Datenblatt für 3060212 von Phoenix Contact
https://www.phoenixcontact.com/us/products/3060212
12.11.2013Page1/9
Plug-UP 4/11-3060212
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://download.phoenixcontact.com)
Plug, Connection method:Screw connection, Number of positions:11, Cross section: 0.14 mm²-6 mm²,
AWG:24-10, Width:68.2 mm, Height:41.2 mm, Color:gray
Product Features
Screw actuation from the side
Conductor connection from above
The plug design enables space-saving potential distribution by using four-conductor terminal blocks with two slots
Key commercial data
Packing unit 1 1
Weight per Piece (excluding packing) 54.98 GRM
Custom tariff number 85366990
Country of origin Poland
Technical data
General
Number of levels 1
Number of connections 1
Color gray
Insulating material PA
Inflammability class according to UL 94 V0
Maximum load current 32 A (with 6 mm² conductor cross section)
Rated surge voltage 8 kV
Pollution degree 3
Surge voltage category III
Insulating material group I
Connection in acc. with standard IEC 61984
PHGNIX
CON'I'ACI'
https://www.phoenixcontact.com/us/products/3060212
12.11.2013Page2/9
Plug-UP 4/11-3060212
Technical data
General
Nominal current IN32 A
Nominal voltage UN800 V
Number of positions 11
Dimensions
Width 68.2 mm
Length 21 mm
Height 41.2 mm
Connection data
Conductor cross section solid min. 0.14 mm²
Conductor cross section solid max. 6 mm²
Conductor cross section AWG/kcmil min. 24
Conductor cross section AWG/kcmil max 10
Conductor cross section stranded min. 0.14 mm²
Conductor cross section stranded max. 6 mm²
Min. AWG conductor cross section, stranded 24
Max. AWG conductor cross section, stranded 10
Conductor cross section stranded, with ferrule without plastic sleeve min. 0.14 mm²
Conductor cross section stranded, with ferrule without plastic sleeve max. 4 mm²
Conductor cross section stranded, with ferrule with plastic sleeve min. 0.14 mm²
Conductor cross section stranded, with ferrule with plastic sleeve max. 4 mm²
2 conductors with same cross section, solid min. 0.14 mm²
2 conductors with same cross section, solid max. 1.5 mm²
2 conductors with same cross section, stranded min. 0.14 mm²
2 conductors with same cross section, stranded max. 1.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
sleeve, min. 0.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
sleeve, max. 1.5 mm²
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min. 0.14 mm²
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max. 1.5 mm²
Connection method Screw connection
Stripping length 9 mm
Internal cylindrical gage A4
Screw thread M3
Tightening torque, min 0.6 Nm
PHGNIX
CONTACT
https://www.phoenixcontact.com/us/products/3060212
12.11.2013Page3/9
Plug-UP 4/11-3060212
Technical data
Connection data
Tightening torque max 0.8 Nm
Classifications
eCl@ss
eCl@ss 4.0 272607xx
eCl@ss 4.1 27260701
eCl@ss 5.0 27260701
eCl@ss 5.1 27260701
eCl@ss 6.0 27141120
eCl@ss 7.0 27141120
eCl@ss 8.0 27141120
ETIM
ETIM 2.0 EC000897
ETIM 3.0 EC000897
ETIM 4.0 EC002021
ETIM 5.0 EC002021
UNSPSC
UNSPSC 6.01 30211802
UNSPSC 7.0901 39121402
UNSPSC 11 39121402
UNSPSC 12.01 39121402
UNSPSC 13.2 39121402
Approvals
Approvals
Approvals
UL Recognized / cUL Recognized / cULus Recognized
Ex Approvals
Approvals submitted
PHGNIX
CONTACT
C“ vs
https://www.phoenixcontact.com/us/products/3060212
12.11.2013Page4/9
Plug-UP 4/11-3060212
Approvals
Approval details
UL Recognized
B C
mm²/AWG/kcmil 26-10 26-10
Nominal current IN 30 A 30 A
Nominal voltage UN 600 V 600 V
cUL Recognized
B C
mm²/AWG/kcmil 26-10 26-10
Nominal current IN 30 A 30 A
Nominal voltage UN 600 V 600 V
cULus Recognized
Accessories
Accessories
End cover
Flange cover-DF-UP 4-3060348
Flange cover, Length:47 mm, Width:4.5 mm, Height:24.7 mm, Color:gray
Insulating sleeve
https://www.phoenixcontact.com/us/products/3060212
12.11.2013Page5/9
Plug-UP 4/11-3060212
Accessories
Insulating sleeve-MPS-IH WH-0201663
Insulating sleeve, Color:white
Insulating sleeve-MPS-IH RD-0201676
Insulating sleeve, Color:red
Insulating sleeve-MPS-IH BU-0201689
Insulating sleeve, Color:blue
Insulating sleeve-MPS-IH YE-0201692
Insulating sleeve, Color:yellow
Insulating sleeve-MPS-IH GN-0201702
Insulating sleeve, Color:green
mm
https://www.phoenixcontact.com/us/products/3060212
12.11.2013Page6/9
Plug-UP 4/11-3060212
Accessories
Insulating sleeve-MPS-IH GY-0201728
Insulating sleeve, Color:gray
Insulating sleeve-MPS-IH BK-0201731
Insulating sleeve, Color:black
Labeled terminal marker
Zack Marker strip, flat-ZBF 8 CUS-0825030
Zack Marker strip, flat, Can be ordered: Strip, white, Labeled according to customer specifications, Mounting type: Snap
into flat marker groove, For terminal block width: 8 mm, Lettering field: 5.15 x 8.15 mm
Marker for terminal blocks-UC-TMF 8 CUS-0824654
Marker for terminal blocks, Can be ordered: By sheet, white, Labeled according to customer specifications, Mounting
type: Snap into flat marker groove, For terminal block width: 8.2 mm, Lettering field: 7.6 x 5.1 mm
Marker for terminal blocks-UCT-TMF 8 CUS-0829672
Marker for terminal blocks, Can be ordered: By sheet, white, Labeled according to customer specifications, Mounting
type: Snap into flat marker groove, For terminal block width: 8.2 mm, Lettering field: 7.4 x 4.7 mm
III
https://www.phoenixcontact.com/us/products/3060212
12.11.2013Page7/9
Plug-UP 4/11-3060212
Accessories
Mounting material
Latching-PRZ-3040614
Latching, Length:3 mm, Width:5.2 mm, Number of positions:2, Color:orange
Latching-PR-3040559
Latching, Number of positions:1, Color:orange
Latching-PR/2-3040630
Latching, Number of positions:2, Color:orange
Screwdriver tools
Screwdriver-SZS 0,6X3,5-1205053
Actuation tool, for ST terminal blocks, insulated, also suitable for use as a bladed screwdriver, size: 0.6 x 3.5 x 100 mm,
2-component grip, with non-slip grip
Shield connection
\
https://www.phoenixcontact.com/us/products/3060212
12.11.2013Page8/9
Plug-UP 4/11-3060212
Accessories
Shield connection clamp-PSH 3- 6-3040591
Shield connection clamp, Color:black
Shield connection clamp-PSH 5-10-3040601
Shield connection clamp, Color:black
Terminal marking
Zack Marker strip, flat-ZBF 8:UNBEDRUCKT-0808781
Zack Marker strip, flat, Strip, white, Unlabeled, Can be labeled with: Plotter, Mounting type: Snap into flat marker groove,
For terminal block width: 8 mm, Lettering field: 5.15 x 8.15 mm
Marker for terminal blocks-UC-TMF 8-0818137
Marker for terminal blocks, Sheet, white, Unlabeled, Can be labeled with: BLUEMARK CLED, BLUEMARK LED, Plotter,
Mounting type: Snap into flat marker groove, For terminal block width: 8.2 mm, Lettering field: 7.6 x 5.1 mm
Marker for terminal blocks-UCT-TMF 8-0828748
Marker for terminal blocks, Sheet, white, Unlabeled, Can be labeled with: THERMOMARK CARD PLUS, THERMOMARK
CARD, BLUEMARK CLED, BLUEMARK LED, Mounting type: Snap into flat marker groove, For terminal block width: 8.2
mm, Lettering field: 7.4 x 4.7 mm
