CDx4HC11 Triple 3-Input AND Gates

1 Features

• Buffered inputs

• Wide operating voltage range: 2 V to 6 V

• Wide operating temperature range:

–55°C to +125°C

• Supports fanout up to 10 LSTTL loads

• Significant power reduction compared to LSTTL

logic ICs

2 Applications

•Combining power good signals

•Enable digital signals

3 Description

This device contains three independent 3-input AND

gates. Each gate performs the Boolean function

Y = A ● B ● C in positive logic.

Device Information(1)

PART NUMBER PACKAGE BODY SIZE (NOM)

CD74HC11M SOIC (14) 8.70 mm × 3.90 mm

CD74HC11E PDIP (14) 19.30 mm × 6.40 mm

CD54HC11F CDIP (14) 21.30 mm × 7.60 mm

(1) For all available packages, see the orderable addendum at

the end of the data sheet.

GND

VCC

Functional pinout

www.ti.com

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021

Product Folder Links: CD74HC11 CD54HC11

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

I TEXAS INSTRUMENTS

Table of Contents

1 Features............................................................................1

2 Applications..................................................................... 1

3 Description.......................................................................1

4 Revision History.............................................................. 2

5 Specifications.................................................................. 4

5.1 Absolute Maximum Ratings........................................ 4

5.2 ESD Ratings............................................................... 4

5.3 Recommended Operating Conditions.........................4

5.4 Thermal Information....................................................5

5.5 Electrical Characteristics.............................................5

5.6 Switching Characteristics............................................5

5.7 Operating Characteristics........................................... 6

5.8 Typical Characteristics................................................ 6

6 Parameter Measurement Information............................ 7

7 Detailed Description........................................................8

7.1 Overview..................................................................... 8

7.2 Functional Block Diagram........................................... 8

7.3 Feature Description.....................................................8

7.4 Device Functional Modes............................................9

8 Application and Implementation.................................. 10

8.1 Application Information............................................. 10

8.2 Typical Application.................................................... 10

9 Layout.............................................................................12

9.1 Layout Guidelines..................................................... 12

9.2 Layout Example........................................................ 12

10 Device and Documentation Support..........................13

10.1 Documentation Support.......................................... 13

10.2 Receiving Notification of Documentation Updates..13

10.3 Support Resources................................................. 13

10.4 Trademarks.............................................................13

10.5 Electrostatic Discharge Caution..............................13

10.6 Related Links.......................................................... 13

10.7 Community Resources............................................13

10.8 Glossary..................................................................13

4 Revision History

NOTE: Page numbers for previous revisions may differ from page numbers in the current version.

Changes from Revision E (September 2003) to Revision F (April 2021) Page

• Updated the numbering format for tables, figures, and cross-references throughout the document..................1

• Updated to new data sheet standards................................................................................................................ 1

• Moved the HCT devices to a standalone data sheet (SCHS405) ......................................................................1

• RθJA increased for the D package (86 to 133.6 ℃/W) and decreased for the N package (80 to 65.2 ℃/W)......5

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021 www.ti.com

Product Folder Links: CD74HC11 CD54HC11

b TEXAS INSTRUMENTS 3:3; iii:

GND

VCC

Figure 5-1. D, N, or J Package

14-Pin SOIC, PDIP, or CDIP

Top View

Pin Functions

PIN I/O DESCRIPTION

NAME NO.

1A 1 Input Channel 1, Input A

1B 2 Input Channel 1, Input B

2A 3 Input Channel 2, Input A

2B 4 Input Channel 2, Input B

2C 5 Input Channel 2, Input C

2Y 6 Output Channel 2, Output Y

GND 7 — Ground

3Y 8 Output Channel 3, Output Y

3A 9 Input Channel 3, Input A

3B 10 Input Channel 3, Input B

3C 11 Input Channel 3, Input C

1Y 12 Output Channel 1, Output Y

1C 13 Input Channel 1, Input C

VCC 14 — Positive Supply

www.ti.com

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021

Product Folder Links: CD74HC11 CD54HC11

TEXAS INSTRUMENTS

5 Specifications

5.1 Absolute Maximum Ratings

over operating free-air temperature range (unless otherwise noted)(1)

MIN MAX UNIT

VCC Supply voltage –0.5 7 V

IIK Input clamp current(2) VI < –0.5 V or VI > VCC +

0.5 V ±20 mA

IOK Output clamp current(2) VO < –0.5 V or VO > VCC +

0.5 V ±20 mA

IOContinuous output current VO > –0.5 V or VO < VCC +

0.5 V ±25 mA

Continuous current through VCC or GND ±50 mA

TJJunction temperature(3) Plastic package 150 °C

Hermetic package or die 175

Lead temperature (soldering 10s) SOIC - lead tips only 300 °C

Tstg Storage temperature –65 150 °C

(1) Stresses beyond those listed under Absolute Maximum Rating may cause permanent damage to the device. These are stress

ratings only, which do not imply functional operation of the device at these or any other conditions beyond those indicated

under Recommended Operating Condition. Exposure to absolute-maximum-rated conditions for extended periods may affect device

reliability.

(2) The input and output voltage ratings may be exceeded if the input and output current ratings are observed.

(3) Guaranteed by design.

5.2 ESD Ratings

VALUE UNIT

V(ESD) Electrostatic discharge

Human-body model (HBM), per ANSI/ESDA/

JEDEC JS-001(1) ±2000

Charged-device model (CDM), per JEDEC

specification JESD22-C101(2) ±750

(1) JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.

(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.

5.3 Recommended Operating Conditions

over operating free-air temperature range (unless otherwise noted)

MIN NOM MAX UNIT

VCC Supply voltage 2 5 6 V

VIH High-level input voltage

VCC = 2 V 1.5

VVCC = 4.5 V 3.15

VCC = 6 V 4.2

VIL Low-level input voltage

VCC = 2 V 0.5

VCC = 4.5 V 1.35

VCC = 6 V 1.8

VIInput voltage 0 VCC V

VOOutput voltage 0 VCC V

ttInput transition time

VCC = 2 V 1000

nsVCC = 4.5 V 500

VCC = 6 V 400

TAOperating free-air temperature –55 125 °C

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021 www.ti.com

Product Folder Links: CD74HC11 CD54HC11

TEXAS INSTRUMENTS

5.4 Thermal Information

THERMAL METRIC(1)

CD74HC11

UNITN (PDIP) D (SOIC)

14 PINS 14 PINS

RθJA Junction-to-ambient thermal resistance 65.2 133.6 °C/W

RθJC(top) Junction-to-case (top) thermal resistance 52.9 89.0 °C/W

RθJB Junction-to-board thermal resistance 44.9 89.5 °C/W

ΨJT Junction-to-top characterization parameter 32.5 45.5 °C/W

ΨJB Junction-to-board characterization parameter 44.7 89.1 °C/W

RθJC(bot) Junction-to-case (bottom) thermal resistance N/A N/A °C/W

(1) For more information about traditional and new thermal metrics, see the Semiconductor and IC Package Thermal Metrics application

report.

5.5 Electrical Characteristics

over operating free-air temperature range; typical values measured at TA = 25°C (unless otherwise noted).

PARAMETER TEST CONDITIONS VCC

Operating free-air temperature (TA)

UNIT25°C –40°C to 85°C –55°C to 125°C

MIN TYP MAX MIN TYP MAX MIN TYP MAX

VOH

High-level

output voltage

VI = VIH or

VIL

IOH = –20

µA

2 V 1.9 1.9 1.9

4.5 V 4.4 4.4 4.4

6 V 5.9 5.9 5.9

IOH = –4

mA 4.5 V 3.98 3.84 3.7

IOH = –5.2

mA 6 V 5.48 5.34 5.2

VOL

Low-level output

voltage

VI = VIH or

VIL

IOL = 20

µA

2 V 0.1 0.1 0.1

4.5 V 0.1 0.1 0.1

6 V 0.1 0.1 0.1

IOL = 4 mA 4.5 V 0.26 0.33 0.4

IOL = 5.2

mA 6 V 0.26 0.33 0.4

Input leakage

current VI = VCC or GND 6 V ±0.1 ±1 ±1 µA

ICC Supply current VI = VCC or

GND IO = 0 6 V 2 20 40 µA

Input

capacitance 5 V 10 10 10 pF

5.6 Switching Characteristics

over operating free-air temperature range; typical values measured at TA = 25°C (unless otherwise noted).

PARAMETER FROM TO

TEST

CONDITIO

VCC

Operating free-air temperature (TA)

UNIT25°C –40°C to 85°C –55°C to 125°C

MIN TYP MAX MIN TYP MAX MIN TYP MAX

tpd Propagation delay

A, B, or

CY CL = 50 pF

2 V 100 125 150

4.5 V 20 25 30

6 V 17 21 26

A, B, or

CY CL = 15 pF 5 V 8

www.ti.com

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021

Product Folder Links: CD74HC11 CD54HC11

TEXAS INSTRUMENTS

over operating free-air temperature range; typical values measured at TA = 25°C (unless otherwise noted).

PARAMETER FROM TO

TEST

CONDITIO

VCC

Operating free-air temperature (TA)

UNIT25°C –40°C to 85°C –55°C to 125°C

MIN TYP MAX MIN TYP MAX MIN TYP MAX

ttTransition-time Y CL = 50 pF

2 V 75 95 110

ns4.5 V 15 19 22

6 V 13 16 19

5.7 Operating Characteristics

over operating free-air temperature range; typical values measured at TA = 25°C (unless otherwise noted).

PARAMETER TEST CONDITIONS VCC MIN TYP MAX UNIT

Cpd

Power dissipation capacitance

per gate No load 2 V to 6 V 26 pF

5.8 Typical Characteristics

TA = 25°C

IOH Output High Current (mA)

VOH Output High Voltage (V)

0 1 2 3 4 5 6

2-V

4.5-V

6-V

Figure 5-1. Typical output voltage in the high state

(VOH)

IOL Output Low Current (mA)

VOL Output Low Voltage (V)

0 1 2 3 4 5 6

0.05

0.1

0.15

0.2

0.25

0.3

2-V

4.5-V

6-V

Figure 5-2. Typical output voltage in the low state

(VOL)

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021 www.ti.com

Product Folder Links: CD74HC11 CD54HC11

I TEXAS INSTRUMENTS Tesl 1H 0 \ V” ‘ \ ‘ F H—DF on

6 Parameter Measurement Information

• Phase relationships between waveforms were chosen arbitrarily. All input pulses are supplied by generators

having the following characteristics: PRR ≤ 1 MHz, ZO = 50 Ω, tt < 6 ns.

• The outputs are measured one at a time, with one input transition per measurement.

CL(1)

From Output

Under Test

Test

Point

A. CL= 50 pF and includes probe and jig capacitance.

Figure 6-1. Load Circuit

VOH

VOL

Output

VCC

0 V

Input

tf(1)

tr(1)

90%

10%

90%

10%

tr(1)

90%

10%

tf(1)

90%

10%

A. tt is the greater of tr and tf.

Figure 6-2. Voltage Waveforms Transition Times

50%Input 50%

VCC

0 V

50% 50%

VOH

VOL

tPLH(1) tPHL(1)

VOH

VOL

tPHL(1) tPLH(1)

Output

Output 50% 50%

A. The maximum between tPLH and tPHL is used for tpd.

Figure 6-3. Voltage Waveforms Propagation Delays

www.ti.com

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021

Product Folder Links: CD74HC11 CD54HC11

TEXAS INSTRUMENTS

7 Detailed Description

7.1 Overview

This device contains three independent 3-input AND gates. Each gate performs the Boolean function Y = A ● B

● C in positive logic.

7.2 Functional Block Diagram

xYxB

7.3 Feature Description

7.3.1 Balanced CMOS Push-Pull Outputs

A balanced output allows the device to sink and source similar currents. The drive capability of this device

may create fast edges into light loads so routing and load conditions should be considered to prevent ringing.

Additionally, the outputs of this device are capable of driving larger currents than the device can sustain without

being damaged. It is important for the output power of the device to be limited to avoid damage due to

over-current. The electrical and thermal limits defined in the Absolute Maximum Ratings must be followed at all

times.

The CD74HC11 can drive a load with a total capacitance less than or equal to the maximum load listed in the

Switching Characteristics connected to a high-impedance CMOS input while still meeting all of the datasheet

specifications. Larger capacitive loads can be applied, however it is not recommended to exceed the provided

load value. If larger capacitive loads are required, it is recommended to add a series resistor between the output

and the capacitor to limit output current to the values given in the Absolute Maximum Ratings.

7.3.2 Standard CMOS Inputs

Standard CMOS inputs are high impedance and are typically modeled as a resistor from the input to ground in

parallel with the input capacitance given in the Electrical Characteristics. The worst case resistance is calculated

with the maximum input voltage, given in the Absolute Maximum Ratings, and the maximum input leakage

current, given in the Electrical Characteristics, using ohm's law (R = V ÷ I).

Signals applied to the inputs need to have fast edge rates, as defined by the input transition time in the

Recommended Operating Conditions to avoid excessive current consumption and oscillations. If a slow or noisy

input signal is required, a device with a Schmitt-trigger input should be used to condition the input signal prior to

the standard CMOS input.

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021 www.ti.com

Product Folder Links: CD74HC11 CD54HC11

{5‘ TEXAS INSTRUMENTS

7.3.3 Clamp Diode Structure

The inputs and outputs to this device have both positive and negative clamping diodes as depicted in Figure 7-1.

CAUTION

Voltages beyond the values specified in the Absolute Maximum Ratings table can cause damage to

the device. The recommended input and output voltage ratings may be exceeded if the input and

output clamp-current ratings are observed.

GND

Logic

Input Output

VCC

Device

-IIK

+IIK +IOK

-IOK

Figure 7-1. Electrical Placement of Clamping Diodes for Each Input and Output

7.4 Device Functional Modes

Table 7-1. Function Table

INPUTS OUTPUT

A B C Y

H H H H

L X X L

X L X L

X X L L

www.ti.com

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021

Product Folder Links: CD74HC11 CD54HC11

I TEXAS INSTRUMENTS

8 Application and Implementation

Note

Information in the following applications sections is not part of the TI component specification,

and TI does not warrant its accuracy or completeness. TI’s customers are responsible for

determining suitability of components for their purposes, as well as validating and testing their design

implementation to confirm system functionality.

8.1 Application Information

In this application, this device is used to directly control the RESET pin of a motor controller. The controller

requires three input signals to all be HIGH before being enabled, and should be disabled in the event that any

one signal goes LOW. The 3-input AND gate function combines the three individual reset signals into a single

active-low reset signal.

8.2 Typical Application

ON/OFF RESET

Power Supply

Motor Controller

On/Off Switch

Over

Current

Detection

Figure 8-1. Typical application schematic

8.2.1 Design Requirements

8.2.1.1 Power Considerations

Ensure the desired supply voltage is within the range specified in the Recommended Operating Conditions. The

supply voltage sets the device's electrical characteristics as described in the Electrical Characteristics.

The supply must be capable of sourcing current equal to the total current to be sourced by all outputs of the

CD74HC11 plus the maximum supply current, ICC, listed in the Electrical Characteristics. The logic device can

only source or sink as much current as it is provided at the supply and ground pins, respectively. Be sure not to

exceed the maximum total current through GND or VCC listed in the Absolute Maximum Ratings.

Total power consumption can be calculated using the information provided in CMOS Power Consumption and

Cpd Calculation.

Thermal increase can be calculated using the information provided in Thermal Characteristics of Standard Linear

and Logic (SLL) Packages and Devices.

CAUTION

The maximum junction temperature, TJ(max) listed in the Absolute Maximum Ratings, is an

additional limitation to prevent damage to the device. Do not violate any values listed in the Absolute

Maximum Ratings. These limits are provided to prevent damage to the device.

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021 www.ti.com

Product Folder Links: CD74HC11 CD54HC11

{5‘ TEXAS INSTRUMENTS

8.2.1.2 Input Considerations

Unused inputs must be terminated to either VCC or ground. These can be directly terminated if the input is

completely unused, or they can be connected with a pull-up or pull-down resistor if the input is to be used

sometimes, but not always. A pull-up resistor is used for a default state of HIGH, and a pull-down resistor is used

for a default state of LOW. The resistor size is limited by drive current of the controller, leakage current into the

CD74HC11, as specified in the Electrical Characteristics, and the desired input transition rate. A 10-kΩ resistor

value is often used due to these factors.

The CD74HC11 has standard CMOS inputs, so input signal edge rates cannot be slow. Slow input edge

rates can cause oscillations and damaging shoot-through current. The recommended rates are defined in the

Recommended Operating Conditions.

Refer to Section 7.3 for additional information regarding the inputs for this device.

8.2.1.3 Output Considerations

The positive supply voltage is used to produce the output HIGH voltage. Drawing current from the output will

decrease the output voltage as specified by the VOH specification in the Electrical Characteristics. Similarly, the

ground voltage is used to produce the output LOW voltage. Sinking current into the output will increase the

output voltage as specified by the VOL specification in the Electrical Characteristics.

Unused outputs can be left floating. Do not connect outputs directly to VCC or ground.

Refer to Section 7.3 for additional information regarding the outputs for this device.

8.2.2 Detailed Design Procedure

1. Add a decoupling capacitor from VCC to GND. The capacitor needs to be placed physically close to the

device and electrically close to both the VCC and GND pins. An example layout is shown in Section 9.

2. Ensure the capacitive load at the output is ≤ 70 pF. This is not a hard limit, however it will ensure optimal

performance. This can be accomplished by providing short, appropriately sized traces from the CD74HC11

to the receiving device.

3. Ensure the resistive load at the output is larger than (VCC / IO(max)) Ω. This will ensure that the maximum

output current from the Absolute Maximum Ratings is not violated. Most CMOS inputs have a resistive load

measured in megaohms; much larger than the minimum calculated above.

4. Thermal issues are rarely a concern for logic gates, however the power consumption and thermal increase

can be calculated using the steps provided in the application report, CMOS Power Consumption and Cpd

Calculation

8.2.3 Application Curves

OFF

Reset

Figure 8-2. Typical application timing diagram

www.ti.com

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021

Product Folder Links: CD74HC11 CD54HC11

I TEXAS INSTRUMENTS

Power Supply Recommendations

The power supply can be any voltage between the minimum and maximum supply voltage rating located in

the Recommended Operating Conditions. Each VCC terminal should have a bypass capacitor to prevent power

disturbance. A 0.1-μF capacitor is recommended for this device. It is acceptable to parallel multiple bypass caps

to reject different frequencies of noise. The 0.1-μF and 1-μF capacitors are commonly used in parallel. The

bypass capacitor should be installed as close to the power terminal as possible for best results, as shown in

Figure 9-1.

9 Layout

9.1 Layout Guidelines

When using multiple-input and multiple-channel logic devices inputs must not ever be left floating. In many

cases, functions or parts of functions of digital logic devices are unused; for example, when only two inputs of

a triple-input AND gate are used. Such unused input pins must not be left unconnected because the undefined

voltages at the outside connections result in undefined operational states. All unused inputs of digital logic

devices must be connected to a logic high or logic low voltage, as defined by the input voltage specifications, to

prevent them from floating. The logic level that must be applied to any particular unused input depends on the

function of the device. Generally, the inputs are tied to GND or VCC, whichever makes more sense for the logic

function or is more convenient.

9.2 Layout Example

GND VCC

GND

VCC

0.1 F

Unused

inputs tied to

GND

Bypass capacitor

placed close to the

device

Avoid 90°

corners for

signal lines

Recommend GND flood fill for

improved signal isolation, noise

reduction, and thermal dissipation

Unused

output left

floating

Unused input

tied to VCC

Figure 9-1. Example layout for the CD74HC11

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021 www.ti.com

Product Folder Links: CD74HC11 CD54HC11

l TEXAS INSTRUMENTS

10 Device and Documentation Support

10.1 Documentation Support

10.1.1 Related Documentation

For related documentation see the following:

•HCMOS Design Considerations

•CMOS Power Consumption and CPD Calculation

•Designing with Logic

10.2 Receiving Notification of Documentation Updates

To receive notification of documentation updates, navigate to the device product folder on ti.com. Click on

Subscribe to updates to register and receive a weekly digest of any product information that has changed. For

change details, review the revision history included in any revised document.

10.3 Support Resources

TI E2E™ support forums are an engineer's go-to source for fast, verified answers and design help — straight

from the experts. Search existing answers or ask your own question to get the quick design help you need.

Linked content is provided "AS IS" by the respective contributors. They do not constitute TI specifications and do

not necessarily reflect TI's views; see TI's Terms of Use.

10.4 Trademarks

TI E2E™ is a trademark of Texas Instruments.

All trademarks are the property of their respective owners.

10.5 Electrostatic Discharge Caution

This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled

with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.

ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may

be more susceptible to damage because very small parametric changes could cause the device not to meet its published

specifications.

10.6 Related Links

The table below lists quick access links. Categories include technical documents, support and community

resources, tools and software, and quick access to sample or buy.

10.7 Community Resources

10.8 Glossary

TI Glossary This glossary lists and explains terms, acronyms, and definitions.

Mechanical, Packaging, and Orderable Information

The following pages include mechanical, packaging, and orderable information. This information is the most

current data available for the designated devices. This data is subject to change without notice and revision of

this document. For browser-based versions of this data sheet, refer to the left-hand navigation.

www.ti.com

CD74HC11, CD54HC11

SCHS273F – AUGUST 1997 – REVISED APRIL 2021

Product Folder Links: CD74HC11 CD54HC11

I TEXAS INSTRUMENTS

PACKAGE OPTION ADDENDUM

www.ti.com 13-Jul-2022

PACKAGING INFORMATION

Orderable Device Status

(1)

Package Type Package

Drawing Pins Package

Qty Eco Plan

(2)

Lead finish/

Ball material

(6)

MSL Peak Temp

(3)

Op Temp (°C) Device Marking

(4/5)

Samples

CD54HC11F ACTIVE CDIP J 14 1 Non-RoHS

& Green SNPB N / A for Pkg Type -55 to 125 CD54HC11F Samples

CD54HC11F3A ACTIVE CDIP J 14 1 Non-RoHS

& Green SNPB N / A for Pkg Type -55 to 125 8404801CA

CD54HC11F3A Samples

CD74HC11E ACTIVE PDIP N 14 25 RoHS & Green NIPDAU N / A for Pkg Type -55 to 125 CD74HC11E Samples

CD74HC11EE4 ACTIVE PDIP N 14 25 TBD Call TI Call TI -55 to 125 Samples

CD74HC11M ACTIVE SOIC D 14 50 RoHS & Green NIPDAU Level-1-260C-UNLIM -55 to 125 HC11M Samples

CD74HC11M96 ACTIVE SOIC D 14 2500 RoHS & Green NIPDAU | SN Level-1-260C-UNLIM -55 to 125 HC11M Samples

CD74HC11MT ACTIVE SOIC D 14 250 RoHS & Green NIPDAU Level-1-260C-UNLIM -55 to 125 HC11M Samples

(1) The marketing status values are defined as follows:

ACTIVE: Product device recommended for new designs.

LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.

NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design.

PREVIEW: Device has been announced but is not in production. Samples may or may not be available.

OBSOLETE: TI has discontinued the production of the device.

(2) RoHS: TI defines "RoHS" to mean semiconductor products that are compliant with the current EU RoHS requirements for all 10 RoHS substances, including the requirement that RoHS substance

do not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, "RoHS" products are suitable for use in specified lead-free processes. TI may

reference these types of products as "Pb-Free".

RoHS Exempt: TI defines "RoHS Exempt" to mean products that contain lead but are compliant with EU RoHS pursuant to a specific EU RoHS exemption.

Green: TI defines "Green" to mean the content of Chlorine (Cl) and Bromine (Br) based flame retardants meet JS709B low halogen requirements of <=1000ppm threshold. Antimony trioxide based

flame retardants must also meet the <=1000ppm threshold requirement.

(3) MSL, Peak Temp. - The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications, and peak solder temperature.

(4) There may be additional marking, which relates to the logo, the lot trace code information, or the environmental category on the device.

(5) Multiple Device Markings will be inside parentheses. Only one Device Marking contained in parentheses and separated by a "~" will appear on a device. If a line is indented then it is a continuation

of the previous line and the two combined represent the entire Device Marking for that device.

Addendum-Page 1

TEXAS INSTRUMENTS

PACKAGE OPTION ADDENDUM

www.ti.com 13-Jul-2022

(6) Lead finish/Ball material - Orderable Devices may have multiple material finish options. Finish options are separated by a vertical ruled line. Lead finish/Ball material values may wrap to two

lines if the finish value exceeds the maximum column width.

Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is provided. TI bases its knowledge and belief on information

provided by third parties, and makes no representation or warranty as to the accuracy of such information. Efforts are underway to better integrate information from third parties. TI has taken and

continues to take reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on incoming materials and chemicals.

TI and TI suppliers consider certain information to be proprietary, and thus CAS numbers and other limited information may not be available for release.

In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI to Customer on an annual basis.

OTHER QUALIFIED VERSIONS OF CD54HC11, CD74HC11 :

•Catalog : CD74HC11

•Military : CD54HC11

NOTE: Qualified Version Definitions:

•Catalog - TI's standard catalog product

•Military - QML certified for Military and Defense Applications

Addendum-Page 2

I TEXAS INSTRUMENTS ‘3‘ V.'

PACKAGE MATERIALS INFORMATION

www.ti.com 9-Aug-2022

TAPE AND REEL INFORMATION

Reel Width (W1)

REEL DIMENSIONS

Dimension designed to accommodate the component length

Dimension designed to accommodate the component thickness

Overall width of the carrier tape

Pitch between successive cavity centers

Dimension designed to accommodate the component width

TAPE DIMENSIONS

K0 P1

B0 W

Cavity

QUADRANT ASSIGNMENTS FOR PIN 1 ORIENTATION IN TAPE

Pocket Quadrants

Sprocket Holes

Q1 Q1Q2 Q2

Q3 Q3Q4 Q4 User Direction of Feed

Reel

Diameter

*All dimensions are nominal

Device Package

Type Package

Drawing Pins SPQ Reel

Diameter

(mm)

Reel

Width

W1 (mm)

(mm) B0

(mm) K0

(mm) P1

(mm) W

(mm) Pin1

Quadrant

CD74HC11M96 SOIC D 14 2500 330.0 16.4 6.6 9.3 2.1 8.0 16.0 Q1

CD74HC11M96 SOIC D 14 2500 330.0 16.4 6.5 9.0 2.1 8.0 16.0 Q1

CD74HC11MT SOIC D 14 250 330.0 16.4 6.5 9.0 2.1 8.0 16.0 Q1

Pack Materials-Page 1

PACKAGE MATERIALS INFORMATION

www.ti.com 9-Aug-2022

TAPE AND REEL BOX DIMENSIONS

Width (mm)

*All dimensions are nominal

Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)

CD74HC11M96 SOIC D 14 2500 366.0 364.0 50.0

CD74HC11M96 SOIC D 14 2500 356.0 356.0 35.0

CD74HC11MT SOIC D 14 250 210.0 185.0 35.0

Pack Materials-Page 2

I TEXAS INSTRUMENTS

PACKAGE MATERIALS INFORMATION

www.ti.com 9-Aug-2022

TUBE

L - Tube length

T - Tube

height

W - Tube

width

B - Alignment groove width

*All dimensions are nominal

Device Package Name Package Type Pins SPQ L (mm) W (mm) T (µm) B (mm)

CD74HC11E N PDIP 14 25 506 13.97 11230 4.32

CD74HC11M D SOIC 14 50 506.6 8 3940 4.32

Pack Materials-Page 3

GENERIC PACKAGE VIEW J 14 CDIP - 5.08 mm max heigm CERAMIC DUAL IN LINE PACKAGE [I l l 'I I.“ Images above are jusl a represenlalion of the package family, aclual package may vary Refel lo the produd dala sheel for package details. 4040053756 I TEXAS INSTRI IMFNTS

www.ti.com

PACKAGE OUTLINE

14X .008-.014

[0.2-0.36]

TYP

-15

AT GAGE PLANE

-.314.308 -7.977.83[ ]

14X -.026.014 -0.660.36[ ]

14X -.065.045 -1.651.15[ ]

.2 MAX TYP

[5.08] .13 MIN TYP

[3.3]

TYP-.060.015 -1.520.38[ ]

4X .005 MIN

[0.13]

12X .100

[2.54]

.015 GAGE PLANE

[0.38]

-.785.754 -19.9419.15[ ]

B -.283.245 -7.196.22[ ]

CDIP - 5.08 mm max heightJ0014A

CERAMIC DUAL IN LINE PACKAGE

4214771/A 05/2017

NOTES:

1. All controlling linear dimensions are in inches. Dimensions in brackets are in millimeters. Any dimension in brackets or parenthesis are for

reference only. Dimensioning and tolerancing per ASME Y14.5M.

2. This drawing is subject to change without notice.

3. This package is hermitically sealed with a ceramic lid using glass frit.

4. Index point is provided on cap for terminal identification only and on press ceramic glass frit seal only.

5. Falls within MIL-STD-1835 and GDIP1-T14.

PIN 1 ID

(OPTIONAL)

SCALE 0.900

SEATING PLANE

.010 [0.25] C A B

www.ti.com

EXAMPLE BOARD LAYOUT

ALL AROUND

[0.05] MAX.002

.002 MAX

[0.05]

ALL AROUND

SOLDER MASK

OPENING

METAL

(.063)

[1.6]

(R.002 ) TYP

[0.05]

14X ( .039)

[1]

( .063)

[1.6]

12X (.100 )

[2.54]

(.300 ) TYP

[7.62]

CDIP - 5.08 mm max heightJ0014A

CERAMIC DUAL IN LINE PACKAGE

4214771/A 05/2017

LAND PATTERN EXAMPLE

NON-SOLDER MASK DEFINED

SCALE: 5X

SEE DETAIL A SEE DETAIL B

SYMM

DETAIL A

SCALE: 15X

SOLDER MASK

OPENING

METAL

DETAIL B

13X, SCALE: 15X

MECHANICAL DATA D U1 4)} 0 (3'4) DLASHC SMALL 0U ¥N¥ 4040047 5/M 06/1‘ NO'ES, A AH Hnec' dimensmrs c'e m 'mc'ves ['nﬂhmeter5> B Th5 drawer ‘5 subje», ,0 change mm: Home, A Body \cngth docs rm mac mod Hoar, p'omswons, (xv gmc bms Mom mm warmers, or gm buns sha‘ nm exceed 3005 (015) eam swce @ Body mm does 101 meme 11mm ﬁsh. E Rdererce JEDEC MS 012 mam AB, nter‘ec: ﬂash sfu‘ not exceed 0017 (043) each swde {If TEXAS INSTRUMENTS www.1i.com

LAND PATTERN DATA D (R7PDSOmGl4) PLASTlC SMALL OUTLINE Example Board Layout Sterlazlogpeulyngs (Mole c) —— <—14x0,55 -hhheb&&t="" tmedddiﬁ§n%="" 5.40="" 5,40="" @eeeeeej="" rﬁhﬂ§eﬂhj="" —=""> ——l 2x1,27 Example Non Soldermask Delined Pad Example Pad Geometry (See Note c) F Example l / Solder Mask Opening 7 0 07 f (See Note E) All Armlnd ,/ tzllmss/E oa/lz NOTES: A. All linear dimensions are in millimeters. a, Tnis drawan is subject to cnonae wl'lhuul notice. c. Publlcutl’on chs7351 is recommended tor alternate desl’gns. D. Laser ctming apertures w‘lth trapezoidal walls and also roundlng comers wlll otter better paste release. Customers should contact their board assembly site for stencil design recommendations, Reter tc ch—7525 lor otner stencil recommendations. E. Customers snoola contact their ooard looricotion site lor solder musk tolerances between ond oroond signol oods. {I} Tums INSTRUMENTS www.li.com

MECHANICAL DATA N (R—PDlP-T“) PLASTIC DUAL—IN—LINE PACKAGE 16 P15 SHOWN PWS " A L . [NM 15 a 20 16 9 0 775 U 777 0 SZU '1 USE 3 , 1H HH HH r% r’H r"—1 r’H H1 1 A VAX “9‘69? (191591 (23,37) (25,92) 0 250 (6,50‘ A MN [1145‘ 0142‘ 0.350 new 3 O 240 (6.10), 15 92/ (1832/ (2 .59) (23,58) MSiUO‘ (A AA AA Ari AA AA AA R1 &. VAR1AT1CN M RR AC AD 1 B 0070( (17s) 0015 (111) A 0045 (1,111 g n > , ‘ -) 3.020 (0,51) MW w o 5 (0 35) 0200( 38) MAX f, ), Gnu E Home 1 1‘ 9 fix—1%)” 1 0125’ 1/111 4% 0010 (v.37 ) NOM 31a) U L»- J 0450 (13,92) MAX L 202‘ (0,53) » e c 015 (0,35) / \ a; 00‘s (0,Zb)® / \ 1 1 \\¥,// 11/18 Pm (My > @ 20 Pm vendor upho'v mom/r 17/7037 NO'FS A AH Mnec' mmensmr‘ﬁ: B 1m: drawmq 1s sume m muss (m1111mevem) 0 change mm): noﬁce /c\ FuHs wumn JEDEC M57001, except 15 an: 20 p171 'r1111mLm body 1mm (01m A) A The 70 p171 and 15m} shmﬂder Md” 15 a ve'vdnr 0311071, eher NIH Dr 111 wkﬂh INSI'RUMENTS www.1i.com

IMPORTANT NOTICE AND DISCLAIMER

TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATA SHEETS), DESIGN RESOURCES (INCLUDING REFERENCE

DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”

AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY

IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD

PARTY INTELLECTUAL PROPERTY RIGHTS.

These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate

TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable

standards, and any other safety, security, regulatory or other requirements.

These resources are subject to change without notice. TI grants you permission to use these resources only for development of an

application that uses the TI products described in the resource. Other reproduction and display of these resources is prohibited. No license

is granted to any other TI intellectual property right or to any third party intellectual property right. TI disclaims responsibility for, and you

will fully indemnify TI and its representatives against, any claims, damages, costs, losses, and liabilities arising out of your use of these

resources.

TI’s products are provided subject to TI’s Terms of Sale or other applicable terms available either on ti.com or provided in conjunction with

such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for

TI products.

TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

Fiche technique pour CD54,74HC(T)11 de Texas Instruments

INFORMATIONS

AIDE

NOUS CONTACTER

NOUS SUIVRE
