SMD Power Inductor
CDRH4D22/HP
Page 1 of 5 Revised: 13-Sep-17
Description
•Ferrite drum core construction.
•Magnetically shielded.
•L×W×H:5.0×5.0×2.4 mm Max.
•Product weight: 0.2g(Ref.)
•Moisture Sensitivity Level: 1
•RoHS compliance.
Environmental Data
•Operating temperature range: -40℃~+100℃
(including coil’s self temperature rise)
•Storage temperature range: -40℃～+100℃
•Solder reflow temperature: 260 ℃peak.
Packaging
•Carrier tape and reel packaging
• 12.9”diameter reel
•2000pcs per reel
Applications
•Ideally used in Mobile phone,PDA,MP3,
HDD,DSC/DVC, Portable Computers, etc as
DC-DC converter inductors.
RoHS
Dimension - [mm]
Land pattern and Schematics - [mm]
※4.7±0.3
4.5
※4.7±0.3
1.5
4.5
6.9Max.
2.4 Max.
(
2.2)
Electrode terminal
1.5 1.9
1.9
5.3
（1.2μH～5.2μH） （6.3μH～100μH）
①
②
①
②
①
②
①
②
-||| mad;
SMD Power Inductor
CDRH4D22/HP
Page 2 of 5 Revised: 13-Sep-17
Electrical Characteristics
※1. Inductance measuring condition: at 100kHz.
※2. Saturation current: The value of D.C. current when the inductance decreases to 65% of it’s nominal value.
※3. Temperature rise current: The value of D.C. current when the temperature rise is △t＝40℃(Ta＝20℃).
Part Name Stamp Inductance
(μH)
[ within ] ※1
D.C.R. (mΩ)
Max. (Typ.)
(at 20℃)
Saturation Current
( A ) ※2Temperature
Rise Current
(A) ※3
at 20℃at 100℃
CDRH4D22HPNP-1R2NC 1R2 1.2±25% 26.5(21.2) 4.20 3.40 3.20
CDRH4D22HPNP-1R5NC 1R5 1.5±25% 31.3(25.0) 3.90 3.20 3.00
CDRH4D22HPNP-2R2NC 2R2 2.2±25% 44.3(35.4) 3.20 2.50 2.40
CDRH4D22HPNP-2R7NC 2R7 2.7±25% 57.8(46.3) 2.80 2.35 2.20
CDRH4D22HPNP-3R5NC 3R5 3.5±25% 65.1(52.0) 2.50 2.10 2.00
CDRH4D22HPNP-4R7NC 4R7 4.7±25% 82.6(66.0) 2.20 1.80 1.80
CDRH4D22HPNP-5R2NC 5R2 5.2±25% 92.8(74.3) 2.00 1.65 1.70
CDRH4D22HPNP-6R3NC 6R3 6.3±25% 110.0(87.9) 1.85 1.50 1.40
CDRH4D22HPNP-8R2NC 8R2 8.2±25% 128.3(102.6) 1.65 1.40 1.35
CDRH4D22HPNP-100MC100 10±20% 143.8(115.0) 1.50 1.20 1.30
CDRH4D22HPNP-120MC120 12±20% 187.2(150.0) 1.30 1.10 1.10
CDRH4D22HPNP-150MC150 15±20% 212.9(170.3) 1.20 1.00 0.85
CDRH4D22HPNP-180MC180 18±20% 238.7(191.0) 1.10 0.90 0.80
CDRH4D22HPNP-220MC220 22±20% 267.0(213.6) 1.05 0.85 0.75
CDRH4D22HPNP-270MC270 27±20% 393.9(315.0) 0.90 0.75 0.70
CDRH4D22HPNP-330MC330 33±20% 448.9(359.0) 0.80 0.68 0.65
CDRH4D22HPNP-390MC390 39±20% 667.9(534.3) 0.75 0.60 0.52
CDRH4D22HPNP-470MC470 47±20% 723.3(578.6) 0.70 0.56 0.50
CDRH4D22HPNP-560MC560 56±20% 810.0(648.2) 0.65 0.52 0.48
CDRH4D22HPNP-680MC680 68±20% 913.0(730.4) 0.60 0.48 0.45
CDRH4D22HPNP-820MC820 82±20% 1221(977.0) 0.55 0.45 0.40
CDRH4D22HPNP-101MC101 100±20% 1370(1096.0) 0.48 0.38 0.35
-||| Wm
SMD Power Inductor
CDRH4D22/HP
Page 3 of 5 Revised: 13-Sep-17
0
3
6
9
12
15
18
0.0 0.3 0.6 0.9 1.2 1.5
0
10
20
30
40
50
60
0
2
4
6
8
10
12
0.0 0.4 0.8 1.2 1.6
0
10
20
30
40
50
60
0
2
4
6
8
10
12
0.0 0.3 0.6 0.9 1.2 1.5 1.8
0
10
20
30
40
50
60
0.0
1.5
3.0
4.5
6.0
7.5
9.0
0.0 0.4 0.8 1.2 1.6 2.0
0
10
20
30
40
50
60
0.0
1.5
3.0
4.5
6.0
7.5
9.0
0.0 0.4 0.8 1.2 1.6 2.0 2.4
0
10
20
30
40
50
60
0
1
2
3
4
5
6
0.0 0.4 0.8 1.2 1.6 2.0 2.4
0
10
20
30
40
50
60
0
1
2
3
4
5
6
0.0 0.5 1.0 1.5 2.0 2.5
0
10
20
30
40
50
60
0.0
0.8
1.6
2.4
3.2
4.0
4.8
0.0 0.5 1.0 1.5 2.0 2.5 3.0
0
10
20
30
40
50
60
0.0
0.5
1.0
1.5
2.0
2.5
3.0
0.0 0.5 1.0 1.5 2.0 2.5 3.0
0
10
20
30
40
50
60
0.0
0.4
0.8
1.2
1.6
2.0
2.4
0.0 0.6 1.2 1.8 2.4 3.0 3.6
0
10
20
30
40
50
60
0.0
0.3
0.6
0.9
1.2
1.5
1.8
0 1 2 3 4 5
0
10
20
30
40
50
60
0.0
0.3
0.6
0.9
1.2
1.5
1.8
0 1 2 3 4 5
0
10
20
30
40
50
60
Saturation Current & Temperature Rise Graph
1. CDRH4D22HPNP-1R2NC △T (℃)
L (μH)
DC (A) DC (A)
2. CDRH4D22HPNP-1R5NC △T (℃)
L (μH) △T (℃)
3. CDRH4D22HPNP-2R2NC
L (μH)
DC (A)
△T (℃)
4. CDRH4D22HPNP-2R7NC
L (μH)
DC (A)
△T (℃)
5. CDRH4D22HPNP-3R5NC
L (μH)
DC (A)
△T (℃)
6. CDRH4D22HPNP-4R7NC
L (μH)
DC (A)
△T (℃)
7. CDRH4D22HPNP-5R2NC
L (μH)
DC (A)
△T (℃)
8. CDRH4D22HPNP-6R3NC
L (μH)
DC (A) DC (A)
△T (℃)
9. CDRH4D22HPNP-8R2NC
L (μH)
L (20℃)△T L (105℃)
△T (℃)
10. CDRH4D22HPNP-100MC
L (μH)
DC (A)
△T (℃)
11. CDRH4D22HPNP-120MC
L (μH)
DC (A) DC (A)
△T (℃)
12. CDRH4D22HPNP-150MC
L (μH)
-||| Wm
SMD Power Inductor
CDRH4D22/HP
Page 4 of 5 Revised: 13-Sep-17
0
20
40
60
80
100
120
0.0 0.1 0.2 0.3 0.4 0.5 0.6
0
10
20
30
40
50
60
0
20
40
60
80
100
120
0.0 0.1 0.2 0.3 0.4 0.5 0.6
0
10
20
30
40
50
60
0
15
30
45
60
75
90
0.0 0.2 0.4 0.6 0.8
0
10
20
30
40
50
60
0
15
30
45
60
75
90
0.0 0.2 0.4 0.6 0.8
0
10
20
30
40
50
60
0
10
20
30
40
50
60
0.0 0.2 0.4 0.6 0.8
0
10
20
30
40
50
60
0
8
16
24
32
40
48
0.0 0.2 0.4 0.6 0.8 1.0
0
10
20
30
40
50
60
0
6
12
18
24
30
36
0.0 0.2 0.4 0.6 0.8 1.0
0
10
20
30
40
50
60
0
6
12
18
24
30
36
0.0 0.2 0.4 0.6 0.8 1.0 1.2
0
10
20
30
40
50
60
0
4
8
12
16
20
24
0.0 0.2 0.4 0.6 0.8 1.0 1.2
0
10
20
30
40
50
60
0
4
8
12
16
20
24
0.0 0.3 0.6 0.9 1.2 1.5
0
10
20
30
40
50
60
Saturation Current & Temperature Rise Graph
13. CDRH4D22HPNP-180MC△T (℃)
L (μH)
DC (A) DC (A)
14. CDRH4D22HPNP-220MC
△T (℃)
L (μH) △T (℃)
15. CDRH4D22HPNP-270MC
L (μH)
DC (A)
△T (℃)
16. CDRH4D22HPNP-330MC
L (μH)
DC (A)
△T (℃)
17. CDRH4D22HPNP-390MC
L (μH)
DC (A)
△T (℃)
18. CDRH4D22HPNP-470MC
L (μH)
DC (A)
△T (℃)
19. CDRH4D22HPNP-560MC
L (μH)
DC (A)
△T (℃)
20. CDRH4D22HPNP-680MC
L (μH)
DC (A) DC (A)
△T (℃)
21. CDRH4D22HPNP-820MC
L (μH)
L (20℃)△T L (105℃)
△T (℃)
22. CDRH4D22HPNP-101MC
L (μH)
DC (A)
-||| Wm hm: ://www.sumida.com sales hk-sumlda-com sham:hal.sales@cn.sumlda.cnm shenzhen.sales@cn.sumlda.cnm sales@iw.sumlda.com sales@ln.sumlda.com sales@kr.summa.cnm sales@w.sumlaa.com sales@us.summa.cnm sales@us.sumlda.com camacl@eu.sumlda.com |Mncnmn@eu.sumlda.com
SMD Power Inductor
CDRH4D22/HP
Page 5 of 5 Revised: 13-Sep-17
Solder Reflow Condition
170±10 ℃,60~120s
40s
230℃
245℃PEAK
Heat Endurance Temperature Chart
300
60
120 180 240
0
0
100
150
200
250
300
50
10
T (℃)
T (s)
60
260℃
230℃
0
100
150
200
250
300
50
T (℃)
300120 180 240
0T (s)
60
