AUTOMATION
IB IL AI 2-HART (-PAC)
Data Sheet
1 Function Description
The terminal is designed for use within an Inline station. It
allows communication with smart field devices using the
standardized communication protocols INTERBUS and
HART. It provides both analog and digital communication.
The analog signal transmits the process information. The
modulated digital signal enables bidirectional
communication to the sensor (with HART capabilities) at the
same time.
Features
– Two differential analog signal inputs to connect current
signals
– Sensors are connected using 2-wire technology
(active and passive sensors)
– Two differential analog signal inputs to connect current
signals
– Current measuring range: 4 mA ... 20 mA
– By default, both channels are set to the measuring
range 4 mA to 20 mA (IB IL format)
– HART protocol transmission using PCP
– Hand-held connection possible
– Measured values can be represented in three different
formats
– 16-bit analog/digital converter
–Resolution depends on the representation format and
the measuring range
– Diagnostic indication
– Point-to-point and multi-drop connections possible
– Approved for the use in potentially explosive areas
(observe the notes on page 7)
Inline Terminal
With 2 Analog Input Channels and
HART Functions
This data sheet is only valid in association with the IL SYS INST UM E user manual or the Inline system manual for
your bus system.
A function block for easy terminal handling can be downloaded at www.download.phoenixcontact.com.
Make sure you always use the latest documentation.
It can be downloaded at www.download.phoenixcontact.com.
A conversion table is available on the Internet at
www.download.phoenixcontact.com/general/7000_en_00.pdf.
This data sheet is valid for the products listed on the following page:
4 x
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 2
2Table of Contents
1 Function Description................................................................................................................... 1
2 Table of Contents ....................................................................................................................... 2
3 Ordering Data ............................................................................................................................. 3
4 Technical Data............................................................................................................................ 4
5 Local Diagnostic Indicators and Terminal Point Assignment....................................................... 6
5.1 Local Diagnostic and Status Indicators........................................................................................................... 6
5.2 Function Identification .................................................................................................................................... 6
5.3 Terminal Point Assignment............................................................................................................................. 6
6 Installation Instructions ............................................................................................................... 6
7 Notes on Using the Terminal in Potentially Explosive Areas ....................................................... 7
8 Internal Circuit Diagram .............................................................................................................. 8
9 Electrical Isolation....................................................................................................................... 9
10 Connection Notes ....................................................................................................................... 9
10.1 Connection of the HART Devices For a Point-to-Point Connection ..............................................................10
10.2 Connection of the HART Devices in a Multidrop Network............................................................................. 10
11 Programming Data/Configuration Data ......................................................................................11
12 Process Data .............................................................................................................................11
12.1 Assignment of the Terminal Points to the Input Data (See page 12) ........................................................... 11
12.2 Process Data Input Words (IN)..................................................................................................................... 12
13 Formats for the Representation of Measured Values.................................................................13
13.1 "IB IL" Format ............................................................................................................................................... 13
13.2 "Standardized Representation" Format ........................................................................................................ 13
13.3 "PIO" Format ................................................................................................................................................ 14
13.4 Examples for Measured Value Representations........................................................................................... 14
14 HART Functions of the IB IL AI 2-HART (-PAC) Terminal .........................................................15
14.1 Recommendations For Its Use ..................................................................................................................... 15
14.2 HART Communication.................................................................................................................................. 15
14.3 HART Operating Mode (Polling/Burst) for Point-to-Point Connections and Multidrop Networks .................. 16
14.4 HART Device Addresses.............................................................................................................................. 17
15 Introduction Into FDT Technology..............................................................................................18
15.1 General Information About FDT/DTM........................................................................................................... 18
15.2 FDT and AutomationXplorer+....................................................................................................................... 18
15.3 FDT and PC WorX........................................................................................................................................ 19
15.4 Internet ......................................................................................................................................................... 20
15.5 Documentation ............................................................................................................................................. 20
15.6 Special Addressing and Connection
(e.g., Using a Hand-Held Operating Device) ................................................................................................ 20
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 3
16 Reading Data Using the HART Protocol ....................................................................................20
17 PCP Communication .................................................................................................................20
17.1 Object Dictionary .......................................................................................................................................... 21
17.2 UNIQUE_IDENTIFIER_CHANNEL1_SLAVE1 ... 5 and
UNIQUE_IDENTIFIER_CHANNEL2_SLAVE1 ... 5 Objects ......................................................................... 22
17.3 HART_PASS_THROUGH_CHANNEL1 / 2 Object...................................................................................... 23
17.4 POLL/BURST_RESPONSE_CHANNEL1_SLAVE1 ... 5 and
POLL/BURST_RESPONSE_CHANNEL2_SLAVE1 ... 5 Object .................................................................. 25
17.5 PROCESS_DATA_VALUE Object ............................................................................................................... 27
17.6 STATUS Object............................................................................................................................................ 28
17.7 CONTROL Object ........................................................................................................................................ 29
17.8 INIT_TABLE Object...................................................................................................................................... 30
18 Start Behavior ............................................................................................................................32
3Ordering Data
Products
Description Type Order No. Pcs./Pkt.
Inline terminal with 2 analog input channels with HART functions;
complete with accessories (connectors and labeling fields)
IB IL AI 2-HART-PAC 2861331 1
Inline Terminal with 2 analog input channels and HART functions;
without accessories
IB IL AI 2-HART 2860264 1
The connectors listed below are needed for the complete fitting of the IB IL AI 2-HART terminal.
Accessories
Description Type Order No. Pcs./Pkt.
Inline shield connector for analog Inline terminals IB IL SCN-6 SHIELD 2726353 5
Connector for digital single-channel, two-channel or 8-channel Inline terminals IB IL SCN-8 2726337 10
Documentation
Description Type Order No. Pcs./Pkt.
"Automation Terminals of the Inline Product Range" user manual IL SYS INST UM E 2698737 1
"Configuring and Installing the INTERBUS Inline Product Range" user manual IB IL SYS PRO UM E 2743048 1
"INTERBUS Addressing" data sheet DB GB IBS SYS ADDRESS 9000990 1
"Inline Terminals for Use in Zone 2 Potentially Explosive Areas"
application note
AH EN IL EX ZONE 2 7217 1
"Peripherals Communication Protocol (PCP)" user manual IBS SYS PCP G4 UM E 2745169 1
"Startup of a HART-Compatible Device in AutomationXplorer+"
application note
AH EN AUTOMATIONXPLORER &
HART
7603 1
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 4
4 Technical Data
General Data
Housing dimensions (width x height x depth) 48.8 mm x 120 mm x 71.5 mm
Weight 134 g (without connectors), 206 g (with connectors)
Operating mode Process data operation with 2 words and PCP operation with 2 words
Transmission speed 500 kbps
Connection method for sensors 2-wire technology
Power supply of the sensors 24 V DC, provided by the terminal
Permissible temperature (operation) -25°C … +55°C
Permissible temperature (storage/transport) -25°C … +85°C
Permissible humidity (operation/storage/transport) 10 % ... 95% according to DIN EN 61131-2
Permissible air pressure (operation/storage/transport) 70 kPa ... 106 kPa (up to 3000 m above sea level)
Degree of protection IP20
Class of protection Class III, IEC 61140
Connection data for Inline connectors
Connection type Spring-cage terminals
Conductor cross-section 0.2 mm2... 1.5 mm2 (solid or stranded), 24 - 16 AWG
Interface
Local bus Data routing
Supply of the Module Electronics and I/O Through the Bus Terminal/Power Terminal
Connection method Potential routing
Power Consumption
Communications power UL7.5 V
Current consumption from UL95 mA (typical), 110 mA (maximum)
I/O supply voltage UANA 24 V DC
Current consumption at UANA 50 mA (typical), 150 mA (maximum)
Total power consumption 1.9 W (typical)
Analog Inputs
Number 2 differential analog inputs
Signals/resolution in the process data word (quantization)
0 mA ... 25 mA (PIO format) 0.381 µA/LSB
4 mA ... 20 mA (Standardized representation format) 1.000 µA/LSB
4 mA ... 20 mA (IB IL format) 0.533 µA/LSB
Measured value representation in the following formats:
IB IL 15 bits with sign bit (see also page 13)
Standardized representation 15 bits with sign bit (see also page 13)
PIO 16 bits without sign bit (see also page 14)
Mean-value generation Using 4, 16, 32 measured values, 16 measured values by default
Conversion time of the A/D converter 10 µs, approximately
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 5
Analog Input Stages of the Current Inputs
Input resistance 250 Ω (shunt)
Limit frequency (-3 dB) of the input filters 25 Hz
Process data update of both channels Bus-synchronous
Behavior on sensor failure Going to 0 mA or 4 mA
Maximum permissible voltage between analog current inputs and analog
reference potential
±10 V (corresponds 40 mA across the sensor resistances)
Common mode rejection (CMR) 105 dB minimum
Reference: current input signal, valid for permissible DC common mode
voltage range
115 dB (typical)
Permissible DC common mode voltage for CMR 40 V between current input and FE
Maximum permissible current ±40 mA
Tolerance Behavior and Temperature Response of the Current Inputs
(The error indications refer to the measuring range final value.)
TA = 23°C
Measuring Range Absolute (Typical) Absolute (Maximum) Relative (Typical) Relative (Maximum)
4 mA ... 20 mA ±10.0 µA ±50.0 µA ±0.05% ±0.25%
0 mA ... 25 mA ±10.0 µA ±50.0 µA ±0.04% ±0.20%
TA = -25°C ... +55°C
Measuring Range Absolute (Typical) Absolute (Maximum) Relative (Typical) Relative (Maximum)
4 mA ... 20 mA ±28.0 µA ±80.0 µA ±0.14% ±0.40%
0 mA ... 25 mA ±28.0 µA ±80.0 µA ±0.11% ±0.32%
Additional Tolerances Influenced by Electromagnetic Fields
Type of Electromagnetic Interference Typical Deviation of the Measuring Range Final Value
(Current Input)
Relative
Electromagnetic fields;
Field strength 10 V/m
According to EN 61000-4-3/IEC 61000-4-3
< ±2%
Conducted interference
Class 3 (test voltage 10 V)
According to EN 61000-4-6/IEC 61000-4-6
< ±1%
Fast transients (burst)
4 kV supply, 2 kV input
According to EN 61000-4-4/IEC 61000-4-4
< ±1%
Safety Equipment
Surge voltage Suppressor diodes in the analog inputs
Electrical Isolation/Isolation of the Voltage Areas
Common Potentials
24 V main power, 24 V segment voltage, and GND have the same potential. FE is a separate potential area.
Separate Potentials in the System Consisting of Bus Terminal/Power Terminal and an I/O Terminal
Test Distance Test Voltage
5 V supply incoming remote bus/7.5 V supply (bus logic) 500 V AC, 50 Hz, 1 min
5 V supply outgoing remote bus/7.5 V supply (bus logic) 500 V AC, 50 Hz, 1 min
7.5 V supply (bus logic), 24 V supply UANA / I/O 500 V AC, 50 Hz, 1 min
7.5 V supply (bus logic), 24 V supply UANA / functional earth ground 500 V AC, 50 Hz, 1 min
I/O / functional earth ground 500 V AC, 50 Hz, 1 min
www duwmoad phoenlxcomaclcom www 25th ghoemxccmauccm
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 6
5 Local Diagnostic Indicators and
Terminal Point Assignment
Figure 1 IB IL AI 2-HART terminal with appropriate
connectors
5.1 Local Diagnostic and Status Indicators
5.2 Function Identification
Green
5.3 Terminal Point Assignment
6 Installation Instructions
High current flowing through potential jumpers UM and US
leads to a temperature rise in the potential jumpers and
inside the terminal. To keep the current flowing through the
potential jumpers of the analog terminals as low as possible,
always place the analog terminals after all the other
terminals at the end of the main circuit (sequence of the
Inline terminals: see also IL SYS INST UM E user manual or
the Inline system manual for your bus system).
Error Messages to the Higher-Level Control or Computer System
Failure of the internal voltage supply Yes
Peripheral fault/user error Yes, error message via the IN process data (see page 12)
Approvals
For the latest approvals, please visit www.download.phoenixcontact.com or www.eshop.phoenixcontact.com.
Des. Color Meaning
DGreen Diagnostics
TR Green PCP communication status
H1, H2Yellow HART communication status
T R
H 1
D
A I 2 - H A R T
H 2
6 7 5 8 B 0 0 3
1 2
1
2
3
4
1
2
3
4
1 . 1
1 . 2
1 . 3
1 . 4
2 . 1
2 . 2
2 . 3
2 . 4
1 2
1
2
3
4
1
2
3
4
1 . 1
1 . 2
1 . 3
1 . 4
2 . 1
2 . 2
2 . 3
2 . 4
14
Con-
nectors
Terminal
Points
Signal Assignment
1 1.1 +24 V 1 Sensor supply channel 1
1.2 +I1 Current input channel 1
1.3 AGND1 Analog ground channel 1
1.4, 2.4 FE Shield connection
2.2, 2.3 +I1 Hand-held operating device
Connection channel 1
2 and 3 Not used
4 1.1 +24 V 2 Sensor supply
channel 2
1.2 -I2 Current input channel 2
1.3 AGND2 Analog ground channel 2
1.4, 2.4 FE Shield connection
2.2, 2.3 +I2 Hand-held operating device
Connection channel 2
Observe the connection notes on page 9.
G
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 7
7 Notes on Using the Terminal in Potentially Explosive Areas
Approval According to EC Directive 94/9 (ATEX)
II 3G Ex nAC IIC T4 X
This Inline terminal conforms to the requirements of
protection type "n" and can be installed in a zone 2
potentially explosive area. This Inline terminal is a category
3G item of electrical equipment.
Figure 2 Typical labeling of terminals for use in
potentially explosive areas
1. When working on the Inline terminal, always disconnect
the supply voltage.
2. The Inline terminal must only be installed, started up,
and maintained by qualified specialist personnel.
3. Install the Inline terminals in a control cabinet or metal
housing. The minimum requirement for both items is
IP54 protection according to EN 60529.
4. The Inline terminal must not be subject to mechanical
strain and thermal loads, which exceed the limits
specified in the product documentation.
5. The Inline terminal must not be repaired by the user.
Repairs may only be carried out by the manufacturer.
The Inline terminal is to be replaced by an approved
terminal of the same type.
6. Only category 3G equipment may be connected to
Inline terminals in zone 2.
7. Observe all applicable standards and national safety
and accident prevention regulations for installing and
operating equipment.
Restrictions
WARNING: Explosion hazard
Only use Inline terminals that are approved
for use in potentially explosive areas.
Before using an Inline terminal in a zone 2
potentially explosive area, check that the terminal
has been approved for installation in this area.
For a list of terminals approved for use in zone 2
potentially explosive areas, please refer to the
AH EN IL EX ZONE 2 application note.
Check the labeling on the Inline terminal and the
packaging (see Figure 2).
5561C001
INTERBUS
GL
U
L
xx
Potential routing 4 A maximum
Potential routing 4 A maximum
for use in Ex areas
for use in Ex areas
II 3G Ex nAC IIC T4 X
II 3G Ex nAC IIC T4 X
LISTED
31ZN
Proc. Ctrl. Eqpt. For Haz. Locs.
Proc. Ctrl. Eqpt. For Haz. Locs.
Cl. I, Zn. 2, AEx nC IIC T5
Cl. I, Zn. 2, AEx nC IIC T5
Cl. I, Zn. 2, Ex nC IIC T5
Cl. I, Zn. 2, Ex nC IIC T5
Cl. I, Div. 2, Grp. A,B,C,D T5
Cl. I, Div. 2, Grp. A,B,C,D T5
IBx IL xx xx x
IBx IL xx xx x
Order-No.: xxxxxxx
Order-No.: xxxxxxx
Module-ID: xx HW/FW XX/-
Module-ID: xx HW/FW XX/-
WARNING: Explosion hazard
Before startup, ensure that the following
points and instructions are observed.
WARNING: Explosion hazard
When using terminals in potentially explosive
areas, observe the technical data and limit values
specified in the corresponding documentation
(user manual, data sheet, package slip).
WARNING: Explosion hazard
Restrictions regarding the Inline system
Please make sure that the maximum
permissible current of 4 A flowing through
potential jumpers UM and US (total current) is not
exceeded when using the Inline terminals in
potentially explosive areas.
Figure 3 Internal wiring ollhe terminal pOlMS Key: Protocol chip Supply unit with electrical isolation % Analog/digital converter |:| Reference voltage :y2c: Oplocoupler Other symbols used are explained in the IL SYS INST UM E user manual 675Len701
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 8
8 Internal Circuit Diagram
Figure 3 Internal wiring of the terminal points
Key:
Protocol chip Microprocessor
Supply unit with electrical isolation Electrically erasable programmable read-
only memory
Analog/digital converter Multiplexer
Reference voltage Amplifier
Optocoupler HART Modem
Other symbols used are explained in the
IL SYS INST UM E user manual.
I N T E R B U S
+ 2 4 V ( U
M
)
+ 2 4 V ( U
S
)
UL +
UA N A
UL -
E E P R O M
O P C
2 4 V
5 V
+-
R E F
2 4 V
2 4 V
5 V
H A R T
H A R T
2 4 V
2 4 V
5 V
µ P
M U X
6 7 5 8 A 0 0 7
OPC µ P
xxx
XXX
E E P R O M
M U X
R E F
H A R T
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 9
9 Electrical Isolation
Figure 4 Electrical isolation of the individual function
areas
10 Connection Notes
– Always connect analog sensors using shielded,
twisted-pair cables.
– Connect the shielding to the terminal using the shield
connection clamp. The clamp connects the shield to FE
(functional earth ground) on the terminal side.
Additional wiring is not necessary.
– Insulate the shielding at the sensor or connect it with a
high resistance and a capacitor to the PE potential.
– Use a connector with shield connection when installing
the sensors. Figure 5 and Figure 6 show the connection
schematically (without a shield connection).
Connection of the HART Devices
Please note that the connections of the HART field devices
(slaves) to the Inline-HART terminal differs for point-to-point
and multidrop connections (see 10.1 and 10.2).
Analog
input 1
Local bus (IN)
Bus interface
OPC
Local bus (OUT)
U
L
U
ANA
U
L
µC
±5 V
+24 V
+5 V
+24 V
+5 V
ADC
HART 1
HART 2
HART 1 HART 2
6758B004
24 V
U
ANA
Analog
input 2
A
B
Electrical isolation
between areas
A and B
ATTENTION:
Do not connect voltages above ±10 V to a current
input. This damages the module electronics as
the maximum permissible current of ±40 mA is
exceeded.
The information can be found in Section "HART
Operating Mode (Polling/Burst) for Point-to-Point
Connections and Multidrop Networks" on
page 16.
D0 D0 DC US EU D0, D0 D3 J-é D0 D0 D7 D)
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 10
10.1 Connection of the HART Devices For a Point-to-Point Connection
Figure 5 Connection of active sensors (slaves) in 2-wire
technology with shield connection
Figure 6 Connection of passive sensors (slaves) in 2-
wire technology with shield connection (Loop
power)
10.2 Connection of the HART Devices in a Multidrop Network
Figure 7 Connection of sensors (slaves) in a multidrop network
1 2
1
2
3
4
1
2
3
4
6758C005
IN
Address 0
6758C006
IN
24 V
1 2
1
2
3
4
1
2
3
4
Address 0
Slave 5
Slave 1
Slave 2
Slave 3
24 V
24 V
Slave 5
Slave 4
1
2
1
2
3
4
1
2
3
4
1 2 1 2 1 2
1
2
3
4
1
2
3
4
Slave 3
Slave 2
Slave 1
Slave 4
Address 1
Address 2
Address 3
Address 4
Address 5
Address 6
Address 7
Address 8
Address 9
Address 10
6758C012
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 11
11 Programming Data/Configuration Data
Local Bus (INTERBUS)Other Bus Systems
12 Process Data
12.1 Assignment of the Terminal Points to the Input Data (See page 12)
ID code DChex (220dec)
Length code 02hex
Input address area 2 words
Output address area 2 words
Parameter channel (PCP) 2 words
Register length (bus) 4 words
For the programming/configuration data of other
bus systems, please refer to the corresponding
electronic device data sheet (e.g., GSD, EDS).
For the assignment of the illustrated (byte.bit)
view to your INTERBUS control or computer
system, please refer to the
DB GB IBS SYS ADDRESS data sheet.
(Word.bit) view Word Word 0
Bit 1514131211109876543210
(Byte.bit) view Byte Byte 0 Byte 1
Bit 7654321076543210
Channel 1
(connector 1)
Signal Terminal point 1.2
Signal reference Terminal point 1.3
Shield (FE) Terminal point 1.4
(Word.bit) view Word Word 1
Bit 1514131211109876543210
(Byte.bit) view Byte Byte 0 Byte 1
Bit 7654321076543210
Channel 2
(connector 4)
Signal Terminal point 1.2
Signal reference Terminal point 1.3
Shield (FE) Terminal point 1.4
IMSB on
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 12
12.2 Process Data Input Words (IN)
The measured value 1 (main measured value) is
transmitted, per channel, to the controller board or the
computer by means of the IN process data input words.
Figure 8 Sequence of the process input data words and display of the bits of the first process data word in the different
formats
Key The "IB IL" and "standardized representation" process data
formats support extended diagnostics.
The following error codes are possible:
Please observe that the content of the IN process
data input words 1 and 2 is relevant for point-to-
point connections only. In multidrop mode, a
current value of 4 mA is indicated.
Channel 1
MSB
LSB
Channel 2
Process data word 1 Process data word 2
014 13 12 11 10 9 8 7 6 5 4 3 2 115
SB AV
014 13 12 11 10 9 8 7 6 5 4 3 2 115
OR
0/4
OC
SB AV
ST
IL,
Standardized representatio
n
Format:
5564A009
SB Sign bit
AV Analog value
MSB Most significant bit
LSB Least significant bit
Code (hex) Error
8001 Overrange
8002 Open circuit
8004 Measured value invalid/
no valid measured value available
8010 Invalid configuration
8040 Terminal faulty
8020 Supply voltage not present
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 13
13 Formats for the Representation of
Measured Values
13.1 "IB IL" Format
The "IB IL" format enables high-resolution representation of
measured values in the 4 mA ... 20 mA measuring range.
The measured value is represented in bits 14 to 0. An
additional bit (bit 15) is available as a sign bit.
This format supports extended diagnostics. Values
>8000hex and <8100hex indicate an error. The error codes
are listed on page 12.
Measured value representation in "IB IL" format (15 bits)
This format is the default format. To ensure that the terminal
can be operated in previously used data formats, the
measured value representation can be switched to other
formats.
Significant Measured Values
Measuring range 4 mA ... 20 mA
13.2 "Standardized Representation" Format
The measured values are represented in bits 14 through 0.
An additional bit (bit 15) is available as a sign bit. The
overrange limits and the open circuit threshold in the higher-
level control system can be freely defined.
In this format, data is standardized to the measuring range
and represented in such a way that it indicates the
corresponding value without conversion. In this format one
bit has the value of 1 µA.
This format supports extended diagnostics. Values
>8000hex and <8100hex indicate an error. The error codes
are listed on page 12.
Error messages occur according to the "IB IL" format. Open
circuit and short-circuit limits can be set with the PCP object
called INIT_TABLE.
Measured value representation in "standardized
representation" format (15 bits)
Significant Measured Values
Measuring range 4 mA ... 20 mA
Please note that the measured values shown are
only relevant for a point-to-point connection. In
multidrop mode a constant value is always
displayed.
15 14131211109876543210
SB AV
SB Sign bit
AV Analog value
Some codes are used for diagnostic functions.
Therefore, the resolution is not 15 bits, but exactly
calculated 14.9886847 bits.
Input Data Word
(Two's Complement)
4 mA ... 20 mA
IInput
hex dec mA
8001 Overrange > +21.339733
7F00 32512 +21.3397
7530 30000 +20.0
0001 1 +4.000533
0000 0 +4.0 to 3.2
8002 Open circuit <+3.2
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SB AV
SB Sign bit
AV Analog value
Input Data Word
(Two's Complement)
4 mA ... 20 mA
IInput
hex dec mA
8001 Overrange > +22.5 (default, value
can be defined)
4E20 20000 +20.0
8002 Open circuit <3.2 (default, value
can be defined)
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 14
13.3 "PIO" Format
PIO format enables high-resolution representation of
measured values in the 0 mA ... 25 mA current measuring
range. In this format, the measuring range of 0 mA ... 25 mA
is divided into 216quantization steps (65 536 steps). Thus,
unipolar measured currents with a resolution of 0.38 µA/
LSB can be represented. Signals between 0 mA ... 25 mA
can be aquired.
Measured value representation in "PIO" format (16 bits)
Significant Measured Values
Measuring range 0 mA ... 25 mA
13.4 Examples for Measured Value Representations
Measured value representation in various data formats.
Process data input word
Please note that error messages cannot be
displayed in this format.
15 14131211109876543210
AV
AV Analog value
Input Data Word
(Two's Complement)
PIO
IInput
hex dec mA
F5C2 62914 +24.0
CCCD 52429 +20.0
6666 26214 +10.0
0A3D 2621 +1.0
0001 1 +0.3815 µA
0000 0 +0
Measured value: 10 mA
Format hex
Value
dec
Value
Meas-
ured
Value
Measuring
Range
IB IL 3A98 15 000 10 mA 4 mA ... 20 mA
PIO 6666 26 214 10 mA 0 mA ... 25 mA
Standardized
representation
2710 10 000 10 mA 4 mA ... 20 mA
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 15
14 HART Functions of the IB IL AI 2-HART (-PAC) Terminal
14.1 Recommendations For Its Use
The following table contains notes on the use of the terminal
depending on your requirements for the application:
14.2 HART Communication
Data between masters and field devices is transmitted by
superimposing an encoded digital signal on the
4 mA ... 20 mA current loop. Thanks to the encoding without
mean value, simultaneous transmission of the analog signal
is not affected.
In accordance with the HART specification, operating
devices (masters) send a voltage signal. Field devices
(slaves) send their messages via load-independent
currents. The current signals are converted to voltage
signals at the internal resistance (i.e., its load) of the
receiver.
The signals are exchanged in accordance with the HART
protocol specified by the HART foundation. In accordance
with this master/slave procedure, the master initiates any
communication activity. Slaves only start transmission upon
request (see Figure 9).
Figure 9 Exchanging HART commands
The HART commands are transmitted as telegrams that are
structured as follows:
Application Recommendation
– A HART slave
– A measured value per HART slave
Please use the process data input words
(see Section 12 on page 11).
These process data input words contain a 16-bit measured signal
value ranging from 4 mA ... 20 mA.
– A HART slave
– Several measured values per HART slave
Use polling mode (see 14.3 on page 16).
The terminal cyclically requests measured value from the HART
slave using HART communication. These measured values are
provided by the terminal. They can be read with a PCP service.
– A HART slave
– Several measured values per HART slave
– Fastest possible update of the measured value
Use burst mode (see Section 14.3 on page 16).
The HART slave continuously sends measured values using HART
communication. These measured values are provided by the
terminal. They can be read with a PCP service.
– Several HART slaves
– Each HART slave offers the same number of
measured values
Use the polling mode (see 14.3 on page 16).
The terminal cyclically requests measured values from each HART
slave using HART communication. These measured values are
provided by the terminal. They can be read with a PCP service.
– Unrestricted access to a HART slave Use the PASS_THROUGH mechanism
(see Section 17.3 on page 23) to directly communicate with each
HART device using HART communication. Please note that the
HART telegram needs to be imbedded into the PCP telegram.
The HART specification allows for two masters,
i.e. usually the HART operating device as primary
master and a hand-held operator panel as
secondary master.
Master
Slave
Master command with data, if req.
Slave response telegram with data
6758C024
www.hancomm org
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 16
The HART Telegram Structure
Key:
Structure of the AD Address for Long Addresses:
Long address (5 bytes)
Further information on the HART topic can be downloaded
from the homepage of the HCF user organization (HART
COMMUNICATION FOUNDATION) at www.hartcomm.org
The HART protocol can be implemented by any
manufacturer and it can be freely used by any user. This
open communication protocol between operating and field
device is supported by the HART Communication
Foundation (HCF). The HCF also provides technical
support for the user. Among other things, the HCF monitors
the openness of the protocol and manages device
descriptions of all devices approved for operation.
.
HART and HCF logo
14.3 HART Operating Mode (Polling/Burst) for Point-
to-Point Connections and Multidrop Networks
Point-to-Point Connection (PTP)
For a point-to-point connection, connect a HART field
device (slave) to the HART operating device (master). The
master communicates with precisely one HART device via
one pair of wires. For this reason, the device address "0"
must be set for the HART field device (cf. Figure 5 and
Figure 6 on page 10).
Multidrop Network
In a multidrop network, the HART operating device
communicates with up to 5 HART field devices being
connected in parallel to the master via an individual wire pair
each (cf. Figure 7). The device address of each slave
determines which slave is addressed by the master. This
device address is to be preset according to the range from
1 to 15. Please make sure
– NOT to set the device address "0" for slaves
– NOT to assign device addresses twice.
Burst Mode Operation
Burst mode operation is only possible for point-to-point
connections. Here the slave is requested by the master to
send a standard HART response telegram (burst telegram).
This burst telegram is sent continuously by the HART slave
until the master cancels the request.
The command number of the response is variable and is
transmitted via the CONTROL object. This command
number is sent to the HART slave via command 108. After
this, burst mode operation is enabled via command 109.
The current response can be read via the POLL/
BURST_RESPONSE_CHANNEL_x_SLAVE_1 object.
In this operating mode a timeout is maintained:
If no response telegram is received within 800 ms, the
object length is set to 0.
When sending the burst command number or the burst
enter command, the first status byte of the response is
checked. If the HART device responds negatively to
commands 108 or 109, the response is made available in
Preamble SC AD HC BC ST DA CS
x1
byte
5
bytes
1
byte
1
byte
2
bytes xx xxx
Preamble: The preamble is used to synchronize the
HART devices.
SC: Start byte
The start byte indicates the sender (master,
slave, slave in burst mode) and whether a long
or a short address is used.
AD: Address
Length: 5 bytes = long address
1 byte = short address
Via this address the two masters are
distinguished, burst telegrams and field
devices are identified.
HC: HART command
The HART command encodes the master's
commands.
BC: Byte count = ST + DA
This byte indicates the number of transmitted
status and data bytes.
ST: Status
The response message of a HART slave
contains two status bytes. It indicates whether
the data was received without errors (= 0) and
the current field device status.
DA: Data
The maximum data length is 26 bytes,
depending on the HART command.
CS: Checksum of the entire telegram.
Master Burst Bit 31, 30, 29, ...0
s depends on the ands supported device- urer. ZLé Figure 10 (In U I] |:l D D A Connecting a hand-heid op address modiiication 675Len701 PH
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 17
the POLL/BURST_RESPONSE_CHANNEL_x_SLAVE_1
object and the 'Burst trouble' bit is set in the STATUS object.
This can be the case when the HART slave does not support
burst mode operation.
Polling Mode Operation
In polling mode operation the Inline-HART terminal
automatically sends HART commands to all HART slaves
present at the same channel. Only HART commands 1, 2,
and 3 are permitted. The current polling response can be
read in the POLL_RESPONSE_CHANNEL_x_SLAVE_x
object.
If a slave sends a faulty HART response to the master, the
corresponding slave is polled once again. A total of two
polling trials are admissible. After the third faulty response,
the object length is set to 0 and the next slave is polled.
The HART Command Scope
The scope of possible HART commands depends on the
HART field device used. For a list of commands supported
by your HART field device, please refer to the device-
specific documentation of the device manufacturer.
14.4 HART Device Addresses
Setting the Device Address
There are several ways of setting the device addresses:
– Use the AutomationXplorer+ or PC WorX software
offered by Phoenix Contact or
– Set the device addresses with a hand-held operating
device (cf. Figure 10) or
– Contact the manufacturer of the HART field devices
used.
The default setting of the device addresses of the field
devices is always "0". Therefore the devices are preset to
point-to-point operation.
For setting the device addresses of a HART field device
connect a hand-held operating device to terminal points
2.2 and 2.3:
Figure 10 Connecting a hand-held operating device for
address modification
6758B013
IN
www Id gvoup org , Aumnmmnxumm. a 9 WWW E I M 3m ETH ZTWB E ,5 mama j 5 ya my may w .HARY mm :3: Beneyyc may Demo: “17'- HARY Ehannsy2 u a PRUFymmnPy/y E m chm j l naps Myzyuumz a a: yumnmen I wyya a: m my when a m my when & yu my :mm a L Vfiurymmnwy p ”.1 mm a I mm a a yByLAyzHAHYDYM M mm :may I Emmy om w my Ehamd 2 Rsad/ Mum Ay ya yLAEI y/sr ya yLAEI y/u/sr ya yLAEI 2mm: ya yLAEI Z/U/BPME ya yLAEI 2/5: ya yLAEI MEN/BF ya My 2/5; ya My 2/3; ME ya My 2/5: an ya My 2/» 2mm ya My 2 HART ya My m; ya My m ya \L rm 2 ND ya yL rm 2 RID/3m] ya yL rm us mo ya yuzwzuw ¥ ya y m: ya yL mm mm 3A ya yuunELRRsA ya \L mu MLR ya: ya chNy ya m: ya yL w: w ya yLSSy ya yL ssy w C:\Dukumelyle um Emsleuunzenlvlrmm\Elzene Damyenweyne rm PrnlekIuFDTKr-fleyfl91m 7.9mm mum nw >< —\madu|auswam="" ipaamm="" slaymsadyessz="" li="" 52m="" yim="" my="" :ymbyzwmdlg="" mm="" mm,="" ammm="" ’7="" mayhem/ww="" dab="" m="" an.="" www/ww="" dab="" yr="" a“.="" maxyengyhaymvm="" m="" w="" em="" lengyhaymvm="" m="" yin="" evy:="" mysngwwmm="" yr.="" a“.="" lsngyhoyompmdata="" yr="" a“.="" max="" numha="" a="" mug,="" fa="" mm,="" m="" madubs="" yr="" s‘nanavu="" 9k="" mum="" ya="" yl="" zwu="" 5="" ya="" my="" 2mm="" ya="" my="" my="" ya="" ylaei="" 2/5:="" flla="" may="" .="" am="" i="" a="" ylayzhart="" mm="" lflsfbmyzyuumyz="" mummy="" um="" imam="" ow="" ill="" flm="" rkpr="" w2dy8="" w2dtm="" i="" ynyeraus="" emmmycahm="" mm="" [jrruanwa="" flmasn="" pry="" uh="" flmzmrcy="" lawn="" flfifuanemya="" .ylersueth="" iymznnya="" flch2nuuny="" .ylesmeth="" 7008="" a="" yassmunmosmy="" flysteyse/ry/yy="" mamas/m="" yrsysase/ry/rylk="" (y="" my="" y="">y schAE SoHyry AIS
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 18
15 Introduction Into FDT Technology
15.1 General Information About FDT/DTM
FDT (Field Device Tool) is the name of the software
specification that standardizes the fieldbus-independent
configuration, parameterization, and diagnostics of devices
in an automation network.
The device manufacturer provides device-specific drivers,
the DTMs (Device Type Managers). The DTM of a device
contains the device description and a device-specific user
interface, for example. The DTM is used to integrate a
device into the automation network using an FDT framework
application (also known as FDT container software).
Phoenix Contact is a member of the FDT Group
(www.fdt-group.org). Compatibility of the DTM provided by
Phoenix Contact for the IB IL AI 2-HART Inline terminal with
FDT specification 1.2 has been tested and certified.
15.2 FDT and AutomationXplorer+
The AutomationXplorer+ software is an FDT framework
application, in which DTMs from various manufacturers can
be integrated. Point-to-point communication, even beyond
network boundaries, enables user-friendly parameterization
and diagnostics of devices and sensors/actuators via,
e.g., Ethernet, INTERBUS, Profibus, HART, and in future
PROFINET IO or IO Link protocol.
Figure 11 shows on the left-hand side (Project Tree) the bus
structure with the communication, gateway and device
DTMs installed.
The DTM for the Inline-Profibus bus coupler is shown in the
middle part. The Inline-Profibus bus coupler and the Inline
station are configured and diagnosed in this part.
The DTM catalog is displayed on the right-hand side, sorted
by device manufacturers as shown.
Figure 11 AutomationXplorer+
2 \ magma \aa‘ufimwaam jammfiol‘ Hu-‘HIE‘ a punk: IL HE mm wwcrmhma m 72+ a: mamdl I ncasuzm m) we m 12 ms H New/W ‘62 M mm R MM: mung. mmmmn mm W9 a I ,t x m A. 27min: mm) D x mmmywr mam mm Demwve wemv'mmz Emmy m Endress+Hanser EST I ncamim zrmn m 192 mu n 2 Mm mm m mmmmw R Ressmme afixxmfinauSu n Mum“; a 5n n I x 1 m m 2mm: mm) H 1 mwwm mzyvx Dam mm 7 a [—j? . - mm fl 5 ‘w 5‘ “m” ’“ “”3“” ‘ R srummvcfl E, was“ SW 51 M. . i : 5mm 3mm er‘mwmn 51 nun m L E a 5mm x Ffigmm offsetsmsan nun d=q< l="" :="" mu="" mom="" memmm="" l—m="" in="" 3mm="" 5%,.="" mam;="" [—ng="" su="" aegz="" 0="" mm“="" s="" 52¢:me="" emma",="" send="" m="" 5|="" 1="" 1="" 2mm="" 2.="" wu="" a="" u="" 52;ng="" my="" mm="" m="" nu="" mam”="" 5m="" 1="" 4i="" pnaemx="" contact="" e="" flow”="" .4="" -="" m="" ma="" damnsxs="" .="" a="" m“="" gamma="" v="" a="" _="" n="">< m=""> S m ‘ ) warm MamafivaW—l @ A“: mlfifilcammm o a 7| x :31) deflenhadflxapnexmunfizdkmnds Sysunfl'aw: mm / m 152 / want. 3 mmmgg , . mm / m / v ‘ , 4 > cmeA FEMEVA Wamungen A Wu: A SPSVFEMEVA Dvurken A Buskunfigmatm Arm Lominer/ mmsmmmv. "u >268 @
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 19
15.3 FDT and PC WorX
FDT function have been integrated into the PC WorX
software, the standard IEC-61131 programming
environment for control systems from Phoenix Contact. This
allows to integrate DTMs from various manufacturers, and
to easily parameterize and diagnose devices and sensors/
actuators, e.g. via Ethernet, INTERBUS, HART and
PROFINET IO and in future even via the IO Link protocol.
The following figure shows the representation of a HART
device in the PC WorX software.
Figure 12 HARTdevice in PC WorX
www.automalionxglorer.ghoenixconlacl.com www.automalionx lorer. hoenixconlacl.com www.down\oadghoemxconlacmom www owmoad ghoemxconlacl om
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 20
15.4 Internet
AutomationXplorer+ can be downloaded at
www.automationxplorer.phoenixcontact.com. Additional
information about the software is also provided here.
Device-specific DTMs can be downloaded at
www.automationxplorer.phoenixcontact.com or
www.download.phoenixcontact.com.
For DTMs for devices from other manufacturers, please
contact the relevant manufacturer.
15.5 Documentation
The "Startup of a HART-Compatible Device in
AutomationXplorer+" application note uses an example to
show how a HART-compatible device is handled in the
AutomationXplorer+ software (see "Ordering Data" on
page 3).
15.6 Special Addressing and Connection
(e.g., Using a Hand-Held Operating Device)
In the PC WorX software, you do not need to program
devices that you integrated into a bus structure using FDT/
DTM technoloy. These devices only need to be configured.
16 Reading Data Using the HART
Protocol
In point-to-point operating mode, the main value of the field
devices is transmitted as an analog signal (4 mA ... 20 mA)
using process data.
To read additional data you may use communications via
the HART protocol. In the local bus and in the INTERBUS
system, this protocol is implemented using PCP.
When using a control system from Phoenix Contact
and/or FDT communication:
For communications via the HART protocol you can use a
function block that supports both, point-to-point as well as
multidrop mode.
The function block can be downloaded at
www.download.phoenixcontact.com. It takes over PCP
communication completely. You do not have to read Section
17 „PCP Communication“ .
When using other control systems:
Create a function block for communications via the HART
protocol. Use the information on PCP communication in
Section 17.
17 PCP Communication
You only need to read this section if you want to create your
own function block for the use of HART communication (see
also Section 16).
By default upon delivery, the terminal is configured for data
transmission according to the parameters on page 30. You
can configure the terminal to meet the requirements of your
application.
The terminal is configured in PCP mode using the
INIT_TABLE object.
For further information on PCP communication,
please refer to the IBS SYS PCP G4 UM E user
manual.
Here you will also find more detailed information
on error messages during PCP operation.
The programs IBS CMD and Config+ (for
standard controller boards) as well as PC WorX
(for Field Controllers (FC) and Remote Field
Controllers (RFC) and embedded controllers
(ILC 3xx)) are available for the configuration and
parameterization of your INTERBUS system.
For more detailed information, please refer to the
following user manuals:
IBS CMD SWT G4 UM E,
UM QS EN CONFIG+, and
UM QS EN PC WORX.
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 21
17.1 Object Dictionary
Index Data Type N L Meaning Object Name Rights
0080hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL1_SLAVE1 rd
0081hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL1_SLAVE2 rd
0082hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL1_SLAVE3 rd
0083hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL1_SLAVE4 rd
0084hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL1_SLAVE5 rd
008Fhex String Var of Octet String 1 58 HART_PASS_THROUGH_CHANNEL1 rd/wr
0090hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL2_SLAVE1 rd
0091hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL2_SLAVE2 rd
0092hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL2_SLAVE3 rd
0093hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL2_SLAVE4 rd
0094hex String Var of Octet String 1 12 UNIQUE_IDENTIFIER_CHANNEL2_SLAVE5 rd
009Fhex String Var of Octet String 1 58 HART_PASS_THROUGH_CHANNEL2 rd/wr
00A0hex String Var of Octet String 1 40 POLL/
BURST_RESPONSE_CHANNEL1_SLAVE1
rd
00A1hex String Var of Octet String 1 40 POLL_RESPONSE_CHANNEL1_SLAVE2 rd
00A2hex String Var of Octet String 1 40 POLL_RESPONSE_CHANNEL1_SLAVE3 rd
00A3hex String Var of Octet String 1 40 POLL_RESPONSE_CHANNEL1_SLAVE4 rd
00A4hex String Var of Octet String 1 40 POLL_RESPONSE_CHANNEL1_SLAVE5 rd
00B0hex String Var of Octet String 1 40 POLL/
BURST_RESPONSE_CHANNEL2_SLAVE1
rd
00B1hex String Var of Octet String 1 40 POLL_RESPONSE_CHANNEL2_SLAVE2 rd
00B2hex String Var of Octet String 1 40 POLL_RESPONSE_CHANNEL2_SLAVE3 rd
00B3hex String Var of Octet String 1 40 POLL_RESPONSE_CHANNEL2_SLAVE4 rd
00B4hex String Var of Octet String 1 40 POLL_RESPONSE_CHANNEL2_SLAVE5 rd
00C0hex Array of Unsigned 16 2 2 Analog values PROCESS_DATA_VALUE rd
00C1hex Array of Unsigned 16 2 2 STATUS rd
00C2hex Array of Unsigned 16 2 2 Settings
(rescan, polling
and burst mode)
CONTROL rd/wr
00C3hex Array of Unsigned 16 14 2 Terminal
configuration
INIT_TABLE rd/wr
N: Number of elements rd: Read access permitted
L: Element length in bytes wr: Write access permitted
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 22
17.2 UNIQUE_IDENTIFIER_CHANNEL1_SLAVE1 ... 5 and
UNIQUE_IDENTIFIER_CHANNEL2_SLAVE1 ... 5 Objects
The UNIQUE_IDENTIFIER_CHANNEL1/2_SLAVE1 ... 5 objects contain the manufacturer's indentification data of the
slaves connected to the HART terminal.
Object Description
The objects with the indices 0080hex-0084hex and 0090hex-0094hex all have the same structure. For every possible HART
slave there is a unique identifier object. All 008xhex indices are valid for channel 1, all 009xhex indices are valid for channel 2.
With every object, the unique identifiers of the corresponding HART slaves can be read.
After power-up, these unique identifiers are read from the HART terminal to all present HART slaves. During this process,
the "Scan Active" status bit is set.
Byte Assignment of the UNIQUE_IDENTIFIER_CHANNELx_SLAVE1 ... 5 Objects
Figure 13 Byte assignment of the UNIQUE_IDENTIFIER_CHANNELx_SLAVE1 ... 5 objects
Error Message of This Object
Parameters:
Objects UNIQUE_IDENTIFIER_CHANNEL1_SLAVE1 ... 5
UNIQUE_IDENTIFIER_CHANNEL2_SLAVE1 ... 5
Access Read
Data type String Var of Octet String
Index 0080hex - 0084hex (Channel 1, Slave 1...5)
0090hex - 0094hex (Channel 2, Slave 1...5)
Subindex 00hex
Length (bytes) 12 bytes
Data Device identification
Error_Class Error_Code Additional_Code Meaning
08hex 00hex 0021hex A Read service was received. The data is not yet available because
the terminal still is in "Scan Active" mode.
Please wait until the "Scan Active" bit is set to 0
(see Figure 16 on page 28)
87654321910
11 0
Manufacturer Identification Code
254 = FE
dez hex
Universal Command Revision
Device ID Number
Device ID Number
Device ID Number
Device Function Flags
Device Type Code
Number of Preambles
Transmitter-spec CMD Revision
Software Revision
Hardware Revision
6758B027
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 23
17.3 HART_PASS_THROUGH_CHANNEL1 / 2 Object
The HART_PASS_THROUGH_CHANNEL1 / 2 objects map the data of a PCP service to a HART telegram. In this way HART
devices can receive HART telegrams directly.
Object Description
Error Messages of This Object During Write Access
Parameters:
The error message "(08, 00, 0022)hex" can be disabled int he INIT_TABLE object. It ensures that a Write service to the
HART_PASS_THROUGH_CHANNELx object is always followed by a Read service.
In case, that two different applications use the HART_PASS_THROUGH_CHANNELx object of the terminal, the service
sequence is to prevent response telegrams being overwritten before they have been read. For example, it is to be prevented
that application 2 generates a HART telegram the response telegram of which overwrites the response telegram of the
HART telegram of application 1 before application 1 has read it.
There are two exceptions for which no error message is generated:
1. The preceding Write confirmation contains a negative result.
2. Between the first and the second Write service more than 30 seconds elapse.
The time of 30 seconds is to prevent the error message "(08, 00, 0022)hex" in the following case:
An application sends a Write service and crashes. After the restart it sends a Write service again.
If between these two Write services a time of 30 seconds elapsed, the application is processed without an error message.
There is a restriction with regard to the HART response transmission: The master address bit and the burst mode bit from
the address field are always set to zero.
Object HART_PASS_THROUGH_CHANNEL1 / 2 object
Access Read, Write
Data type String Var of Octet String
Index 008Fhex (channel 1) / 009Fhex (channel 2)
Subindex 00hex
Length (bytes) 58 bytes, maximum
Data Mapping the PCP user data to a HART telegram
Error_Class Error_Code Additional_Code Meaning
08hex 00hex 0020hex – Polling or burst mode operation active
– The message is to activate burst operating mode on a HART
slave (command = 109 and data = 1)
08hex 00hex 0022hex A second Write service was received, without the HART response
having been collected by a Read service.
08hex 00hex 0024hex HART timeout, the addressed HART slave did not answer
08hex 00hex 0025hex HART communication error
06hex 02hex 0000hex HART supply voltage not present
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 24
Mapping the PCP User Data to a HART Telegram
Figure 14 Mapping the PCP user data to a HART telegram
The user data of the PCP Write services are inserted between the preamble and the checksum of a HART request telegram.
The start sign must be assigned because this sign contains the information whether the following address is short or long.
The same is valid for a HART response telegram. The data of a HART response telegram between preamble and checksum
are made available as user data in the PCP read confirmation.
The PCP write confirmation is only sent back as soon as the HART response telegram was received by the Inline terminal.
Usually this happens after 300 ms. Then the HART response telegram must be read via a PCP read request.
Figure 15 Service sequence between HART operating device (master) and HART field device (slave)
Command_Code
Parameter_Count
Invoke_ID Comm._Reference
Index
Subindex Length
Data [1]
6758C020
Preamble
SC
AD
HC
BC
DA
Checksum
Data [...]Data [...]
Data [...]Data [...]
Data [2]
15 ...................... 8 7 ........................ 0
0082hex
Word 1
Word 2
Word 3
Word 4
Word 5
Word 6
Word ...
Word ...
Write_Request
PCP
Request telegram
HART
Master
6758B021
IL AI 2 HART HART-Slave
Write_Request to "HART_PASS_THROUGH" object
HART-Request-Telegram
Hart-Response-Telegram
Write_Confirmation
Read_Request to "HART_PASS_THROUGH" object
Read_Confirmation with HART-Response
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 25
17.4 POLL/BURST_RESPONSE_CHANNEL1_SLAVE1 ... 5 and
POLL/BURST_RESPONSE_CHANNEL2_SLAVE1 ... 5 Object
The objects contain response telegrams of the HART devices that
– during polling mode operation responded to a request telegram by the master or
– are operated in burst mode.
Object Description
The objects with the indices 00A0hex-00A4hex and 00B0hex-00B4hex all have the same structure. For every possible HART
slave there is a response object. All 00Axhex indices are valid for channel 1, all 00Bxhex indices are valid for channel 2. With
every object, the unique identifiers of the corresponding HART slaves can be read. Since burst mode operation is only
admissable for point-to-point connection, a burst response can only be read with index 00A0hex for channel 1 and index
00B0hex for channel 2.
The HART response to be read comprises the complete HART telegram format, however without preamble and checksum.
In this way, the object has the same format as the PASS_THROUGH object. For an example of a HART response. please
refer to page 26.
Error Message of This Object
Parameters:
Object POLL/BURST_RESPONSE_CHANNEL1_SLAVE1 ... 5
POLL/BURST_RESPONSE_CHANNEL2_SLAVE1 ... 5
Access Read
Data type String Var of Octet String
Index 00A0hex - 00A4hex (Channel 1, Slave 1...5)
00B0hex - 00B4hex (Channel 2, Slave 1...5)
Subindex 00hex
Length (bytes) 40 bytes, maximum
Data Measured data
Error_Class Error_Code Additional_Code Meaning
06hex 02hex 0030hex HART supply voltage not present
Check the voltage supply of the Inline HART terminal.
Please observe that the measured data structure depends on the polling mode set. For further information, please
refer to the HART command overview of the HART Communication Foundation HCF.
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 26
Example of a HART Response
The following example only deals with the response telegram in polling mode operation. Here, only the 3 HART commands
1, 2 or 3 can be selected. The response telegram is structured according to the selected command. The data of a HART
response telegram between preamble and checksum are made available as user data in the PCP read confirmation.
The object is read with a PCP read request. The content of a read confirmation depends on the selected HART command.
Structure of the PCP read confirmation:
Byte Meaning Command 1 Command 2 Command 3
PCP header 1 Message code 1st byte 80 80 80
2 Message code 2nd byte 81 81 81
3 Parameter count 1st byte 00 00 00
4 Parameter count
2nd byte
0Bhex = 11dec 0Chex = 12dec 14hex = 20dec
5 Invoke ID xx xx xx
6 Comm. reference xx xx xx
7 Result 1st byte 00 00 00
8 Result 2nd byte 00 00 00
9 Not used -- -- --
10 Length 0Fhex = 15dec 12hex = 18dec 22hex = 34dec
HART part 11 Start character 86hex 86hex 86hex
12 Address 1st byte xx xx xx
13 Address 2nd byte xx xx xx
14 Address 3rd byte xx xx xx
15 Address 4th byte xx xx xx
16 Address 5th byte xx xx xx
17 Command 01 02 03
18 Byte count 07 Ahex = 10dec 1Ahex = 26dec
19 Status 1st byte 00 00 00
20 Status 2nd Byte 00 00 00
21 Data PV units code Current 1st byte Current 1st byte
22 Data PV 1st byte Current 2nd byte Current 2nd byte
23 Data PV 2nd byte Current 3rd byte Current 3rd byte
24 Data PV 3rd byte Current 4th byte Current 4th byte
25 Data PV 4th byte Percent of range 1st byte PV units code
26 Data Percent of range 2nd byte PV 1st byte
27 Data Percent of range 3rd byte PV 2nd byte
28 Data Percent of range 4th byte PV 3rd byte
29 Data PV 4th byte
30 Data SV units code
31 - 34 Data (4 bytes) SV 1st to 4th byte
35 Data TV units code
36 - 39 Data (4 bytes) TV 1st to 4th byte
40 Data FV units code
41 - 44 Data (4 bytes) FV 1st to 4th byte
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 27
17.5 PROCESS_DATA_VALUE Object
This object provides measured values that are also contained in the IN process data (see Section 12.2 on page 12).
Object Description
This object is only relevant for a point-to-point connection.
Object PROCESS DATA VALUE
Access Read
Data type Array of Unsigned 16 2 x 2 bytes
Index 00C0hex
Subindex 00hex
01hex
02hex
Both channels
Channel 1
Channel 2
Length (bytes) For subindex 0, the length is 4 bytes.
For subindex >0, the length is 2 bytes.
Data 1st word for channel 1
2nd word for channel 2
Please observe that the data read out with this object depends on the addressed HART field device.
“W
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 28
17.6 STATUS Object
The STATUS object indicates the operating state of each channel of the terminal.
Object Description
Description of an Element/Bit Assignment
Figure 16 Assignment of an element of the STATUS object (00C1hex)
These two supply voltage error bits are reset after voltage is restored. If the Burst Trouble bit is set, you can set it via an error-
free write access onto the CONTROL object.
Object STATUS
Access Read
Data type Array of Unsigned 16 2 x 2 bytes
Index 00C1hex
Subindex 00hex
01hex
02hex
Both channels
Channel 1
Channel 2
Length (bytes) For subindex 0, the length is 4 bytes.
For subindex >0, the length is 2 bytes.
Data 1st word (element) for channel 1
2nd word (element) for channel 2
– The polling modes can be selected depending on the HART field devices used.
– The data read out with this object depend on the addressed HART field device.
Number of HART-Slaves
3
7
8910
1112
13
14
15
6758B022
Scan Active
Burst Mode Active
Poll Mode Active
Analog Supply Fail
HART Supply Fail
Burst Trouble
10
2
4
5
6
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 29
17.7 CONTROL Object
Set the polling mode or burst mode via this object for each channel of the terminal.
Object Description
Description of an Element/Bit Assignment
Figure 17 Assignment of an element of the CONTROL object (00C2hex)
Please observe that burst and polling mode cannot be active simultaneously (see also "HART Operating Mode (Polling/
Burst) for Point-to-Point Connections and Multidrop Networks" on page 16).
Re-Scan
The HART interface is re-initialized via the Re-Scan bit. The UNIQUE_IDENTIFIER... objects are deleted and the scan
process is introduced again. In this way, all connected slaves on the affected HART channel are detected. During this
process, the Scan Active bit is reset in the STATUS object.
The Re-Scan bit is cannot be read back in this object.
Object CONTROL
Access Read, Write
Data type Array of Unsigned 16 2 x 2 bytes
Index 00C2hex
Subindex 00hex
01hex
02hex
Both channels
Channel 1
Channel 2
Length (bytes) For subindex 0, the length is 4 bytes.
For subindex >0, the length is 2 bytes.
Data 1st word (element) for channel 1
2nd word (element) for channel 2
1514131211109876543210
Re-
Scan
Poll command
0: Polling mode not active
1, 2, 3 allowed
Burst command
0: Burst mode not active
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 30
Error Message of This Object:
17.8 INIT_TABLE Object
Writing the INIT_TABLE object with a Write service configures the terminal.
Object Description
Error_Class Error_Code Additional_Code Meaning
06hex 02hex 0000hex HART supply voltage not present
08hex 00hex 2020hex No HART slave found at the channel and polling or burst-command
<> 0.
08hex 00hex 2022hex Scan phase active and (polling command <> 0 or burst-command <>
0).
08hex 00hex 2030hex Polling and burst command (both) <> 0.
08hex 00hex 2130hex Polling command > 3.
08hex 00hex 2230hex Re-Scan bit set and polling command <> 0 or burst-command <> 0.
08hex 00hex 2330hex A bit of the reserved bits 12, 13 or 14 is set.
08hex 00hex 2040hex Polling command <> 0 and burst mode still active.
08hex 00hex 2043hex Burst command <> 0 and polling mode still active.
08hex 00hex 2047hex Burst mode is to be enabled for multidrop environment.
Object INIT_TABLE
Access Read, Write
Data type Array of Unsigned 16 14 x 2 bytes
Index 00C3hex
Subindex 00hex
01hex
02hex
03hex
04hex
05hex
06hex
07hex
:
0Ehex
Write all elements
Analog configuration
Limit value for open circuit
Limit value for overrange
Reserved
Reserved
System settings
Reserved
:
Reserved
Length (bytes) For subindex 0, the length is 28 bytes.
For subindex >0, the length is 2 bytes.
Data IB IL AI 2-HART terminal configuration
IB IL AI 2-HART (-PAC)
6758_en_01 PHOENIX CONTACT 31
Element Description (Subindex)
Analog Configuration Element
Figure 18 Assignment of the analog configuration element (index 00C3, hex, subindex 1hex)
Open Circuit Element
In the "Standardized representation" format this element is used to determine the limit value for open circuit. If the current
falls below the limit value the error message open circuit 8002hexis indicated in the IN process data. By default, the value is
3200dec, which corresponds to 3.2 mA.
Overrange Element
In the "Standardized Representation" format this element is used to determine the limit value for overrange. If the current is
above the limit value the Overrange error message 8001hexis indicated in the IN process data. By default, the value is
22500dec, which corresponds to 22.5 mA.
System Settings Element
Figure 19 Assignment of the system settings element (index 00C3, hex, subindex 06hex)
The Peripheral Fault that can be switched off, relates to the response of a supply voltage interrupt.
Error Messages of This Object
If a Write service writes an invalid value to an element, the service will be aborted with a negative confirmation.
Here, the parameters are the following:
The high byte of the ADDITIONAL_CODE (xx) contains the number of the affected element. If several elements are affected,
the highest number is given. If, for example, the "analog configuration" element is written with the value 0001hex, an error
message with the ADDITIONAL_CODE 0130hex will be displayed, because the first element is faulty.
1514131211109876543210
Filter Format
The options in bold are default settings.
Code Filter
0 16-fold mean value
1 No mean-value generation
24-fold mean value
3 32-fold mean value
Code Format
0 IB IL 4 mA ... 20 mA
1 Standardized representation
2PIO
3 Reserved
Error_Class Error_Code Additional_Code Meaning
08hex 00hex xx30hex Value is out of range
014 13 12 11 10 9 8 7 6 5 4 3 2 1
6758D010
15
Peripheral Fault:
1: disable
0: enable
Error message 08, 00, 0022 with PASS_THROUGH objects
1: disable
0: enable
IB IL AI 2-HART (-PAC)
6758_en_01 32
PHOENIX CONTACT GmbH & Co. KG • 32823 Blomberg • Germany • Phone: +49-(0) 5235-3-00
PHOENIX CONTACT • P.O.Box 4100 • Harrisburg • PA 17111-0100 • USA • Phone: +717-944-1300
www.phoenixcontact.com
18 Start Behavior
After power-up, the terminal searches both HART channels
for possible slaves. To do this, the HART command 0 at the
short addresses 0 up to 15 are sent in ascending order.
If the slave already responds to short address 0, the search
process is aborted. If not, the search process continues until
either the short address 15 is reached or the number of
slaves detected equals five. For a command to short
address 0, 6 different attempts have been executed where
normally only 1 attempt takes place.
During this process being executed in parallel on both
channels of the Inline HART terminal, the Scan Active bit is
set.
From the detected slaves, the
UNIQUE_IDENTIFIER_CHANNEL1/2_SLAVE1...5 objects
are read and can then be read via the 008xhex and 009xhex
object indices. Among others the UNIQUE_IDENTIFIERx
object contains the unique 38-bit address of the HART
slave.
The UNIQUE_IDENTIFIERx objects are distributed onto the
objects in the order in which they are found during the
search process.
Example:
A multidrop network at the HART channel 1 comprises the
short addresses 1, 3, 7, 12, and 14.
Distribution of the UNIQUE_IDENTIFIER1 objects:
The number of detected slaves can be read via the STATUS
(00C1hex) object.
After the search process, the Inline HART terminal waits for
4 seconds for a HART slave to send a burst telegram, if
required. This case is possible because some HART slaves
save there settings in a non-volatile memory. If a slave is in
active burst mode, it contiunes to send burst telegrams after
the voltage interrupt.
After having received a burst telegram, the Inline HART
terminal sends a request telegram to the slave in question in
order to switch off burst mode. Only then a search process
starts.
Duration of the Scan Process For the Worst Case
(no HART device present):
Index
(hex)
Distribution Description
0080 UNIQUE_IDENTIFIER_
CHANNEL1_SLAVE1
Slave with short
address 1
0081 UNIQUE_IDENTIFIER_
CHANNEL1_SLAVE2
Slave with short
address 3
0082 UNIQUE_IDENTIFIER_
CHANNEL1_SLAVE3
Slave with short
address 7
0083 UNIQUE_IDENTIFIER_
CHANNEL1_SLAVE4
Slave with short
address 12
0084 UNIQUE_IDENTIFIER_
CHANNEL1_SLAVE5
Slave with short
address 14
Burst waiting time 4 seconds
6 messages to
addresses 0
6 * 330 ms = approx. 2
seconds
1 messages to
addresses 1-15
15 * 330 ms = approx. 5
seconds
Total approx. 11
seconds
