Fabric label sheet-BMK 20X 8 WH-0805470
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Fabric label sheet, Sheet, white, unlabeled, can be labeled with: Plotter, Mounting type: Adhesive, Lettering field:
20 mm x 8 mm
The illustration shows version BMK
38x11 in yellow
Product Features
Available in various dimensions
Self-adhesive labels for labeling by hand or with a plotter
Labeling service: Phoenix Contact can custom-label all BMK ... markers according to your requirements
Secure adhesion even on curved or uneven surfaces as well as round corners
The material file can be downloaded under the CLIP PROJECT software under Downloads - “Software update - Marking”.
Key Commercial Data
Packing unit 1 pc
Minimum order quantity 10 pc
Weight per Piece (excluding packing) 19.32 g
Custom tariff number 39199000
Country of origin Belgium
Technical data
Dimensions
Length (b) 20 mm
Width (a) 8 mm
Ambient conditions
Ambient temperature (operation) -40 °C ... 80 °C
General
Note Can be labeled with CMS
Color white
Base element material Polyester foil
Components Silicone-free
PHGNIX CONTACT
https://www.phoenixcontact.com/us/products/0805470
12/11/2015Page2/3
Fabric label sheet-BMK 20X 8 WH-0805470
Technical data
General
Flammability rating according to UL 94 V0
Material Polyester foil
Number of individual labels 270
Number of individual labels per row 9
Adhesive Acrylic
Printability Plotter
Device 5144615 CMS-P1-PLOTTER
Test for substances that would hinder coating with paint or varnish VW PV 3.10.7:2005-02
Result Test passed
Test specification weathering-resistance Following ISO 4892-2:2013-03
Test duration 96 h
Wipe resistance test result Test passed
Salt spray test specification DIN EN 60068-2-11:2000-02
Test duration 96 h
Salt spray testing result Test passed
Alternating condensation climate with SO2 test specification DIN 50018:2013-05
Climate level AHT 1.0 S
Cycles 2
Condensation test result Test passed
Wipe resistance of test specification inscriptions DIN EN 61010-1 (VDE 0411-1):2011-07
Result Test passed
Marking mounting type Adhesive
Standards and Regulations
Flammability rating according to UL 94 V0
Classifications
eCl@ss
eCl@ss 4.0 24190218
eCl@ss 4.1 24190218
eCl@ss 5.0 27141137
eCl@ss 5.1 27141137
eCl@ss 6.0 27141137
eCl@ss 7.0 27141137
eCl@ss 8.0 27149129
PHGNIX CON'I'ACI'
https://www.phoenixcontact.com/us/products/0805470
12/11/2015Page3/3
Fabric label sheet-BMK 20X 8 WH-0805470
Classifications
ETIM
ETIM 2.0 EC000761
ETIM 3.0 EC000761
ETIM 4.0 EC000761
ETIM 5.0 EC001288
UNSPSC
UNSPSC 6.01 30211811
UNSPSC 7.0901 39121410
UNSPSC 11 39121410
UNSPSC 12.01 39121410
UNSPSC 13.2 39121410
