Datenblatt für COM_ETH-V1 Brd Manual von Infineon Technologies

Microcontroller
Hexagon Application Kit
For XMC4000 Family
Board User„s Manual
Revision 1.0, 2012-02-28
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Edition 2012-02-28
Published by
Infineon Technologies AG
81726 Munich, Germany
© 2012 Infineon Technologies AG
All Rights Reserved.
Legal Disclaimer
The information given in this document shall in no event be regarded as a guarantee of conditions or
characteristics. With respect to any examples or hints given herein, any typical values stated herein and/or any
information regarding the application of the device, Infineon Technologies hereby disclaims any and all
warranties and liabilities of any kind, including without limitation, warranties of non-infringement of intellectual
property rights of any third party.
Information
For further information on technology, delivery terms and conditions and prices, please contact the nearest
Infineon Technologies Office (www.infineon.com).
Warnings
Due to technical requirements, components may contain dangerous substances. For information on the types in
question, please contact the nearest Infineon Technologies Office.
Infineon Technologies components may be used in life-support devices or systems only with the express written
approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the
failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life
support devices or systems are intended to be implanted in the human body or to support and/or maintain and
sustain and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other
persons may be endangered.
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Template: IFX_Template_2011-02-24.dot
Revision History
Page or Item
Subjects (major changes since previous revision)
Revision 1.0,
2012-02-28
Initial release
Trademarks of Infineon Technologies AG
AURIX™, C166™, CanPAK™, CIPOS™, CIPURSE™, EconoPACK™, CoolMOS™, CoolSET™,
CORECONTROL™, CROSSAVE™, DAVE™, EasyPIM™, EconoBRIDGE™, EconoDUAL™, EconoPIM™,
EiceDRIVER™, eupec™, FCOS™, HITFET™, HybridPACK™, I²RF™, ISOFACE™, IsoPACK™, MIPAQ™,
ModSTACK™, my-d™, NovalithIC™, OptiMOS™, ORIGA™, PRIMARION™, PrimePACK™, PrimeSTACK™,
PRO-SIL™, PROFET™, RASIC™, ReverSave™, SatRIC™, SIEGET™, SINDRION™, SIPMOS™,
SmartLEWIS™, SOLID FLASH™, TEMPFET™, thinQ!™, TRENCHSTOP™, TriCore™.
Other Trademarks
Advance Design System™ (ADS) of Agilent Technologies, AMBA™, ARM™, MULTI-ICE™, KEIL™,
PRIMECELL™, REALVIEW™, THUMB™, µVision™ of ARM Limited, UK. AUTOSAR™ is licensed by
AUTOSAR development partnership. Bluetooth™ of Bluetooth SIG Inc. CAT-iq™ of DECT Forum.
COLOSSUS™, FirstGPS™ of Trimble Navigation Ltd. EMV™ of EMVCo, LLC (Visa Holdings Inc.). EPCOS™
of Epcos AG. FLEXGO™ of Microsoft Corporation. FlexRay™ is licensed by FlexRay Consortium.
HYPERTERMINAL™ of Hilgraeve Incorporated. IEC™ of Commission Electrotechnique Internationale. IrDA™
of Infrared Data Association Corporation. ISO™ of INTERNATIONAL ORGANIZATION FOR
STANDARDIZATION. MATLAB™ of MathWorks, Inc. MAXIM™ of Maxim Integrated Products, Inc.
MICROTEC™, NUCLEUS™ of Mentor Graphics Corporation. Mifare™ of NXP. MIPI™ of MIPI Alliance, Inc.
MIPS™ of MIPS Technologies, Inc., USA. muRata™ of MURATA MANUFACTURING CO., MICROWAVE
OFFICE™ (MWO) of Applied Wave Research Inc., OmniVision™ of OmniVision Technologies, Inc.
Openwave™ Openwave Systems Inc. RED HAT™ Red Hat, Inc. RFMD™ RF Micro Devices, Inc. SIRIUS™ of
Sirius Satellite Radio Inc. SOLARIS™ of Sun Microsystems, Inc. SPANSION™ of Spansion LLC Ltd.
Symbian™ of Symbian Software Limited. TAIYO YUDEN™ of Taiyo Yuden Co. TEAKLITE™ of CEVA, Inc.
TEKTRONIX™ of Tektronix Inc. TOKO™ of TOKO KABUSHIKI KAISHA TA. UNIX™ of X/Open Company
Limited. VERILOG™, PALLADIUM™ of Cadence Design Systems, Inc. VLYNQ™ of Texas Instruments
Incorporated. VXWORKS™, WIND RIVER™ of WIND RIVER SYSTEMS, INC. ZETEX™ of Diodes Zetex
Limited.
Last Trademarks Update 2011-02-24
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Table of Contents
Board Users Manual 4 Revision 1.0, 2012-02-28
Table of Contents
1 Overview ............................................................................................................................................. 7
1.1 Key Features ........................................................................................................................................ 7
1.2 Block Diagram ...................................................................................................................................... 8
2 Hardware Description ........................................................................................................................ 9
2.1 Ethernet ................................................................................................................................................ 9
2.2 CAN .................................................................................................................................................... 11
2.3 RS485/CAN Boot Loader ................................................................................................................... 12
2.4 IO Expander ....................................................................................................................................... 13
2.5 Power ................................................................................................................................................. 13
2.6 Satellite Connector ............................................................................................................................. 15
3 Production Data................................................................................................................................ 16
3.1 Schematics ......................................................................................................................................... 16
3.2 Layout and Geometry ......................................................................................................................... 19
3.3 Bill of Material ..................................................................................................................................... 20
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
List of Figures
Board Users Manual 5 Revision 1.0, 2012-02-28
List of Figures
Figure 1 Block Diagram of the Ethernet/CAN/RS485 Interface Card ................................................................ 8
Figure 2 Ethernet/CAN/RS485 Interfaces Card (COM_ETH-V1)....................................................................... 9
Figure 3 Ethernet Interface ................................................................................................................................. 9
Figure 4 CAN Interface ..................................................................................................................................... 11
Figure 5 RS485/CAN BootLoader .................................................................................................................... 12
Figure 6 Power Cirucit ...................................................................................................................................... 14
Figure 7 Power LED‟s ....................................................................................................................................... 14
Figure 8 COM Satellite Connector ................................................................................................................... 15
Figure 9 Satellite Connector Type COM .......................................................................................................... 15
Figure 10 Satellite Connector, I2C-GPIO, Power ............................................................................................... 17
Figure 11 Ethernet, CAN, RS485 ....................................................................................................................... 18
Figure 12 Ethernet/CAN/RS485 Interfaces Card Layout ................................................................................... 19
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
List of Tables
Board Users Manual 6 Revision 1.0, 2012-02-28
List of Tables
Table 1 RJ45 Connector Pinout ...................................................................................................................... 10
Table 2 Ethernet signal connection to the Satellite Connector ....................................................................... 10
Table 3 CAN Connector Pinout (X320) ........................................................................................................... 11
Table 4 CAN signal connection to the Satellite Connector ............................................................................. 11
Table 5 RS485 Connector Pinout (X331) ........................................................................................................ 12
Table 6 CAN Connector Pinout (X330) ........................................................................................................... 12
Table 7 RS485/CAN signal connection to the Satellite Connector ................................................................. 13
Table 8 GPIO channel LED/SMD pad mapping .............................................................................................. 13
Table 9 IO Expander I2C signal connection to the Satellite Connector .......................................................... 13
Table 10 Power LED‟s ....................................................................................................................................... 14
Table 11 PowerScale Jumper ........................................................................................................................... 14
Table 12 Power connection to the Satellite Connector ..................................................................................... 15
Table 13 Ethernet/CAN/RS485 Interfaces Card BOM ...................................................................................... 20
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Overview
Board Users Manual 7 Revision 1.0, 2012-02-28
Introduction
This document describes the features and hardware details of the Ethernet/CAN/RS485 Interface Card
(COM_ETH-V1) designed to work with Infineon‟s XMC4500 CPU board. This board is part of Infineon‟s
Hexagon Application Kits.
1 Overview
The COM_ETH-V1 board is an application expansion satellite card of the Hexagon Application Kits. The satellite
card along with a CPU board (e.g. CPU_45A-V2 board) demonstrates the communication capabilities of
XMC4500. The main use case for this satellite card is to demonstrate the communication features of XMC4500
device including the toolchain. The focus is safe operation under evaluation conditions. The satellite card is not
cost optimized and cannot be seen as reference design.
1.1 Key Features
The COM_ETH-V1 satellite card is equipped with following features
Connection to CPU board (e.g. CPU_45A-V2) via satellite connector COM
10/100Mbps Ethernet (RJ45)
CAN transceiver with CAN connector (DE-9 male)
RS-485 transceiver, full-duplex, bootable (DE-9 female)
CAN transceiver, bootable (4-pin header)
I2C based IO expander with 8 channels
Power supply
o Powerjack for external 24 V supply
o From CPU board via COM satellite connector
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Overview
Board Users Manual 8 Revision 1.0, 2012-02-28
1.2 Block Diagram
Figure 1 shows the block diagram of the COM_ETH-V1 satellite card. There are following building blocks:
Figure 1 Block Diagram of the Ethernet/CAN/RS485 Interface Card
Inflneon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Hardware Description
Board Users Manual 9 Revision 1.0, 2012-02-28
2 Hardware Description
The following sections give a detailed description of the hardware and how it can be used.
Figure 2 Ethernet/CAN/RS485 Interfaces Card (COM_ETH-V1)
2.1 Ethernet
The COM_ETH-V1 satellite card supports RJ45 jack with magnetic on board for communication to LAN. On
board PHY device DP83848CVV is connected to the CPU via a RMII.
A 50 MHz crystal oscillator is used on board to generate the clock required by the RMII interface.
Figure 3 Ethernet Interface
RS485 Connector
(DE-9)
I2C I/O Expander
GPIO LEDs
Power Indicating
LEDs
COM Satellite
Connector
Power 3.3 V
(IFX1763SJV33)
CAN Tranceiver
(TLE6250GV33)
&
4-Pin Header
RS485 Transceiver
(ADM3074EARZ)
CAN Connector
(DB-9)
CAN Transceiver
(TLE6250GV33)
Ethernet PHY
(DP83848CVV)
Ethernet Jack
(RJ45)
Power 5 V
(IFX91041EJV)
Power Jack
(24 V)
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Hardware Description
Board Users Manual 10 Revision 1.0, 2012-02-28
Table 1 below gives the signal details of RJ45 connector.
Table 1 RJ45 Connector Pinout
Pin No.
Signal Name
Description
1
TD+
Tranmit Data Plus
2
TD-
Tranmit Data Minus
3
RD+
Receive Data Plus
4
NC
No Connection
5
NC
No Connection
6
RD-
Receive Data Minus
7
NC
No Connection
8
NC
No Connection
Table 2 shows the connection of the Ethernet signals to the COM satellite connector.
Table 2 Ethernet signal connection to the Satellite Connector
Pin No.
Signal Name
Description
22
ETH_REF_CLK
Clock
21
ETH_TXD0
Tansmit Data 0
14
ETH_TXD1
Tansmit Data 1
16
ETH_TXEN
Tansmit Enable
15
ETH_RXD0
Receive Data 0
13
ETH_RXD1
Receive Data 1
18
ETH_CRS_DV
Receive Data Valid
20
ETH_RXER
Receive Error
19
ETH_MDC
Management Clock
17
ETH_MDIO
Management Data
Inflneon B a > g m 9 m 9 <1 ('1="" m="" —="" i]="" d="" n="" o="" a="" e="" g=""> > U320 3 vcc GND ‘7”:er D 5 vaav a H 2 Q i 5 Wu R320 as ._. vmmqm o ‘ 1 '— ‘20Reosos 5 m) CANH A RXD CANL TLEazsonea 3321 --‘ODnFrDSDS EAR) (SN—D €th 6qu GND GND
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Hardware Description
Board Users Manual 11 Revision 1.0, 2012-02-28
2.2 CAN
The COM_ETH-V1 satellite card supports a CAN interface on board via a DE-9 connector (X320). A CAN
transciever (U320) is connected to the CPU via the 80-pin satellite connector.
The CAN bus on board has a 120 Ohm termination resistor.
Figure 4 CAN Interface
Table 3 gives the details of CAN connector pin mapping.
Table 3 CAN Connector Pinout (X320)
Pin No.
Signal Name
Description
1
NC
No Connection
2
CANL
CAN Low
3
GND
Ground
4
NC
No Connection
5
NC
No Connection
6
GND
Ground
7
CANH
CAN High
8
NC
No Connection
9
VDD
5 V
Table 4 shows the connection of the CAN signals to the COM satellite connector.
Table 4 CAN signal connection to the Satellite Connector
Pin No.
Signal Name
Description
28
CAN_TXD
CAN Transmit Data
30
CAN_RXD
CAN Receive Data
Inflneon g um 5’ g é V“ em 6 » H 3 A5 a ”£9 2 > > > JW‘ U33“ SM 5.11 A m we 3—. ‘ .a ‘ a ) ”<1“ §="" fl="" ..="" .a="" w="" “5.5mm="" a="" ,="" ma="" ,5="" a="" 0‘="" _="" g="" g="" mm="" ,1="" 5'="" ‘="" caw="" w="" l="" 1="" amp="" a="" ;="" g="" ylegzsugvgs="" g,="" 1="" 7nd="" gnhsnd="" w="" r="" ‘="" e="" a="" g="" cm_="" cam="" ,="" g="" g="" mamm—="" mama:="" $3533="" gnu="" _d="" gun="" 0="">
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Hardware Description
Board Users Manual 12 Revision 1.0, 2012-02-28
2.3 RS485/CAN Boot Loader
The COM_ETH-V1 satellite card supports RS485 interface via a DE-9 connector (X331). The satellite card uses
a RS485 transciever (U331) connected to the CPU via the 80-pin satellite connector.
Table 5 gives the details of RS485 connector pin mapping.
Table 5 RS485 Connector Pinout (X331)
Pin No.
Signal Name
Description
1
NC
No Connection
2
TX+
Transmit Data Plus
3
GND
Ground
4
RX+
Receive Data Plus
5
NC
No Connection
6
NC
No Connection
7
TX-
Transmit Data Minus
8
RX-
Receive Data Minus
9
NC
No Connection
The COM satellite card supports booting of the CPU via RS485 (default) or CAN. Boot option can be chosen
using the solder jumpers SJ1/SJ2. SJ2 (RS485) is closed by default. For booting through CAN use connector
X330, for booting through RS485 use connector X331.
Figure 5 RS485/CAN BootLoader
Table 6 CAN Connector Pinout (X330)
Pin No.
Signal Name
Description
1
VDD
5 V
2
CANH
CAN High
3
CANL
CAN Low
4
GND
Ground
Both RS485 as well as CAN bus have a 120 Ohm termination resistor.
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Hardware Description
Board Users Manual 13 Revision 1.0, 2012-02-28
Table 7 shows the connection of the RS485/CAN signals to the COM satellite connector.
Table 7 RS485/CAN signal connection to the Satellite Connector
Pin No.
Signal Name
Description
29
ASC_TXD
ASC Transmit Data
27
ASC RXD
ASC Receive Data
2.4 IO Expander
The COM_ETH-V1 satellite card supports GPIO expansion though I2C IO-Expander on board (U230). The I2C
address for the IO expander device is 0x1001100X. The satellite card supports 8 such GPIO‟s. All the GPIO‟s
are connected to LEDs (V230-V237) and SMD-Pads (TP230 – TP237). The table below gives the GPIO channel
and corresponding LED/PAD mapping.
Table 8 GPIO channel LED/SMD pad mapping
GPIO
LED reference
SMD pad Reference
GPIO0
V230
TP230
GPIO1
V231
TP231
GPIO2
V232
TP232
GPIO3
V233
TP233
GPIO4
V234
TP234
GPIO5
V235
TP235
GPIO6
V236
TP236
GPIO7
V237
TP237
Table 9 shows the connection of the IO Expander device to the COM satellite connector.
Table 9 IO Expander I2C signal connection to the Satellite Connector
Pin No.
Signal Name
Description
38
I2C_SCL
I2C Clock
37
I2C_SDA
I2C Data
2.5 Power
The COM_ETH-V1 satellite card can be supplied by an external power supply (24 V / 1 A) to be connected to
the power jack X240 or by a 5 V supply via the 80-pin COM satellite connector. An external power supply is
necessary only in case the current coming via the COM satellite connector is not sufficient.
A DC-DC converter on board (U240) steps down the input voltage from the power jack X240 to 5 V (VDD5). The
input voltage can be in the range from 12 V to 24 V. An on board linear voltage regulator is generating a 3.3 V
(VDD3.3) power supply out of the VDD5.
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Hardware Description
Board Users Manual 14 Revision 1.0, 2012-02-28
Figure 6 Power Cirucit
A Diode V242 protects the reverse flow of current to an external source. Therefore a simultaneous power supply
of the satellite boards via both the power jack and the satellite connector with not harm.
LED V210 indicates the presence of 5 V power and LED V211 indicates the presence of 3.3 V power.
Table 10 Power LED’s
LED
Power Rail
Voltage
Note
V210
VDD5
5 V
Must always be “ON”
V211
VDD3.3
3.3 V
Must always be “ON”
Figure 7 Power LED’s
The COM_ETH-V1 satellite card supports a PowerScale probe for power measurement purpose.
Table 11 PowerScale Jumper
Jumper
Function
Description
JP242
PowerScale
At this point a Hitex PowerScale probe can be connected for current
sensing VDD (complete power delivered by U240)
Default: pos. 1-2 (closed)
Note: On the PCB bottom side there will be a shorting trace between pin 1-
2. This trace has to be cut first, before using PowerScale
Ethernet/CAN/RS485 Interface Card
COM_ETH-V1
COM Sat. Connector
U250
+5V
VDD5
VDD3.3
+5 V
Power Jack
(24 V)
DC/DC
Converter
IFX91041
U240
On board
devices
V242
VDD24 Lin. Voltage
Regulator
IFX1763
VDD5
VDD3.3
+3.3 V
VDD5
3.3 V LED (V211)
5 V LED (V210)
I! 454749515355575861535557697173757779 2 973mm 2 972mm 2 93mm 2 93mm 2 93mm 2 972mm 2 93mm 2 972mm 2 972mm 2 93mm 2 972mm 2 93mm 2 973mm 2 93mm 2 973mm 2 973$ «73$ 2 «72$ 2 <7ij 2="" «73$="" 2="" «73$="" 2="" «73$="" 2=""><7an 2="" «72$="" 2="" 37:3="" 2="" 67:2="" 2="" 23e="" 2="" 23e="" 2="" 933="" 2="" 5575="" 2="" 9m”.="" 2="" 4648505254565860626466637072747678="" meon="" #mwmk="" 30‘200="" nmn="" 9%="" ”$28="" ene?="" 38="" 335="" i="" xdmxim="" smuxim="" e="" udimjuu:="" 93733="" 9&qu="" 2th="" nxfiufl="" n="">mm Enxuw< e.="" e="" 53715="" 25.6="" 25.6="" sifm="" 9:="" b="" emu="" s="" 55="" .0="" emv="" e="" 55="" 1113151719="" 27="" 23="" 25="" 27="" 29="" a7="" 33="" 35="" a7="" 39="" 47="" 43="" w1214161820222426283fl3234363840¢244="" emmi="" 3="" 357g="" xdm‘imu="" z468="" o="" .="" ,:.="" nuclmményl="" mean="" if="" cm_45a="" v2="" funmcm="" »="" connennr="" mus="" »="" opujsa="" v2="" function="" »="">
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Hardware Description
Board Users Manual 15 Revision 1.0, 2012-02-28
Table 12 shows the power connection to to the COM satellite connector.
Table 12 Power connection to the Satellite Connector
Pin No.
Signal Name
Description
43,44,45,46
VDD5
5 V
1,2,24,61,79,80
GND
Ground
2.6 Satellite Connector
The satellite connector of the COM_ETH-V1 satellite card interfaces it‟s the signals to a CPU board e.g.
CPU_45A-V2. Take care to connect the COM satellite card always to the corresponding COM satellite
connector of the CPU board only.
Figure 8 COM Satellite Connector
The signal mapping details of the COM satellite connector and the correponding CPU function are provided in
Figure 9
Figure 9 Satellite Connector Type COM
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Production Data
Board Users Manual 16 Revision 1.0, 2012-02-28
3 Production Data
3.1 Schematics
This chapter contains the schematics for the Ethernet/CAN/RS485 Interface Card:
Satellite Connector, IO Expander, Power
Ethernet, CAN, RS485
‘m‘ w L ‘m ‘ . ‘ m ‘ N F H ON 5% hflgfifi $2: $23 ; fig" S‘Ega Essa. imam .23 9565 k am 25535 >zr , E as. , 2 a .5". :8 Ag. 2% , a M” a E E. , @ij m: x‘w3mfiw.®m‘w§w.a‘ g 3r L n m“ w; m. u m. w: a; a. w". s a mam u“ mmaaummvmwmwuuawmummm»; m mmwmfmmimwnmmmfimfimmummm 2 Wm EMAthmAemAzmAJAKMAimA E m m m m m m m m m w t c I c c g c c a 53.2? mm “ " Wm w m w Hm _ s a E as E E m m m H H c: m m n m n E Snag mu 3 :35: M m M m wfl v41 m m . um um mHm “HA “W A . a: “H a s m i. x: .e z, “W m“ m m an: m nu Nu m m m .n Um Inlélllllalél IIIIIIIIIIIIIII nus IIIII nuzflllozualamlauglymlwm IIIIII m u . Z fin“ a 2% w W m Wmm mm m W mm m n m m m m .n J m 3% m. E M EA “WM Him m a a 5313. in?“ any“ w. {w a n a U ”M M a 2.5 , m m m 5 m W w m m , m m m , s ; $35.: , 5E§Eg§ m . , , « Infineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Production Data
Board Users Manual 17 Revision 1.0, 2012-02-28
Figure 10 Satellite Connector, I2C-GPIO, Power
Ineon f . . . m . a N . Sig 28:552.... ‘32.... 2.2.... I —— |§EEB at. m . 3.32.... :22... m . . ... .s M H... p. .0 52...... w m w . 22.2.... nu m . . u. 2...... .. m“ 225.22.. .. z. . 52...... .2 1 m. ....|. .3 A: . {J 5. s :2 .1... . . . 1.5 2... Beam 1 . Jo . w 23...... . 1 . a: . 3... . 2 3.. . w 5. ... . “m m m S . m .2 . w a a 1.1.. .2. . ... .241 _. 52.2. m m a. m H . m .... m m u s s m; s u .5 m m H w H... , m. z m m . m m m m . m . 5.3.3. . 25.2.... “““““““““““““““““““““““““““ k1}l}11111111111} P. a..o .5. 5 a... 5.0 ex W m m 7 m a 2...... mum mum .u. 2.. m .. m .. m . m .. . w . 55E. . «gm. 2.... 2...... w 2... . fl 2 2 41 EE w 7.1% i. e . G .r 2.2 2...... .. .. .3 . .ldqflwnmlflv E. a . :11... .9 _ 28.... laws... . ”TI... 2 h .22. 3.. :28 w. www.mmm 17$ m “$5.1 m.m. memmmmm. 1m. WWW... . L m L m m m w m c c 2 c c m m m m m m. m m m m m m m m w ¢ « 0/,— In
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Production Data
Board Users Manual 18 Revision 1.0, 2012-02-28
Figure 11 Ethernet, CAN, RS485
EYR I Wow: ‘3 *7 man ; n 0000 025, $333M“ B mu _3 i .52 a :63 m 3 35: n- aklu m all.“ u E+ . H- H- H- ? away n H- u n m E. E Est 5? mm a: a” @mfifi
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Production Data
Board Users Manual 19 Revision 1.0, 2012-02-28
3.2 Layout and Geometry
Figure 12 Ethernet/CAN/RS485 Interfaces Card Layout
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Production Data
Board Users Manual 20 Revision 1.0, 2012-02-28
3.3 Bill of Material
Table 13 Ethernet/CAN/RS485 Interfaces Card BOM
Sl. No.
Qty
Value
Device
Reference Designator
1
1
0R/0402
Resistor
SJ2
2
3
0R/0603
Resistor
R254, R311, R312
3
1
0R/0805
Resistor
R241
4
3
1k5/0603
Resistor
R210, R230, R301
5
1
1k8/0603
Resistor
R244
6
13
2k2/0603
Resistor
R231, R232, R233, R234, R235,
R236, R237, R238, R302, R305,
R306, R314, R316
7
1
4k87/0603
Resistor
R304
8
2
10k/0603
Resistor
R303, R331
9
2
10uF/10V/0805
Capacitor
C250, C252
10
1
10uF/T/10V/A
Capacitor
C305
11
1
14k/0603
Resistor
R245
12
2
22R/0603
Resistor
R300, R317
13
1
22k/0603
Resistor
R243
14
1
22nF/0603
Capacitor
C242
15
1
33uH/3.2A
Inductor,
IHLP3232DZER330M11
Vishay/Dale
L240
16
1
47uF/E/50V/6.6
Capacitor,
UWT1H470MCL1GS
Nichicon
C240
17
4
49R9/0603
Resistor
R307, R308, R309, R310
18
1
50MHZ/VX3MH
Crystal, 50MHz 3,3V
7x5mm
Q300
19
1
100k/0603
Resistor
R242
20
21
100nF/0603
Resistor
C200, C202, C230, C241, C245,
C246, C253, C300, C301, C302,
C303, C304, C306, C307, C308,
C309, C320, C321, C330, C331, C332
21
1
100uF/T/10V/C
Capacitor
C244
22
2
120R/0603
Resistor
R313, R315
23
3
120R/0805
Resistor
R320, R330, R332
24
1
220nF/0603
Capacitor
C243
25
1
470pF/0603
Capacitor
C247
26
1
680R/0603
Resistor
R211
27
1
ADM3074E
IC, ADM3074EARZ
Analog Devices
U331
28
2
B340A-13-F
Diode, B340A-13-F
Diodes Inc.
V241, V242
29
1
BUCHSE-LP-5A
Connector RAPC722X
X240
30
1
DP83848CVV
IC DP83848CVV
National Semiconductor
U300
31
1
F09-SLIM
Connector DSUB9-
X331
(ifineon
COM_ETH-V1
Ethernet/CAN/RS485 Interface Card
Production Data
Board Users Manual 21 Revision 1.0, 2012-02-28
Table 13 Ethernet/CAN/RS485 Interfaces Card BOM
Sl. No.
Qty
Value
Device
Reference Designator
Female
32
1
HSEC8-140-01-S-
RA
Connector HSEC8-140-
01-S-RA Samtec
X200
33
1
IFX1763SJV33
IC IFX1763SJV33
Infineon Technologies
U250
34
1
IFX91041EJV
IC IFX91041EJV
Infineon PSOP-8 Vvar
U240
35
8
LED-GE/D/0603
LED
V230, V231, V232, V233, V234, V235,
V236, V237
36
2
LED-GN/D/0603
LED
V210, V211
37
1
M09-SLIM
Connector DSUB9-Male
X320
38
1
PCA9502
IC PCA9502BS NXP,
HVQFN-24
U230
39
1
RJ45/J0026
Connector
J0026D21BNL Pulse
X300
40
2
TLE6250GV33
IC TLE6250GV33
Infineon Technologies
U320, U330
41
1
W1*4
Connector Pinheader
0.1" TH
X330
42
1
no ass./0R/0603
Resistor
R253
43
1
no ass./0R/0805
Resistor
R321
44
2
no ass./2k2/0603
Resistor
R220, R221
45
1
no ass./10nF/0603
Capacitor
C251
46
1
no ass./0R/0402
SMD-Pads
SJ1
47
1
no ass.
Pinheader 0.1" TH, Hitex
PowerScale
JP242
48
12
no ass.
SMD-Pads
TP200, TP210, TP211, TP212, TP230,
TP231, TP232, TP233, TP234, TP235,
TP236, TP237
w w w . i n f i n e o n . c o m
Published by Infineon Technologies AG
