 10000 011011 0101 100100 0101

D17.2 010 10001 100011 0101 100011 0101

D18.2 010 10010 010011 0101 010011 0101

D19.2 010 10011 110010 0101 110010 0101

D20.2 010 10100 001011 0101 001011 0101

D21.2 010 10101 101010 0101 101010 0101

D22.2 010 10110 011010 0101 011010 0101

D23.2 010 10111 111010 0101 000101 0101

D24.2 010 11000 110011 0101 001100 0101

D25.2 010 11001 100110 0101 100110 0101

D26.2 010 11010 010110 0101 010110 0101

D27.2 010 11011 110110 0101 001001 0101

D28.2 010 11100 001110 0101 001110 0101

D29.2 010 11101 101110 0101 010001 0101

D30.2 010 11110 011110 0101 100001 0101

D31.2 010 11111 101011 0101 010100 0101

D0.3 011 00000 100111 0011 011000 1100

D1.3 011 00001 011101 0011 100010 1100

Valid Data Characters (SC/D = LOW) (continued)

Data Byte

Name

Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

Document Number: 38-02017 Rev. *K Page 24 of 42

CY7B923/CY7B933

D2.3 011 00010 101101 0011 010010 1100

D3.3 011 00011 110001 1100 110001 0011

D4.3 011 00100 110101 0011 001010 1100

D5.3 011 00101 101001 1100 101001 0011

D6.3 011 00110 011001 1100 011001 0011

D7.3 011 00111 111000 1100 000111 0011

D8.3 011 01000 111001 0011 000110 1100

D9.3 011 01001 100101 1100 100101 0011

D10.3 011 01010 010101 1100 010101 0011

D11.3 011 01011 110100 1100 110100 0011

D12.3 011 01100 001101 1100 001101 0011

D13.3 011 01101 101100 1100 101100 0011

D14.3 011 01110 011100 1100 011100 0011

D15.3 011 01111 010111 0011 101000 1100

D16.3 011 10000 011011 0011 100100 1100

D17.3 011 10001 100011 1100 100011 0011

D18.3 011 10010 010011 1100 010011 0011

D19.3 011 10011 110010 1100 110010 0011

D20.3 011 10100 001011 1100 001011 0011

D21.3 011 10101 101010 1100 101010 0011

D22.3 011 10110 011010 1100 011010 0011

D23.3 011 10111 111010 0011 000101 1100

D24.3 011 11000 110011 0011 001100 1100

D25.3 011 11001 100110 1100 100110 0011

D26.3 011 11010 010110 1100 010110 0011

D27.3 011 11011 110110 0011 001001 1100

D28.3 011 11100 001110 1100 001110 0011

D29.3 011 11101 101110 0011 010001 1100

D30.3 011 11110 011110 0011 100001 1100

D31.3 011 11111 101011 0011 010100 1100

D0.4 100 00000 100111 0010 011000 1101

D1.4 100 00001 011101 0010 100010 1101

D2.4 100 00010 101101 0010 010010 1101

Valid Data Characters (SC/D = LOW) (continued)

Data Byte

Name

Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

Document Number: 38-02017 Rev. *K Page 25 of 42

CY7B923/CY7B933

D3.4 100 00011 110001 1101 110001 0010

D4.4 100 00100 110101 0010 001010 1101

D5.4 100 00101 101001 1101 101001 0010

D6.4 100 00110 011001 1101 011001 0010

D7.4 100 00111 111000 1101 000111 0010

D8.4 100 01000 111001 0010 000110 1101

D9.4 100 01001 100101 1101 100101 0010

D10.4 100 01010 010101 1101 010101 0010

D11.4 100 01011 110100 1101 110100 0010

D12.4 100 01100 001101 1101 001101 0010

D13.4 100 01101 101100 1101 101100 0010

D14.4 100 01110 011100 1101 011100 0010

D15.4 100 01111 010111 0010 101000 1101

D16.4 100 10000 011011 0010 100100 1101

D17.4 100 10001 100011 1101 100011 0010

D18.4 100 10010 010011 1101 010011 0010

D19.4 100 10011 110010 1101 110010 0010

D20.4 100 10100 001011 1101 001011 0010

D21.4 100 10101 101010 1101 101010 0010

D22.4 100 10110 011010 1101 011010 0010

D23.4 100 10111 111010 0010 000101 1101

D24.4 100 11000 110011 0010 001100 1101

D25.4 100 11001 100110 1101 100110 0010

D26.4 100 11010 010110 1101 010110 0010

D27.4 100 11011 110110 0010 001001 1101

D28.4 100 11100 001110 1101 001110 0010

D29.4 100 11101 101110 0010 010001 1101

D30.4 100 11110 011110 0010 100001 1101

D31.4 100 11111 101011 0010 010100 1101

D0.5 101 00000 100111 1010 011000 1010

D1.5 101 00001 011101 1010 100010 1010

D2.5 101 00010 101101 1010 010010 1010

D3.5 101 00011 110001 1010 110001 1010

Valid Data Characters (SC/D = LOW) (continued)

Data Byte

Name

Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

Document Number: 38-02017 Rev. *K Page 26 of 42

CY7B923/CY7B933

D4.5 101 00100 110101 1010 001010 1010

D5.5 101 00101 101001 1010 101001 1010

D6.5 101 00110 011001 1010 011001 1010

D7.5 101 00111 111000 1010 000111 1010

D8.5 101 01000 111001 1010 000110 1010

D9.5 101 01001 100101 1010 100101 1010

D10.5 101 01010 010101 1010 010101 1010

D11.5 101 01011 110100 1010 110100 1010

D12.5 101 01100 001101 1010 001101 1010

D13.5 101 01101 101100 1010 101100 1010

D14.5 101 01110 011100 1010 011100 1010

D15.5 101 01111 010111 1010 101000 1010

D16.5 101 10000 011011 1010 100100 1010

D17.5 101 10001 100011 1010 100011 1010

D18.5 101 10010 010011 1010 010011 1010

D19.5 101 10011 110010 1010 110010 1010

D20.5 101 10100 001011 1010 001011 1010

D21.5 101 10101 101010 1010 101010 1010

D22.5 101 10110 011010 1010 011010 1010

D23.5 101 10111 111010 1010 000101 1010

D24.5 101 11000 110011 1010 001100 1010

D25.5 101 11001 100110 1010 100110 1010

D26.5 101 11010 010110 1010 010110 1010

D27.5 101 11011 110110 1010 001001 1010

D28.5 101 11100 001110 1010 001110 1010

D29.5 101 11101 101110 1010 010001 1010

D30.5 101 11110 011110 1010 100001 1010

D31.5 101 11111 101011 1010 010100 1010

D0.6 110 00000 100111 0110 011000 0110

D1.6 110 00001 011101 0110 100010 0110

D2.6 110 00010 101101 0110 010010 0110

D3.6 110 00011 110001 0110 110001 0110

D4.6 110 00100 110101 0110 001010 0110

Valid Data Characters (SC/D = LOW) (continued)

Data Byte

Name

Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

Document Number: 38-02017 Rev. *K Page 27 of 42

CY7B923/CY7B933

D5.6 110 00101 101001 0110 101001 0110

D6.6 110 00110 011001 0110 011001 0110

D7.6 110 00111 111000 0110 000111 0110

D8.6 110 01000 111001 0110 000110 0110

D9.6 110 01001 100101 0110 100101 0110

D10.6 110 01010 010101 0110 010101 0110

D11.6 110 01011 110100 0110 110100 0110

D12.6 110 01100 001101 0110 001101 0110

D13.6 110 01101 101100 0110 101100 0110

D14.6 110 01110 011100 0110 011100 0110

D15.6 110 01111 010111 0110 101000 0110

D16.6 110 10000 011011 0110 100100 0110

D17.6 110 10001 100011 0110 100011 0110

D18.6 110 10010 010011 0110 010011 0110

D19.6 110 10011 110010 0110 110010 0110

D20.6 110 10100 001011 0110 001011 0110

D21.6 110 10101 101010 0110 101010 0110

D22.6 110 10110 011010 0110 011010 0110

D23.6 110 10111 111010 0110 000101 0110

D24.6 110 11000 110011 0110 001100 0110

D25.6 110 11001 100110 0110 100110 0110

D26.6 110 11010 010110 0110 010110 0110

D27.6 110 11011 110110 0110 001001 0110

D28.6 110 11100 001110 0110 001110 0110

D29.6 110 11101 101110 0110 010001 0110

D30.6 110 11110 011110 0110 100001 0110

D31.6 110 11111 101011 0110 010100 0110

D0.7 111 00000 100111 0001 011000 1110

D1.7 111 00001 011101 0001 100010 1110

D2.7 111 00010 101101 0001 010010 1110

D3.7 111 00011 110001 1110 110001 0001

D4.7 111 00100 110101 0001 001010 1110

D5.7 111 00101 101001 1110 101001 0001

Valid Data Characters (SC/D = LOW) (continued)

Data Byte

Name

Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

Document Number: 38-02017 Rev. *K Page 28 of 42

CY7B923/CY7B933

D6.7 111 00110 011001 1110 011001 0001

D7.7 111 00111 111000 1110 000111 0001

D8.7 111 01000 111001 0001 000110 1110

D9.7 111 01001 100101 1110 100101 0001

D10.7 111 01010 010101 1110 010101 0001

D11.7 111 01011 110100 1110 110100 1000

D12.7 111 01100 001101 1110 001101 0001

D13.7 111 01101 101100 1110 101100 1000

D14.7 111 01110 011100 1110 011100 1000

D15.7 111 01111 010111 0001 101000 1110

D16.7 111 10000 011011 0001 100100 1110

D17.7 111 10001 100011 0111 100011 0001

D18.7 111 10010 010011 0111 010011 0001

D19.7 111 10011 110010 1110 110010 0001

D20.7 111 10100 001011 0111 001011 0001

D21.7 111 10101 101010 1110 101010 0001

D22.7 111 10110 011010 1110 011010 0001

D23.7 111 10111 111010 0001 000101 1110

D24.7 111 11000 110011 0001 001100 1110

D25.7 111 11001 100110 1110 100110 0001

D26.7 111 11010 010110 1110 010110 0001

D27.7 111 11011 110110 0001 001001 1110

D28.7 111 11100 001110 1110 001110 0001

D29.7 111 11101 101110 0001 010001 1110

D30.7 111 11110 011110 0001 100001 1110

D31.7 111 11111 101011 0001 010100 1110

Valid Data Characters (SC/D = LOW) (continued)

Data Byte

Name

Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

RDr

Document Number: 38-02017 Rev. *K Page 29 of 42

CY7B923/CY7B933

Valid Special Character Codes and Sequences (SC/D = HIGH)[1, 2]

S.C. Byte Name S.C. Code Name Bits Current RDCurrent RD+

HGF EDCBA abcdei fghj abcdei fghj

K28.0 C0.0 (C00) 000 00000 001111 0100 110000 1011

K28.1 C1.0 (C01) 000 00001 001111 1001 110000 0110

K28.2 C2.0 (C02) 000 00010 001111 0101 110000 1010

K28.3 C3.0 (C03) 000 00011 001111 0011 110000 1100

K28.4 C4.0 (C04) 000 00100 001111 0010 110000 1101

K28.5 C5.0 (C05) 000 00101 001111 1010 110000 0101

K28.6 C6.0 (C06) 000 00110 001111 0110 110000 1001

K28.7 C7.0 (C07) 000 00111 001111 1000 110000 0111

K23.7 C8.0 (C08) 000 01000 111010 1000 000101 0111

K27.7 C9.0 (C09) 000 01001 110110 1000 001001 0111

K29.7 C10.0 (C0A) 000 01010 101110 1000 010001 0111

K30.7 C11.0 (C0B) 000 01011 011110 1000 100001 0111

Idle C0.1 (C20) 001 00000 K28.5+,D21.4,D21.5,D21.5,repeat[3]

R_RDY C1.1 (C21) 001 00001 K28.5+,D21.4,D10.2,D10.2,repeat[4]

EOFxx C2.1 (C22) 001 00010 K28.5,Dn.xxx0[5]+K28.5,Dn.xxx1[5]

Follows K28.1 for ESCON ConnectSOF (Rx indication only)

CSOF C7.1 (C27) 001 00111 001111 1000 110000 0111

Follows K28.5 for ESCON PassiveSOF (Rx indication only)

PSOF C7.2 (C47) 010 00111 001111 1000 110000 0111

Code Rule Violation and SVS Tx Pattern

Exception C0.7 (CE0) 111 00000 100111 1000[6] 011000 0111[6]

K28.5 C1.7 (CE1) 111 00001 001111 1010[29] 001111 1010[29]

+K28.5 C2.7 (CE2) 111 00010 110000 0101[30] 110000 0101[30]

Running Disparity Violation Pattern

Exception C4.7 (CE4) 111 00100 110111 0101[31] 001000 1010[31]

Notes

1. All codes not shown are reserved.

2. Notation for Special Character Byte Name is consistent with Fibre Channel and ESCON naming conventions. Special Character Code Name is intended to

describe binary information present on I/O pins. Common usage for the name can either be in the form used for describing Data patterns (i.e., C0.0 through

C31.7), or in hex notation (i.e., Cnn where nn = the specified value between 00 and FF).

3. C0.1 = Transmit Negative K28.5 (K28.5+) disregarding Current RD when input is held for only one byte time. If held longer, transmitter begins sending the

repeating transmit sequence K28.5+, D21.4, D21.5, D21.5, (repeat all four bytes)... defined in X3.230 as the primitive signal “Idle word.” This Special Character

input must be held for four (4) byte times or multiples of four bytes or it will be truncated by the new data. The receiver will never output this Special Character,

since K28.5 is decoded as C5.0, C1.7, or C2.7, and the subsequent bytes are decoded as data.

4. C1.1 = Transmit Negative K28.5 (K28.5+) disregarding Current RD when input is held for only one byte time. If held longer, transmitter begins sending the

repeating transmit sequence K28.5+, D21.4, D10.2, D10.2,(repeat all four bytes)... defined in X3.230 as the primitive signal “Receiver_Ready (R_RDY).” This

Special Character input must be held for four (4) byte times or multiples of four bytes or it will be truncated by the new data.

The receiver will never output this Special Character, since K28.5 is decoded as C5.0, C1.7, or C2.7 and the subsequent bytes are decoded as data.

5. C2.1 = Transmit either K28.5+ or +K28.5 as determined by Current RD and modify the Transmission Character that follows, by setting its least significant bit

to 1 or 0. If Current RD at the start of the following character is plus (+) the LSB is set to 0, and if Current RD is minus () the LSB becomes 1. This modification

allows construction of X3.230 “EOF” frame delimiters wherein the second data byte is determined by the Current RD.

For example, to send “EOFdt” the controller could issue the sequence C2.1D21.4 D21.4D21.4, and the HOTLink Transmitter will send either

K28.5D21.4D21.4D21.4 or K28.5D21.5 D21.4D21.4 based on Current RD. Likewise to send “EOFdti” the controller could issue the sequence

C2.1D10.4D21.4D21.4, and the HOTLink Transmitter will send either K28.5D10.4D21.4 D21.4 or K28.5D10.5D21.4 D21.4 based on Current RD.

The receiver will never output this Special Character, since K28.5 is decoded as C5.0, C1.7, or C2.7, and the subsequent bytes are decoded as data.

6. C0.7 = Transmit a deliberate code rule violation. The code chosen for this function follows the normal Running Disparity rules. Transmission of this Special

Character has the same effect as asserting SVS = HIGH.

The receiver will only output this Special Character if the Transmission Character being decoded is not found in the tables.

a CYPRESS ' manna: mlanRRaw V‘LT 'er I‘LT Ambient Commercial 0 “C m +70 “(2 5 V t 10% Indus‘rial 40 DC m +85 "C 5 V :10%

Document Number: 38-02017 Rev. *K Page 30 of 42

CY7B923/CY7B933

Maximum Ratings

Exceeding maximum ratings may impair the useful life of the

device. These user guidelines are not tested.

Storage temperature................................. –65 °C to +150 °C

Ambient temperature with

power applied ........................................... –55 °C to +125 °C

Supply voltage to ground potential .............. –0.5 V to +7.0 V

DC input voltage .......................................... –0.5 V to +7.0 V

Output current into TTL outputs (LOW) ....................... 30 mA

Output current into PECL outputs (HIGH) ................. –50 mA

Static discharge voltage........................................... > 4001 V

(per MIL-STD-883, Method 3015)

Latch up current...................................................... > 200 mA

Operating Range

Range Ambient

Temperature VCC

Commercial 0°C to +70°C 5V  10%

Industrial –40 °C to +85 °C 5V  10%

CY7B923/CY7B933 Electrical Characteristics

Over the Operating Range[7]

Parameter Description Test Condition Min Max Unit

TTL OUTs, CY7B923: RP; CY7B933: Q07, SC/D, RVS, RDY, CKR, SO

VOHT Output HIGH voltage IOH = - 2 mA 2.4 V

VOLT Output LOW voltage IOL = 4 mA 0.45 V

IOST Output short circuit current VOUT = 0V[8] –15 –90 mA

TTL INs, CY7B923: D07, SC/D, SVS, ENA, ENN, CKW, FOTO, BISTEN; CY7B933: RF, REFCLK, BISTEN

VIHT Input HIGH voltage Commercial and industrial 2.0 VCC V

Industrial (CKW and

FOTO, only)

2.2 VCC V

VILT Input LOW voltage –0.5 0.8 V

IIHT Input HIGH current VIN = VCC –10 +10 A

IILT Input LOW current VIN = 0.0V –500 A

Transmitter PECL-Compatible Output Pins: OUTA+, OUTA, OUTB+, OUTB, OUTC+, OUTC

VOHE Output HIGH voltage

(VCC referenced)

Load = 50 to

VCC – 2V

Commercial VCC – 1.03 VCC – 0.83 V

Industrial VCC – 1.05 VCC – 0.83 V

VOLE Output LOW voltage

(VCC referenced)

Load = 50 to

VCC – 2V

Commercial VCC – 1.86 VCC – 1.62 V

Industrial VCC – 1.96 VCC – 1.62 V

VODIF Output differential voltage

|(OUT+)  (OUT)|

Load = 50 to VCC – 2V 0.6 V

Receiver PECL-Compatible Input Pins: A/B, SI, INB

VIHE Input HIGH voltage Commercial VCC – 1.165 VCC V

Industrial VCC – 1.14 VCC V

VILE Input LOW voltage Commercial 2.0 VCC – 1.475 V

Industrial 2.0 VCC – 1.50 V

IIHE[9] Input HIGH current VIN = VIHE Max. +500 A

IILE[9] Input LOW current VIN = VILE Min. +0.5 A

Notes

7. See the last page of this specification for group A subgroup testing information.

8. Tested one output at a time, output shorted for less than one second, less than 10% duty cycle.

9. Applies to A/B only.

‘CYPRESS' ' manna: mmmw l‘HH I‘LL lcc ICCR Parameter Description Test Conditions Max Unit C Inpur capacirance TA : 25 “(2‘ f5 :1 MHz, Vcc : 5,0V 10 pF 7i Vcc , 7Max , one PECL ompm pew \uaded wwlh so uhms \u v 2 UV and omerPECL uulpms ned luvs? Typlca‘ \m .s m pm 9 and pm ”22) Maxwmum‘ , \smeesured wthcc , 75 ov T 523%: Due ompm paw \oaded wllh so ohms IDVC cc , 2 ov mhelshed mv BIS N7 LOW \ Indudes amermmov VCCN \s delerrmned by PECL had cunems, Iypwa‘lyiw mvam SOuhmsm vm 2quam addmona‘ ena any“ PECL paw adds 5 mﬂg’w 11?ch and an addn Led by w ms VCCN as descnbed When ca‘cu‘almg me wnmbulmn oWEcL \uad cunemsmcmp powerdwsswpalmn me ompm bad amen] smu‘d be mu ,m[ [ch ] R— i

Document Number: 38-02017 Rev. *K Page 31 of 42

CY7B923/CY7B933

Differential Line Receiver Input Pins: INA+, INA, INB+, INB

VDIFF Input differential voltage

|(IN+) – (IN)|

50 mV

VIHH Highest input HIGH voltage VCC V

VILL Lowest input LOW voltage 2.0 V

IIHH Input HIGH current VIN = VIHH Max. 750 A

IILL[10] Input LOW current VIN = VILL Min. –200 A

Miscellaneous Typ Max Unit

ICCT[11] Transmitter power supply

current

Freq. = Max. Commercial 65 85 mA

Industrial 75 95 mA

ICCR[12] Receiver power supply

current

Freq. = Max. Commercial 120 155 mA

Industrial 135 160 mA

Capacitance[13]

Parameter Description Test Conditions Max Unit

CIN Input capacitance TA = 25 °C, f0 = 1 MHz, VCC = 5.0V 10 pF

Figure 9. AC Test Loads and Waveforms

Notes

10. Input currents are always positive at all voltages above VCC/2.

11. Maximum ICCT is measured with VCC = Max., one PECL output pair loaded with 50 ohms to VCC  2.0V, and other PECL outputs tied to VCC. Typical ICCT is measured with VCC

= 5.0V, TA = 25C, one output pair loaded with 50 ohms to VCC  2.0V, others tied to VCC, BISTEN = LOW. ICCT includes current into VCCQ (pin 9 and pin 22) only. Current into

VCCN is determined by PECL load currents, typically 30 mA with 50 ohms to VCC  2.0V. Each additional enabled PECL pair adds 5 mA to ICCT and an additional load current to

VCCN as described. When calculating the contribution of PECL load currents to chip power dissipation, the output load current should be multiplied by 1V instead of VCC.

12. Maximum ICCR is measured with VCC = Max., RF = LOW, and outputs unloaded. Typical ICCR is measured with VCC = 5.0V, TA = 25C, RF = LOW, BISTEN = LOW, and outputs

unloaded. ICCR includes current into VCCQ (pins 21 and 24). Current into VCCN (pin 9) is determined by the total TTL output buffer quiescent current plus the sum of all the load

currents for each output pin. The total buffer quiescent current is 10mA max., and max. TTL load current for each output pin can be calculated as follows:

Where RL= equivalent load resistance, CL= capacitive load, and Fpin= frequency in MHz of data on pin. A derating factor of 1.1 has been included to account for

worst process corner and temperature condition.

13. Tested initially and after any design or process changes that may affect these parameters, but not 100% tested.

14. Cypress uses constant current (ATE) load configurations and forcing functions. This figure is for reference only.

CY7B923/CY7B933 Electrical Characteristics

Over the Operating Range[7]

2.0V

1.0V

3.0V

GND

2.0V

1.0V

OUTPUT

(a) TTL AC Test Load (b) PECL AC Test Load

<1ns < 1ns

80%

20%

80%

20%

<1ns < 1ns

CLRL

R1 = 910

R2 = 510 

CL<30pF

(Includes fixture and

probe capacitance)

RL= 50 

CL<5pF

(Includes fixture and

probe capacitance)

VIHE

3.0V

VCC – 2

VIHE

VILE VILE

[14][14]

II CCN

TTLPin = [0.95 + (VCCN

-5) * 0.3

+CL* [

VCCN

2+1.5

] * F

pin] *1.1

CYPRESS ' manna: mlanRRaw RP correct RP \E .s ca‘cu‘a‘ed as «GM Du 7, 505. svs, ME kw and MW (mung \nsures men RP W ‘5 me smndard TTL resib . RP

Document Number: 38-02017 Rev. *K Page 32 of 42

CY7B923/CY7B933

Transmitter Switching Characteristics

Over the Operating Range[7]

Parameter Description 7B923-155 7B923 7B923-400 Unit

Min Max Min Max Min Max

tCKW Write clock cycle 62.5 66.7 30.3 62.5 25 62.5 ns

tBBit time[15] 6.25 6.67 3.03 6.25 2.5 6.25 ns

tCPWH CKW pulse width HIGH 6.5 –6.5 –6.5 –ns

tCPWL CKW pulse width LOW 6.5 –6.5 –6.5 –ns

tSD Data setup time[16] 5–5–5–ns

tHD Data hold time[16] 0–0–0–ns

tSENP Enable setup time (to insure correct RP)[17] 6tB + 8 –6tB + 8 –6tB + 8 –ns

tHENP Enable hold time (to insure correct RP)[17] 0–0–0–ns

tPDR Read pulse rise alignment[18] –4 2–4 2–4 2ns

tPPWH Read pulse HIGH[18] 4tB–3 –4tB–3 –4tB–3 –ns

tPDF Read pulse fall alignment[18] 6tB–3 6tB–3 –6tB–3 –ns

tRISE PECL output rise time 20 to 0% (PECL test load)[13] –1.2 –1.2 –1.2 ns

tFALL PECL output fall time 80to 20% (PECL test load)[13] –1.2 –1.2 –1.2 ns

tDJ Deterministic jitter (peak-peak)[13, 19] –35 –35 –35 ps

tRJ Random jitter (peak-peak)[13, 20] –175 –175 –175 ps

tRJ Random jitter ()[13, 20] –20 –20 –20 ps

Notes

15. Transmitter tB is calculated as tCKW/10. The byte rate is one tenth of the bit rate.

16. Data includes D07, SC/D, SVS, ENA, ENN, and BISTEN. tSD and tHD minimum timing assures correct data load on rising edge of CKW, but not RP function or timing.

17. tSENP and tHENP timing insures correct RP function and correct data load on the rising edge of CKW.

18. Loading on RP is the standard TTL test load shown in part (a) of AC Test Loads and Waveforms except CL = 15 pF.

19. While sending continuous K28.5s, RP unloaded, outputs loaded to 50 to VCC2.0V, over the operating range.

20. While sending continuous K28.7s, after 100,000 samples measured at the cross point of differential outputs, time referenced to CKW input, over the operating range.

‘CYPRESS' ' manna: mlanRRaw ‘CKR E \s m‘cu‘aled is a 7 sen) i 7 how and «H specmcamars amonw vahd NEH cmpuls (CKR‘ Rm, on 7 gen)

Document Number: 38-02017 Rev. *K Page 33 of 42

CY7B923/CY7B933

Receiver Switching Characteristics

Over the Operating Range [7]

Parameter Description 7B933-155 7B933 7B933-400 Unit

Min Max Min Max. Min Max

tCKR Read clock period (no serial data input), REFCLK as

reference[21] –1 +1 –1 +1 –1 +1 %

tBBit time[22] 6.25 6.67 3.03 6.25 2.5 6.25 ns

tCPRH Read clock pulse HIGH 5tB–3 –5tB–3 –5tB–3 –ns

tCPRL Read clock pulse LOW 5tB–3 –5tB–3 –5tB–3 –ns

tRH RDY hold time tB–2.5 – tB–2.5 – tB–2.5 –ns

tPRF RDY pulse fall to CKR rise 5tB–3 –5tB–3 –5tB–3 –ns

tPRH RDY pulse width HIGH 4tB–3 –4tB–3 –4tB–3 –ns

tAData access time[23, 24] 2tB–2 2tB+4 2tB–2 2tB+4 2tB–2 2tB+4 ns

tROH Data hold time[23, 24] tB–2.5 – tB–2.5 – tB–2.5 ns

tHData hold time from CKR rise [23, 24] 2tB–3 –2tB–3 –2tB–3 ns

tCKX REFCLK clock period referenced to CKW of

transmitter[25] –0.1 +0.1 –0.1 +0.1 –0.1 +0.1 %

tCPXH REFCLK clock pulse HIGH 6.5 –6.5 –6.5 –ns

tCPXL REFCLK clock pulse LOW 6.5 –6.5 –6.5 –ns

tDS Propagation delay SI to SO (note PECL and TTL

thresholds)[26] –20 –20 –20 ns

tSA Static alignment[13, 27] –100 –100 –100 ps

tEFW Error-free window[13, 28] 0.9tB–0.9tB–0.9tB– –

Notes

21. The period of tCKR will match the period of the transmitter CKW when the receiver is receiving serial data. When data is interrupted, CKR may drift to one of the range limits above.

22. Receiver tB is calculated as tCKR/10 if no data is being received, or tCKW/10 if data is being received. See note.

23. Data includes Q07, SC/D, and RVS.

24. tA, tROH, and tH specifications are only valid if all outputs (CKR, RDY, Q07, SC/D, and RVS) are loaded with similar DC and AC loads.

25. REFCLK has no phase or frequency relationship with CKR and only acts as a centering reference to reduce clock synchronization time. REFCLK must be within 0.1%

of the transmitter CKW frequency, necessitating a 500-PPM crystal.

nnnnnnnnnnnnnnnnnn TD 77 IQ10{93310101919101.1933{91016101910101(910

Document Number: 38-02017 Rev. *K Page 34 of 42

CY7B923/CY7B933

Switching Waveforms

Figure 10. Switching Waveforms for the CY7B923 HOTLink Transmitter

Notes

26. The PECL switching threshold is the midpoint between the PECL VOH, and VOL specification (approximately VCC  1.35V). The TTL switching threshold is 1.5V.

27. Static alignment is a measure of the alignment of the Receiver sampling point to the center of a bit. Static alignment is measured by sliding one bit edge in 3,000

nominal transitions until a byte error occurs.

28. Error Free Window is a measure of the time window between bit centers where a transition may occur without causing a bit sampling error. EFW is measured

over the operating range, input jitter 50% Dj.

CKW

ENA

D0–D7,

SC/D,

SVS,

BISTEN

tSD

tCPWL

tHD

tPDR

VALID DATA

tCPWH

tCKW

tSENP

tSD tHENP

tPDF DISABLED

ENABLED

tPPWH

NOTES 16,17

CKW

tCPWL

tCPWH

tCKW

ENN

D0–D7,

SC/D,

SVS,

BISTEN

tSD tHD

VALID DATA

tSD tHD

nnnnnnnnnnnnnnnnnn

Document Number: 38-02017 Rev. *K Page 35 of 42

CY7B923/CY7B933

Figure 11. Switching W0aveforms for the CY7B933 HOTLink Receiver

Switching Waveforms (continued)

CKR

RDY

Q0–Q7,

SC/D,RVS,

tCPRL

tCPRH

tCKR

tPRH

tPRF

tRH

tAtROH

REFCLK

tCPXL tCPXH

tCKX

VBB

tDS

1.5V

NOTE

INA ,

INB

tB/2 tSA

Static Alignment

SAMPLE WINDOW

INA

INB

tEFW

BIT CENTER BIT CENTER

Error-free Window

nnnnnnnnnnnnnnnnnn ’__\ X II \ I \ XXXXXX XXX (XXX XXX XXX X

Document Number: 38-02017 Rev. *K Page 36 of 42

CY7B923/CY7B933

Figure 12. CY7B923 Transmitter Data Pipeline

CKW

ENA

D07,

SC/D,

SVS

K28.5 K28.5

DATA LATCHED IN

DATA SENT

DATA

OUTX

TRANSMITTER LATENCY = 21 tB10 ns

DATA

Document Number: 38-02017 Rev. *K Page 37 of 42

CY7B923/CY7B933

Ordering Code Definitions

Ordering Information

Speed Ordering Code Package

Name Package Type Operating

Range

Standard CY7B923-JXC J64 28-pin PLCC (Pb-free) Commercial

CY7B923-JXCT J64 28-pin PLCC (Pb-free)

CY7B923-JXI J64 28-pin PLCC (Pb-free) Industrial

CY7B923-JXIT J64 28-pin PLCC (Pb-free)

CY7B923-SXC S21 28-pin SOIC (Pb-free) Commercial

CY7B923-SXCT S21 28-pin SOIC (Pb-free)

400 CY7B923-400JXC J64 28-pin PLCC (Pb-free) Commercial

CY7B923-400JXCT J64 28-pin PLCC (Pb-free)

Standard CY7B933-JXC J64 28-pin PLCC (Pb-free) Commercial

CY7B933-JXCT J64 28-pin PLCC (Pb-free)

CY7B933-JXI J64 28-pin PLCC (Pb-free) Industrial

CY7B933-JXIT J64 28-pin PLCC (Pb-free)

CY7B933-SXC S21 28-pin SOIC (Pb-free) Commercial

CY7B933-SXCT S21 28-pin SOIC (Pb-free)

400 CY7B933-400JXC J64 28-pin PLCC (Pb-free) Commercial

CY7B933-400JXCT J64 28-pin PLCC (Pb-free)

Marketing Code: 7B = HOTLink

Transmitter/Receiver

7B XXX

Company ID: CY = Cypress

Package type:

J = PLCC, JX = PLCC (Pb-Free), SX = SOIC (Pb-Free)

XX T

Tape and reel

Base part number:

923 = Transmitter, 933 = Receiver

C/I

Temperature range:

C = Commercial, I = Industrial

Notes

29. C1.7 = Transmit Negative K28.5 (–K28.5+) disregarding Current RD.

The receiver will only output this Special Character if K28.5 is received with the wrong running disparity. The receiver will output C1.7 if K28.5 is received with RD+,

otherwise K28.5 is decoded as C5.0 or C2.7.

30. C2.7 = Transmit Positive K28.5 (+K28.5–) disregarding Current RD.

The receiver will only output this Special Character if K28.5 is received with the wrong running disparity. The receiver will output C2.7 if +K28.5 is received with RD,

otherwise K28.5 is decoded as C5.0 or C1.7.

31. C4.7 = Transmit a deliberate code rule violation to indicate a Running Disparity violation.

The receiver will only output this Special Character if the Transmission Character being decoded is found in the tables, but Running Disparity does not match. This

might indicate that an error occurred in a prior byte.

‘CYPRESS' ' EMIEuummlnNannaw SEATING PLANE pm on [17 1 as 5 E j 25 l E , 7 uosu E Er y w “55 E 1 arms so “‘95 DDSS an E 1 E ] 11E 1 19 l_l L1 L1 L1 l_l l_l Ll 1a m 0450 ms mu ¥mas #‘ man DIMENSIEINS 1N INCHES MIN MAX

Document Number: 38-02017 Rev. *K Page 38 of 42

CY7B923/CY7B933

Package Diagrams

Figure 13. 28-Pin Plastic Leaded Chip Carrier J64

51-85001 *D

‘CYPRESS' ' EMuEnniu mlnnankow NOTE u JEDEE sr: REF MDrHQ 2, saw LEmrH DMENS‘ON DOES NOT wcLuoE mum FFOT‘ZUS‘ON/END “swam DUES \NCLLDE MOLD wsMAmH AND ARE MEASLRED Ar THE Mam PM’HNG UNE MOLD PNmRuSmN/END mm >HALL PW 1 ID NOT EXCEED am m (H.254 mn) PER 5qu 3 DMEAS‘UNS w \NCHES MN m j o 291 7 39 030017.621 a 39.: w m U MENU 5"] 4‘ y o 026 o as 525 3 STANDARD PKG n awn an szza 3 LEAD EREE PKG sxza 3 LEAD FREE PKG E14 ‘E a 00910 23 J L mm mm SEATWG PLANE 0713mm; ‘ 0.597 17.7w 0 n92 2 33 X a man an @— 4‘,

Document Number: 38-02017 Rev. *K Page 39 of 42

CY7B923/CY7B933

Figure 14. 28-Pin (300-Mil) Molded SOIC S21

Package Diagrams (continued)

51-85026 *H

nnnnnnnnnnnnnnnnnn

Document Number: 38-02017 Rev. *K Page 40 of 42

CY7B923/CY7B933

Acronyms Document Conventions

Units of Measure

Table 5. Acronyms Used in this Document

Acronym Description

AC alternating current

BIST built-in self-test

CDR clock/data recovery

CML current mode logic

DC direct current

DVB digital video broadcasting

ECL emitter coupled logic

I/O input/output

JTAG joint test action group

LFI link fault indicator

LFSR linear feedback shift register

LPEN local loopback input

PECL positive-ECL

PLL phase-locked loop

TTL transistor-transistor logic

VCO voltage controlled oscillator

Table 1-1:

Symbol Unit of Measure

°C degrees Celsius

MHz megahertz

µA microampere

µs microsecond

Mbps megabits per second

mA milliampere

mm millimeter

ms millisecond

mV millivolt

nA nano ampere

ns nanosecond

nV nano volt

ohm

pF picofarad

pp peak-to-peak

ps picosecond

sps samples per second

Vvolt

A biCYPRESS' ENuEnnEn mlanRRaw w

Document Number: 38-02017 Rev. *K Page 41 of 42

CY7B923/CY7B933

Document History Page

Document Title: CY7B923/CY7B933, HOTLink Transmitter/Receiver

Document Number: 38-02017

Revision ECN Orig. of

Change

Submission

Date Description of Change

** 105855 SZV 03/28/01 Changed from Spec number: 38-00189 to 38-02017

*A 112164 REV 03/25/02 Changed OUTA± pin description to improve consistency with diagram.

Changed INA± pin description to include what to do with unused pairs of inputs.

Changed Equation in note 6–old one made no sense.

*B 114562 BSS 03/27/02 Changed Hotlink Transmitter/Receiver to HotlinkTransmitter/Receiver.

*C 125525 OOR 04/01/03 Removed all references to Military parts (Obsolete): CY7B923-LMB,

CY7B933-LMB

*D 132104 KKV 12/22/03 Minor change: reset Valid Data Characters (SC/D = LOW) table format to

single-column pages

*E 393422 PCX See ECN Added Pb-Free Logo

Added Pb-Free parts to Ordering Information:

CY7B923-400JXC, CY7B923-JXC, CY7B923-JXI, CY7B923-SXC,

CY7B933-400JXC, CY7B933-JXC, CY7B933-JXI, CY7B933-SXC,

CY7B933-SXI

*F 2896112 CGX 03/19/10 Removed obsolete parts in ordering information table

Updated package diagrams

*G 3028517 FRE 09/13/2010 Removed references to obsolete low-speed and military parts.

Added ordering code definition.

Updated 28-pin PLCC package diagram.

Updated to new template.

*H 3059305 SAAC 10/14/2010 Reviewed Content - No change

*I 3400761 SAAC 10/10/2011 Removed reference to LCC from Features section on page 1.

Removed following obsolete parts:

CY7B923-JC

CY7B933-JC

Updated package diagrams.

*J 4571788 YLIU 11/17/2014 Updated Package Diagrams:

spec 51-85026 – Changed revision from *F to *H.

Updated to new template.

Completing Sunset Review.

*K 5959791 YLIU 11/07/2017 Updated package diagram (51-85001)

nnnnnnnnnnnnnnnnnnn

Document Number: 38-02017 Rev. *K Revised November 7, 2017 Page 42 of 42

including any software or firmware included or referenced in this document ("Software"), is owned by Cypress under the intellectual property laws and treaties of the United States and other countries

worldwide. Cypress reserves all rights under such laws and treaties and does not, except as specifically stated in this paragraph, grant any license under its patents, copyrights, trademarks, or other

intellectual property rights. If the Software is not accompanied by a license agreement and you do not otherwise have a written agreement with Cypress governing the use of the Software, then Cypress

hereby grants you a personal, non-exclusive, nontransferable license (without the right to sublicense) (1) under its copyright rights in the Software (a) for Software provided in source code form, to

modify and reproduce the Software solely for use with Cypress hardware products, only internally within your organization, and (b) to distribute the Software in binary code form externally to end users

(either directly or indirectly through resellers and distributors), solely for use on Cypress hardware product units, and (2) under those claims of Cypress's patents that are infringed by the Software (as

provided by Cypress, unmodified) to make, use, distribute, and import the Software solely for use with Cypress hardware products. Any other use, reproduction, modification, translation, or compilation

of the Software is prohibited.

TO THE EXTENT PERMITTED BY APPLICABLE LAW, CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THIS DOCUMENT OR ANY SOFTWARE

OR ACCOMPANYING HARDWARE, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. To the extent

permitted by applicable law, Cypress reserves the right to make changes to this document without further notice. Cypress does not assume any liability arising out of the application or use of any

product or circuit described in this document. Any information provided in this document, including any sample design information or programming code, is provided only for reference purposes. It is

the responsibility of the user of this document to properly design, program, and test the functionality and safety of any application made of this information and any resulting product. Cypress products

are not designed, intended, or authorized for use as critical components in systems designed or intended for the operation of weapons, weapons systems, nuclear installations, life-support devices or

systems, other medical devices or systems (including resuscitation equipment and surgical implants), pollution control or hazardous substances management, or other uses where the failure of the

device or system could cause personal injury, death, or property damage ("Unintended Uses"). A critical component is any component of a device or system whose failure to perform can be reasonably

expected to cause the failure of the device or system, or to affect its safety or effectiveness. Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim,

damage, or other liability arising from or related to all Unintended Uses of Cypress products. You shall indemnify and hold Cypress harmless from and against all claims, costs, damages, and other

liabilities, including claims for personal injury or death, arising from or related to any Unintended Uses of Cypress products.

Cypress, the Cypress logo, Spansion, the Spansion logo, and combinations thereof, WICED, PSoC, CapSense, EZ-USB, F-RAM, and Traveo are trademarks or registered trademarks of Cypress in

the United States and other countries. For a more complete list of Cypress trademarks, visit cypress.com. Other names and brands may be claimed as property of their respective owners.

CY7B923/CY7B933

Sales, Solutions, and Legal Information

Worldwide Sales and Design Support

Cypress maintains a worldwide network of offices, solution centers, manufacturer’s representatives, and distributors. To find the office

closest to you, visit us at Cypress Locations.

Products

ARM® Cortex® Microcontrollers cypress.com/arm

Automotive cypress.com/automotive

Clocks & Buffers cypress.com/clocks

Interface cypress.com/interface

Internet of Things cypress.com/iot

Memory cypress.com/memory

Microcontrollers cypress.com/mcu

PSoC cypress.com/psoc

Power Management ICs cypress.com/pmic

Touch Sensing cypress.com/touch

USB Controllers cypress.com/usb

Wireless Connectivity cypress.com/wireless

PSoC® Solutions

PSoC 1 | PSoC 3 | PSoC 4 | PSoC 5LP

Cypress Developer Community

Training | Components

Technical Support

cypress.com/support

Fiche technique pour CY7B923/33 de Infineon Technologies

INFORMATIONS

AIDE

NOUS CONTACTER

NOUS SUIVRE
