XRA1206

8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS

SEPTEMBER 2011 REV. 1.0.0

GENERAL DESCRIPTION

The XRA1206 is an 8-bit GPIO expander with an I2C/

SMBus interface. After power-up, the XRA1206 has

internal 100K ohm pull-up resistors on each I/O pin

that can be individually enabled.

In addition, the GPIOs on the XRA1206 can

individually be controlled and configured. As outputs,

the GPIOs can be outputs that are high, low or in

three-state mode. The three-state mode feature is

useful for applications where the power is removed

from the remote devices, but they may still be

connected to the GPIO expander.

As inputs, the internal pull-up resistors can be

enabled or disabled and the input polarity can be

inverted. The interrupt can be programmed for

different behaviors. The interrupts can be

programmed to generate an interrupt on the rising

edge, falling edge or on both edges. The interrupt

can be cleared if the input changes back to its original

state or by reading the current state of the inputs.

The XRA1206 is an enhanced version of the

TCA6408. The XRA1206 is pin and software

compatible with the TCA6408.

The XRA1206 is available in 16-pin QFN and 16-pin

TSSOP packages.

FEATURES

•1.65V to 3.6V operating voltage

•Integrated level shifters

•8 General Purpose I/Os (GPIOs)

•5V tolerant inputs

•Maximum stand-by current of 1uA at +1.8V

•I2C/SMBus bus interface

■I2C clock frequency up to 400kHz

■Noise filter on SDA and SCL inputs

■Up to 4 I2C Slave Addresses

•Individually programmable inputs

■Internal pull-up resistors

■Polarity inversion

■Individual interrupt enable

■Rising edge and/or Falling edge interrupt

■Input filter

•Individually programmable outputs

■Output Level Control

■Output Three-State Control

•Open-drain active low interrupt output

•Active-low reset input

•Pin and software compatible with TCA6408

•3kV HBM ESD protection per JESD22-A114F

•200mA latch-up performance per JESD78B

APPLICATIONS

•Personal Digital Assistants (PDA)

•Cellular Phones/Data Devices

•Battery-Operated Devices

•Global Positioning System (GPS)

•Bluetooth

/@ REV. 1.0.0 XRA1206|L167F QFN716 740°C m +85°C Ac‘ive HHHHHHHH UUUUUUUU

XRA1206

8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS REV. 1.0.0

FIGURE 1. XRA1206 BLOCK DIAGRAM

I2C/

SMBus

Interface

SCL

SDA

GPIO

Control

Registers

RESET#

IRQ#

GPIOs

VCC (1.65V – 3.6V)

GND

Integrated

Level

Shifters

(1.65V – 3.6V) VCCP

ORDERING INFORMATION

PART NUMBER PACKAGE NUMBER OF

GPIOS

OPERATING TEMPERATURE

RANGE DEVICE STATUS

XRA1206IL16-F QFN-16 8-40°C to +85°C Active

XRA1206IL16TR-F QFN-16 8-40°C to +85°C Active

XRA1206IG16-F TSSOP-16 8-40°C to +85°C Active

XRA1206IG16TR-F TSSOP-16 8-40°C to +85°C Active

NOTE: TR = Tape and Reel, F = Green / RoHS

FIGURE 2. PIN OUT ASSIGNMENTS

XRA1206

16-Pin TSSOP

VCC

RESET#

GND 9

16 VCCP

SDA

SCL

IRQ#

XRA1206

16-Pin QFN

RESET#

GND

VCC

VCCP

SDA

IRQ#

SCL

16 15 14 13

5678

/@ REV. 1.0.0

XRA1206

REV. 1.0.0 8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS

PIN DESCRIPTIONS

Pin Description

NAME PIN# PIN#TYPE DESCRIPTION

I2C INTERFACE

SDA 13 15 I/O I2C-bus data input/output (open-drain).

SCL 12 14 II2C-bus serial input clock.

IRQ# 11 13 OD Interrupt output (open-drain, active LOW).

A0 16 2 I This pin selects the I2C slave address. See Table 1.

RESET# 1 3 I Reset (active LOW) - A longer than 40 ns LOW pulse on this pin will reset the

internal registers and all GPIOs will be configured as inputs.

GPIOs

I/O

General purpose I/Os P0-P7. All GPIOs are configured as inputs upon power-

up or after a reset.

ANCILLARY SIGNALS

VCCP 14 16 Pwr 1.65V to 3.6V VCC supply voltage for GPIOs.

VCC 15 1Pwr 1.65V to 3.6V VCC supply voltage for I2C-bus interface.

GND 6 8 Pwr Power supply common, ground.

GND Center

Pad

-Pwr The exposed pad at the bottom surface of the package is designed for thermal

performance. Use of a center pad on the PCB is strongly recommended for ther-

mal conductivity as well as to provide mechanical stability of the package on the

PCB. The center pad is recommended to be solder masked defined with open-

ing size less than or equal to the exposed thermal pad on the package bottom to

prevent solder bridging to the outer leads of the device. Thermal vias must be

connected to GND plane as the thermal pad of package is at GND potential.

Pin type: I=Input, O=Output, I/O= Input/output, OD=Output Open Drain.

QFN-16 TSSOP-16

/@ REV. 1.0.0

XRA1206

8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS REV. 1.0.0

1.0 FUNCTIONAL DESCRIPTIONS

1.1 I2C-bus Interface

The I2C-bus interface is compliant with the Standard-mode and Fast-mode I2C-bus specifications. The I2C-bus

interface consists of two lines: serial data (SDA) and serial clock (SCL). In the Standard-mode, the serial clock

and serial data can go up to 100 kbps and in the Fast-mode, the serial clock and serial data can go up to 400

kbps.

The first byte sent by an I2C-bus master contains a start bit (SDA transition from HIGH to LOW when SCL is

HIGH), 7-bit slave address and whether it is a read or write transaction. The next byte is the sub-address that

contains the address of the register to access. The XRA1206 responds to each write with an acknowledge

(SDA driven LOW by XRA1206 for one clock cycle when SCL is HIGH). The last byte sent by an I2C-bus

master contains a stop bit (SDA transition from LOW to HIGH when SCL is HIGH). See Figures 3 - 5 below.

For complete details, see the I2C-bus specifications.

FIGURE 3. I C START AND STOP CONDITIONS

SDA

SCL

START condition STOP condition

FIGURE 4. MASTER WRITES TO SLAVE

SWA A AP

SLAVE

ADDRESS

COMMAND

BYTE

DATA

BYTE

White block: host to XRA120x

Grey block: XRA120x to host

FIGURE 5. MASTER READS FROM SLAVE

SWAAR

SLAVE

ADDRESS

COMMAND

BYTE

White block: host to XRA120x

Grey block: XRA120x to host

AS SLAVE

ADDRESS nDATA ANAPLAST DATA

/@ REV. 1.0.0

XRA1206

REV. 1.0.0 8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS

1.1.1 I2C-bus Addressing

There could be many devices on the I2C-bus. To distinguish itself from the other devices on the I2C-bus, the

XRA1206 has up to 4 I2C slave addresses using the A0 address line. Table 1 below shows the different

addresses that can be selected.

TABLE 1: I C ADDRESS MAP

C ADDRESS

GND 0x40 (0100 000X)

VCC 0x42 (0100 001X)

SCL 0x50 (0101 000X)

SDA 0x52 (0101 001X)

1.1.2 I2C Read and Write

A read or write transaction is determined by bit-0 of the slave address. If bit-0 is ’0’, then it is a write

transaction. If bit-0 is ’1’, then it is a read transaction.

1.1.3 I2C Command Byte

An I2C command byte is sent by the I2C master following the slave address. The command byte indicates the

address offset of the register that will be accessed. Table 2 below lists the command bytes for each register.

TABLE 2: I C COMMAND BYTE (REGISTER ADDRESS)

COMMAND BYTE REGISTER NAME DESCRIPTION READ/WRITE DEFAULT VALUES

0x00 GSR - GPIO State Read-Only 0xXX

0x01 OCR - Output Control Read/Write 0xFF

0x02 PIR - Input Polarity Inversion Read/Write 0x00

0x03 GCR - GPIO Configuration Read/Write 0xFF

0x04 PUR - Input Internal Pull-up Resistor Enable/Disable Read/Write 0x00

0x05 IER - Input Interrupt Enable Read/Write 0x00

0x06 TSCR - Output Three-State Control Read/Write 0x00

0x07 ISR - Input Interrupt Status Read 0x00

0x08 REIR - Input Rising Edge Interrupt Enable Read/Write 0x00

0x09 FEIR - Input Falling Edge Interrupt Enable Read/Write 0x00

0x0A IFR - Input Filter Enable/Disable Read/Write 0xFF

A0 I2

XRA1206

8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS REV. 1.0.0

1.2 Interrupts

The table below summarizes the interrupt behavior of the different register settings for the XRA1206.

TABLE 3: INTERRUPT GENERATION AND CLEARING

BIT BIT BIT BIT BIT INTERRUPT GENERATED BY: INTERRUPT CLEARED BY:

1 0 X X X No interrupts enabled (default) N/A

1 1 0 0

0A rising or falling edge on the input Reading the GSR register or if the input

changes back to its previous state (state of

input during last read to GSR)

1A rising or falling edge on the input and

remains in the new state for more than

1075ns

1 1 1 0

0A rising edge on the input Reading the GSR register

1A rising edge on the input and remains high

for more than 1075ns

1 1 0 1

0A falling edge on the input Reading the GSR register

1A falling edge on the input and remains low

for more than 1075ns

1 1 1 1

0A rising or falling edge on the input Reading the GSR register

1A rising or falling edge on the input and

remains in the new state for more than

1075ns

0 x x x x No interrupts in output mode N/A

GCR IER REIR FEIR IFR

XRA1206

REV. 1.0.0 8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS

2.0 REGISTER DESCRIPTION

2.1 GPIO State Register (GSR) - Read-Only

The status of P7 - P0 can be read via this register. A read will show the current state of these pins (or the

inverted state of these pins if enabled via the PIR Register). Reading this register will clear an input interrupt

(see Table 3 for complete details). Reading this register will also return the last value written to the OCR

since the output pin can be in three-state mode). A write to this register has no effect. The MSB of this register

corresponds with P7 and the LSB of this register corresponds with P0.

2.2 Output Control Register (OCR) - Read/Write

When P7 - P0 are defined as outputs, they can be controlled by writing to this register. Reading this register

will return the last value written to it, however, this value may not be the actual state of the output pin since

these pins can be in three-state mode. The MSB of this register corresponds with P7 and the LSB of this

2.3 Input Polarity Inversion Register (PIR) - Read/Write

When P7 - P0 are defined as inputs, this register inverts the polarity of the input value read from the Input Port

inverted value of the input pin. If the corresponding bit in this register is set to ’0’, the value of this bit in the

GSR Register will be the actual value of the input pin. The MSB of this register corresponds with P7 and the

LSB of this register corresponds with P0.

2.4 GPIO Configuration Register (GCR) - Read/Write

This register configures the GPIOs as inputs or outputs. After power-up and reset, the GPIOs are inputs.

Setting these bits to ’0’ will enable the GPIOs as outputs. Setting these bits to ’1’ will enable the GPIOs as

inputs. The MSB of this register corresponds with P7 and the LSB of this register corresponds with P0.

2.5 Input Internal Pull-up Enable/Disable Register (PUR) - Read/Write

This register enables/disables the internal pull-up resistors for an input. After power-up and reset, the internal

pull-up resistors are disabled for the XRA1206. Writing a ’1’ to these bits will enable the internal pull-up

resistors. Writing a ’0’ to these bits will disable the internal pull-up resistors. The MSB of this register

corresponds with P7 and the LSB of this register corresponds with P0.

2.6 Input Interrupt Enable Register (IER) - Read/Write

This register enables/disables the interrupts for an input. After power-up and reset, the interrupts are disabled.

Writing a ’1’ to these bits will enable the interrupt for the corresponding input pins. See Table 3 for complete

details of the interrupt behavior for various register settings. No interrupts are generated for outputs when GCR

bit is 0. The MSB of this register corresponds with P7 and the LSB of this register corresponds with P0.

2.7 Output Three-State Control Register (TSCR) - Read/Write

This register can enable/disable the three-state mode of an output. Writing a ’1’ to these bits will enable the

three-state mode for the corresponding output pins. The MSB of this register corresponds with P7 and the LSB

of this register corresponds with P0.

2.8 Input Interrupt Status Register (ISR) - Read-Only

This register reports the input pins that have generated an interrupt. See Table 3 for complete details of the

interrupt behavior for various register settings. The MSB of this register corresponds with P7 and the LSB of

this register corresponds with P0.

XRA1206

8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS REV. 1.0.0

2.9 Input Rising Edge Interrupt Enable Register (REIR) - Read/Write

Writing a ’1’ to these bits will enable the corresponding input to generate an interrupt on the rising edge. See

Table 3 for complete details of the interrupt behavior for various register settings. The MSB of this register

corresponds with P7 and the LSB of this register corresponds with P0.

2.10 Input Falling Edge Interrupt Enable Register (FEIR) - Read/Write

Writing a ’1’ to these bits will enable the corresponding input to generate an interrupt on the falling edge.

Writing a ’1’ to these bits will make that input generate an interrupt on the rising edge only. See Table 3 for

complete details of the interrupt behavior for various register settings. The MSB of this register corresponds

with P7 and the LSB of this register corresponds with P0.

2.11 Input Filter Enable Register (IFR) - Read/Write

By default, the input filters are enabled (IFR = 0xFF). When the input filters are enabled, any pulse that is

greater than 1075ns will generate an interrupt (if enabled). Pulses that are less than 225ns will be filtered and

will not generate an interrupt. Pulses in between this range may or may not generate an interrupt. Writing a ’0’

to these bits will disable the input filter for the corresponding inputs. With the input filters disabled, any change

on the inputs will generate an interrupt (if enabled). See Table 3 for complete details of the interrupt behavior

for various register settings. The MSB of this register corresponds with P7 and the LSB of this register

corresponds with P0.

/@ REV. 1.0.0

ABSOLUTE MAXIMUM RATINGS

Power supply voltage 3.6 Volts

Supply current 160 mA

Ground current 200 mA

External current limit of each GPIO 25 mA

Total current limit for GPIO[7:0] 100 mA

Total supply current sourced by all GPIOs 160 mA

Operating Temperature -40o to +85oC

Storage Temperature -65o to +150oC

Power Dissipation 200 mW

TYPICAL PACKAGE THERMAL RESISTANCE DATA (MARGIN OF ERROR: ± 15%)

Thermal Resistance (16-QFN) theta-ja = 40oC/W, theta-jc = 26oC/W

Thermal Resistance (16-TSSOP) theta-ja = 105oC/W, theta-jc = 20oC/W

XRA1206

REV. 1.0.0 8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS

H» \+

ELECTRICAL CHARACTERISTICS

DC ELECTRICAL CHARACTERISTICS

UNLESS OTHERWISE NOTED: TA = -40O TO +85OC, VCC IS 1.65V TO 3.6V

SYMBOL PARAMETER

LIMITS

MIN MAX

LIMITS

MIN MAX

LIMITS

MIN MAX

UNITS CONDITIONS

VIL Input Low Voltage -0.3 0.3VCC -0.3 0.3VCC -0.3 0.3VCC VNote 1

VIL Input Low Voltage -0.3 0.2 -0.3 0.5 -0.3 0.8 VNote 2

VIH Input High Voltage 1.3 VCC 1.8 VCC 2.3 VCC VNote 1

VIH Input High Voltage 1.4 5.5 1.8 5.5 2.0 5.5 VNote 2

VOL Output Low Voltage

0.4

0.4 V

IOL = 3 mA

Note 3

VOL Output Low Voltage 0.5 0.5 0.5 V IOL = 8 mA

Note 4

VOL Output Low Voltage

0.4

0.4 V

IOL = 6 mA

IOL = 4 mA

IOL = 1.5 mA

Note 5

VOH Output High Voltage

1.2

1.8

2.6 V

IOH = -8 mA

Note 4

IIL Input Low Leakage Current ±10 ±10 ±10 uA

IIH Input High Leakage Current ±10 ±10 ±10 uA

ICC Power Supply Current 50 100 200 uA Test 1

ICC Power Supply Current 150 250 500 uA Test 2

ICCS Standby Current 1 2 5 uA Test 3

CIN Input Pin Capacitance 5 5 5 pF

RGPIO GPIO pull-up resistance 60 140 60 140 60 140 kΩ100kΩ ± 40%

RRESET# Reset# pull-up resistance 35 85 35 85 35 85 kΩ60kΩ ± 40%

XRA1206

8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS REV. 1.0.0

NOTE: The Vcc comes from VCCP pin for the GPIOs and the VCC pin for the other signals;

NOTES:

1. For I2C input signals (SDA, SCL);

2. For GPIOs, A0, A1 and A2 signals;

3. For I2C output signal SDA;

4. For GPIOs;

1.8V 10% 2.5V 10% 3.3V 10%

6m) REV. 1.0.0

XRA1206

REV. 1.0.0 8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS

5. For IRQ# signal;

Test 1: SCL frequency is 400 KHz with internal pull-ups disabled. All GPIOs are configured as inputs. All inputs are steady

at VCC or GND. Outputs are floating or in the tri-state mode.

Test 2: SCL frequency is 400 KHz with internal pull-ups enabled. All GPIOs are configured as inputs. All inputs are steady

at VCC or GND. Outputs are floating or in the tri-state mode.

Test 3: All inputs are steady at VCC or GND to minimize standby current. If internal pull-up is enabled, input voltage level

should be the same as VCC. All GPIOs are configured as inputs. SCL and SDA are at VCC. Outputs are left floating or in

tri-state mode.

AC ELECTRICAL CHARACTERISTICS

Unless otherwise noted: TA=-40o to +85oC, Vcc=1.65V - 3.6V

SYMBOL PARAMETER

STANDARD MODE

C-BUS

MIN MAX

FAST MODE

C-BUS

MIN MAX

UNIT

fSCL Operating frequency 0100 0400 kHz

TBUF Bus free time between STOP and START 4.7 1.3 µs

THD;STA START condition hold time 4.0 0.6 µs

TSU;STA START condition setup time 4.7 0.6 µs

THD;DAT Data hold time 0 0 ns

TVD;ACK Data valid acknowledge 0.6 0.6 µs

TVD;DAT SCL LOW to data out valid 0.6 0.6 ns

TSU;DAT Data setup time 250 150 ns

TLOW Clock LOW period 4.7 1.3 µs

THIGH Clock HIGH period 4.0 0.6 µs

TFClock/data fall time 300 300 ns

TRClock/data rise time 1000 300 ns

TSP Pulse width of spikes tolerance 50 50 ns

TD1 I2C-bus GPIO output valid 0.2 0.2 µs

TD4 I2C input pin interrupt valid 4 4 µs

TD5 I2C input pin interrupt clear 4 4 µs

TD15 SCL delay after reset 3 3 µs

I2I2

HXf ]\/

FIGURE 6. I C-BUS TIMING DIAGRAM

START

condition

(S)

Bit 7

MSB

(A7)

Bit 6

(A6)

Protocol

TBUF

TSU;STA TLOW THIGH

1/FSCL

SCL

THD;STA TSU;DAT THD;DAT

SDA

Bit 0

LSB

(R/W)

Acknowledge

(A)

STOP

condition

(P)

TVD;DAT

TSP

TVD;ACK TSU;STO

FIGURE 7. WRITE TO OUTPUT

SLAVE

ADDRESS WA COMMAND

BYTE ADATAASDA

GPIOn

TD1

FIGURE 8. GPIO PIN INTERRUPT

SLAVE

ADDRESS WA COMMAND

BYTE ADATAASDA

INT#

TD5

SLAVE

ADDRESS

TD4

ACK from slave ACK from slave ACK from m aster

XRA1206

8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS REV. 1.0.0

/@ REV. 1.0.0

PACKAGE DIMENSIONS (16 PIN QFN - 3 X 3 X 0.9 mm, 0.50 PITCH)

Note: the actual center pad

is metallic and the size (D2)

is device-dependent with a

typical tolerance of 0.3mm

Note: The control dimension is in millimeter.

INCHES MILLIMETERS

SYMBOL MIN MAX MIN MAX

A0.031 0.039 0.80 1.00

A1 0.000 0.002 0.00 0.05

A3 0.000 0.008 0.00 0.20

D0.118 BSC 3.00 BSC

D2 0.063 0.071 1.60 1.80

b0.010 0.014 0.25 0.35

e0.020 BSC 0.50 BSC

L0.012 0.020 0.30 0.50

θ014o014o

k0.008 -0.20 -

XRA1206

REV. 1.0.0 8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS

PACKAGE DIMENSIONS (16 PIN TSSOP - 4.4 mm)

Note: The control dimension is in millimeter.

INCHES MILLIMETERS

SYMBOL MIN MAX MIN MAX

A0.031 0.047 0.80 1.20

A1 0.002 0.006 0.05 0.15

A2 0.031 0.037 0.80 0.95

b0.007 0.012 0.19 0.30

C0.004 0.008 0.09 0.2

D0.193 0.201 4.90 5.10

E0.240 0.264 6.30 6.60

E1 0.169 0.177 4.30 4.50

e0.0256 BSC 0.65 BSC

L0.018 0.030 0.45 0.75

α0° 8° 0° 8°

XRA1206

8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS REV. 1.0.0

/@ REV. 1.0.0

REVISION HISTORY

DATE REVISION DESCRIPTION

September 2011 1.0.0 Final Datasheet.

NOTICE

EXAR Corporation reserves the right to make changes to the products contained in this publication in order to

improve design, performance or reliability. EXAR Corporation assumes no responsibility for the use of any

circuits described herein, conveys no license under any patent or other right, and makes no representation that

the circuits are free of patent infringement. Charts and schedules contained here in are only for illustration

purposes and may vary depending upon a user’s specific application. While the information in this publication

has been carefully checked; no responsibility, however, is assumed for inaccuracies.

EXAR Corporation does not recommend the use of any of its products in life support applications where the

failure or malfunction of the product can reasonably be expected to cause failure of the life support system or

to significantly affect its safety or effectiveness. Products are not authorized for use in such applications unless

EXAR Corporation receives, in writing, assurances to its satisfaction that: (a) the risk of injury or damage has

been minimized; (b) the user assumes all such risks; (c) potential liability of EXAR Corporation is adequately

protected under the circumstances.

Datasheet September 2011.

Send your UART technical inquiry with technical details to hotline: uarttechsupport@exar.com.

Reproduction, in part or whole, without the prior written consent of EXAR Corporation is prohibited.

XRA1206

REV. 1.0.0 8-BIT I2C/SMBUS GPIO EXPANDER WITH INTEGRATED LEVEL SHIFTERS

Fiche technique pour XRA1206 de MaxLinear, Inc.

INFORMATIONS

AIDE

NOUS CONTACTER

NOUS SUIVRE
