The Important Information/Disclaimer is incorporated in these specifications
by reference and should be reviewed in full before placing any order. 101
HOW TO ORDER
AVX PART NUMBER:
TWA 407 100E B # Z 0 00
^
*
Type Case
Size
Capacitance
Code
pF code:
1st two digits
represent
significant
figures 3rd
digit represents
multiplier
(number of
zeros to follow)
Capacitance
Tolerance
K = ±10%
M = ±20%
Voltage
Code
Qualification
E = Extended range
S = COTS+
L = Group A
Reliability
Z = Non-ER
Termination
Finish
0 = Sn/Pb 60/40
7 = Matte tin
Custom Test
Options
00 = Standard
01 = Random
vibration*
Qualification
Level
0 = N/A
Insulation Sleeve
C = Without Sleeve
S = With Sleeve
Packaging
B = Tray Pack
LEAD-FREE COMPATIBLE
COMPONENT
For RoHS compliant products,
please select correct termination style.
* Please contact the factory for additional details and availability.
The TWA series is an axial leaded wet electrolytic tantalum capacitor with a unique cathode system
that promotes very high CV (Capacitance/Voltage) per cc in traditional MIL-PRF-39006 case sizes.
The series also utilizes a welded tantalum can and header assembly to provide a hermetic seal and
subsequent long operating lifetime.
The construction is similar to DLA 93026 with capability of meeting harsh shock and vibration
conditions.
OUTLINE DIMENSIONS
GENERAL DESCRIPTION
CASE DIMENSIONS: millimeters (inches)
VOLTAGE RATINGS (Operating Temperature -55ºC to 125ºC)
DLA
Case
Size
AVX
Case
Size
L
+0.79 (0.031)
-0.41 (0.016)
D
Without
Insulating
Sleeve
±0.41 (0.016)
D
With
Insulating
Sleeve
Max
E
±6.35 (0.250)
T1 A11.51 (0.453) 4.78 (0.188) 5.56 (0.219) 38.10 (1.500)
T2 B16.28 (0.641) 7.14 (0.281) 7.92 (0.312) 57.15 (2.250)
T3 D19.46 (0.766) 9.52 (0.375) 10.31 (0.406) 57.15 (2.250)
T4 E26.97 (1.062) 9.52 (0.375) 10.31 (0.406) 57.15 (2.250)
Voltage (DC)
Rated Voltage: (VR)85ºC 15 25 30 50 60 75 100 125
Derated Voltage: (VC)125ºC 10 15 20 30 40 50 65 85
Surge Voltage: (VS)85ºC 17.3 28.8 34.5 57.5 69 86.3 115 144
Terminal welded
to case (T)
Case
+-
F 6.35 (0.250)
W 0.64 +0.05
(.025 +.002)
T 2.380 (.094)
FD
EW
LE
TWA SERIES
COTS-Plus – Wet Electrolytic Tantalum Capacitor
102418
/A\V/)I(” /;.\V/)I( |
The Important Information/Disclaimer is incorporated in these specifications
by reference and should be reviewed in full before placing any order.
102
RIPPLE CURRENT MULTIPLIERS vs. Frequency, temperature and applied voltage1/ 2/
Frequency of
Applied
Ripple Current
120Hz 800Hz 1kHz
Ambient Still Air
Temperature (ºC) ≤55 85 105 125 ≤55 85 105 125 ≤55 85 105 125
% of
85ºC
Rated
Peak
Voltage
100% 0.60 0.39 – – 0.71 0.43 – – 0.72 0.45 – –
90% 0.60 0.46 – – 0.71 0.55 – _ 0.72 0.55 – –
80% 0.60 0.52 0.35 – 0.71 0.62 0.42 – 0.72 0.62 0.42 –
70% 0.60 0.58 0.44 – 0.71 0.69 0.52 – 0.72 0.70 0.52 –
66-2/3% 0.60 0.60 0.46 0.27 0.71 0.71 0.55 0.32 0.72 0.72 0.55 0.32
Frequency of
Applied
Ripple Current
10kHz 40kHz 100kHz
Ambient Still Air
Temperature (ºC) ≤55 85 105 125 ≤55 85 105 125 ≤55 85 105 125
% of
85ºC
Rated
Peak
Voltage
100% 0.88 0.55 – – 1.00 0.63 – – 1.10 0.69 – –
90% 0.88 0.67 – – 1.00 0.77 – _ 1.10 0.85 – –
80% 0.88 0.76 0.52 – 1.00 0.87 0.59 – 1.10 0.96 0.65 –
70% 0.88 0.85 0.64 – 1.00 0.97 0.73 – 1.10 1.07 0.80 –
66-2/3% 0.88 0.88 0.68 0.40 1.00 1.00 0.77 0.45 1.10 1.10 0.85 0.50
1/ At 125ºC the rated voltage of the capacitors decreases to 66 2/3 of the 85ºC rated voltage.
2/ The peak of the applied ac ripple voltage plus the applied dc voltage must not exceed the dc voltage rating of the capacitors.
TWA SERIES
COTS-Plus – Wet Electrolytic Tantalum Capacitor
020620
CAPACITANCE AND RATED VOLTAGE, VR (VOLTAGE CODE) RANGE
(LETTER DENOTES CASE SIZE)
Capacitance Rated Voltage DC (VR) to 85°C
µF Code 15V 25V 30V 50V 60V 75V 100V 125V
10 106 A(M)A
15 156 A
22 226 B
27 276 B
33 336 A
47 476 B A B
68 686 A A A(M)B
82 826 E
100 107 A A(M)B B D
110 117 B
120 127 A B D
150 157 B B D E
220 227 B B E D,E E
270 277 B
330 337 B E D,E E E
390 397 D D
400 407 E
470 477 B D,E E E E
560 567 B E E
660 667 E
680 687 E D,E E E E
750 757 D,E D,E E E E E
1000 108 D,E D,E D,E E E
1200 128 D E
1500 158 E E E
1800 188 E
2200 228 E E(M)
3000 308 E
4700 478 E
5600 568
Available Ratings (M tolerance only)
/A\V/)I(® /.‘.\V/)I( |
The Important Information/Disclaimer is incorporated in these specifications
by reference and should be reviewed in full before placing any order. 103
AVX Part Number
Cap (μF)
25ºC
at 120Hz
DC Rated
Voltage
(V)
at 85ºC
ESR max
(ohms)
at 120Hz
DC Leakage max
(μA)
Impedance
max (Ohms)
-55ºC at
120Hz
Maximum Capacitance
Change (%)
AC Ripple
(mA rms)
85ºC at
40kHz
Case Size
+25ºC +85ºC &
+125ºC AVX DLA
-55ºC +85ºC +125ºC
15 Volts
TWAD397*015BSZ0^00 390 15 1.7 728 48 -70 25 25 1396 DT3
25 Volts
TWAA686*025BEZ0^00 68 25 2.5 0.6 3 45 -40 12 15 850 AT1
TWAA127*025BSZ0000 120 25 1.3 1 5 25 -42 812 1250 AT1
TWAA127*025BEZ0^00* 120 25 2.3 210 35 -42 20 25 1250 AT1
TWAB277*025BEZ0^00 270 25 0.9 420 17.5 -50 18 28 1800 BT2
TWAB337*025BEZ0^00 330 25 1.3 220 25 -60 10 15 1550 BT2
TWAB567*025BSZ0^00 560 25 0.83 210 12 -65 10 15 2100 BT2
TWAE687*025BEZ0^00 680 25 0.75 312 12 -50 815 2100 ET4
TWAD757*025BEZ0^00 750 25 1 3 25 15 -50 815 2000 DT3
TWAE757*025BEZ0^00 750 25 0.75 3.5 16 9-55 10 18 2200 ET4
TWAD108*025BEZ0^00 1000 25 1 4 30 15 -50 815 2300 DT3
TWAE108*025BEZ0^00 1000 25 0.7 420 9-55 10 18 2400 ET4
TWAD128*025B#Z0^00 1200 25 0.65 5 20 7-70 12 18 2600 DT3
TWAE158*025BEZ0^00 1500 25 0.5 624 7-65 15 20 2850 ET4
TWAE188*025BSZ0^00 1800 25 0.5 625 7-75 12 20 3100 ET4
TWAE228*025BSZ0^00 2200 25 0.5 10 80 10 -90 30 50 3200 ET4
TWAE478*025B#Z0^00 4700 25 0.5 30 180 5-90 60 80 4250 ET4
30 Volts
TWAA107*030BSZ0000 100 30 1.3 1 5 25 -38 812 1200 AT1
TWAA107*030BEZ0^00* 100 30 2.3 210 35 -38 20 25 1200 AT1
TWAB227*030BEZ0^00 220 30 21.9 10 40 -40 18 28 1200 BT2
TWAB477*030BSZ0^00 470 30 0.85 210 15 -65 10 18 1800 BT2
TWAD687*030BEZ0^00 680 30 13.3 25 15 -50 815 1900 DT3
TWAE687*030BEZ0^00 680 30 0.8 4.5 18 10 -60 815 2100 ET4
TWAD757*030BEZ0^00 750 30 1 3.6 30 15 -50 815 2000 DT3
TWAE757*030BEZ0^00 750 30 0.8 520 10 -65 10 18 2200 ET4
TWAD108*030B#Z0^00 1000 30 0.7 725 7-70 10 18 2500 DT3
TWAE108*030BEZ0^00 1000 30 0.7 520 7-70 10 18 2500 ET4
TWAE158*030BSZ0^00 1500 30 0.6 12 35 6-72 10 20 3000 ET4
50 Volts
TWAB476*050BSZ0^00 47 50 30.8 870 -28 13 15 1155 BT2
TWAA686*050BSZ0000 68 50 1.5 1 5 35 -25 815 1050 AT1
TWAA686*050BEZ0^00* 68 50 2.5 210 45 -25 20 25 1050 AT1
TWAA107M050BSZ0^00 100 50 5 2 15 70 -45 50 95 1500 AT1
TWAB127*050BEZ0^00 120 50 2 2 10 40 -45 815 1200 BT2
TWAB157*050BEZ0^00 150 50 2 2 10 25 -50 815 1400 BT2
TWAB227*050BSZ0000 220 50 0.9 210 17.5 -50 815 1800 BT2
TWAB227*050BEZ0^00* 220 50 0.9 420 17.5 -50 18 28 1800 BT2
TWAE337*050B#Z0^00 330 50 0.8 2.5 25 15 -50 815 1900 ET4
TWAD477*050BSZ0^00 470 50 0.75 325 10 -50 815 2100 DT3
TWAD477*050BEZ0^00* 470 50 1 3 25 11 -50 815 2100 DT3
TWAE477*050B#Z0^00 470 50 0.75 330 10 -50 815 2200 ET4
TWAE687*050B#Z0^00 680 50 0.7 540 8-58 10 20 2750 ET4
TWAE757*050BEZ0^00 750 50 0.6 12 60 8-50 15 20 2800 ET4
TWAD108*050BEZ0^00 1000 50 1.5 20 125 12 -90 100 140 2500 DT3
TWAE108*050BSZ0^00 1000 50 1.0 12 90 20 -90 30 50 3200 ET4
TWAE108*050BEZ0^00* 1000 50 0.7 11 110 20 -70 30 40 3200 ET4
TWAE128*050BSZ0^00 1200 50 1.0 12 90 20 -90 30 50 3200 ET4
TWAE158*050BSZ0^00 1500 50 135 130 6-75 45 55 3500 ET4
TWAE308M050B#Z0^00 3000 50 0.3 30 150 3.5 -80 60 85 3100 ET4
TWAE308K050BSZ0^00 3000 50 0.6 30 150 5-90 90 100 3100 ET4
60 Volts
TWAA476*060BSZ0000 47 60 2 1 5 44 -25 812 1050 AT1
TWAA476*060BEZ0^00* 47 60 2 2 10 55 -25 15 25 1050 AT1
TWAB107*060BSZ0^00 100 60 1.5 1.7 10 30 -35 12 20 1650 BT2
TWAB107*060BEZ0^00* 100 60 2.5 1.7 10 40 -40 815 1100 BT2
TWAB157*060BSZ0000 150 60 1.1 210 20 -40 815 1650 BT2
TWAB157*060BEZ0^00* 150 60 1.5 210 30 -35 12 20 1650 BT2
TWAD397*060B#Z0^00 390 60 0.9 325 15 -60 815 2100 DT3
TWAE567*060B#Z0^00 560 60 0.8 540 10 -58 815 2750 ET4
TWAE687*060BEZ0^00 680 60 0.6 13 65 8 -50 15 20 2800 E T4
TWAE757*060BEZ0^00 750 60 0.6 15 75 8 -50 15 20 2800 E T4
TWAE108*060BSZ0^00 1000 60 1 12 90 20 -90 30 50 3200 E T4
TWAE108*060BEZ0^00* 1000 60 0.5 20 60 4.5 -70 30 60 3200 E T4
TWAE228M060BEZ0^00 2200 60 0.5 40 120 3.0 -80 60 80 3000 E T4
RATINGS & PART NUMBER REFERENCE
TWA SERIES
COTS-Plus – Wet Electrolytic Tantalum Capacitor
020620
/A\V/)I(® /.‘.\V/)I( |
The Important Information/Disclaimer is incorporated in these specifications
by reference and should be reviewed in full before placing any order.
104
RATINGS & PART NUMBER REFERENCE
TWA SERIES
COTS-Plus Wet Electrolytic Tantalum Capacitor of Contents
020620
AVX Part Number
Cap (μF)
25ºC
at 120Hz
DC Rated
Voltage
(V)
at 85ºC
ESR max
(ohms)
at 120Hz
DC Leakage max
(μA)
Impedance
max (Ohms)
-55ºC at
120Hz
Maximum Capacitance
Change (%)
AC Ripple
(mA rms)
85ºC at
40kHz
Case Size
+25ºC +85ºC &
+125ºC AVX DLA
-55ºC +85ºC +125ºC
75 Volt
TWAA336*075BSZ0000 33 75 2.5 1 5 66 -25 5 9 1050 AT1
TWAA336*075BEZ0^00* 33 75 2.5 210 70 -25 15 25 1050 AT1
TWAA686M075BSZ0^00 68 75 5 2 15 70 -45 50 95 1500 AT1
TWAB107*075BEZ0^00 100 75 2.5 210 40 -35 610 1400 BT2
TWAB117*075 BSZ0000 110 75 1.3 210 24 -35 610 1650 BT2
TWAB117*075 BEZ0^00* 110 75 1.5 210 30 -35 12 20 1650 BT2
TWAE227*075B#Z0^00 220 75 1.1 2.5 30 20 -50 610 1800 ET4
TWAD337*075BSZ0^00 330 75 1 3 30 12 -45 610 2100 DT3
TWAD337*075BEZ0^00* 330 75 1.2 330 15 -60 10 20 2100 DT3
TWAE337*075BEZ0^00 330 75 1 3 40 12 -50 610 2200 ET4
TWAE477*075B#Z0^00 470 75 0.9 550 12 -55 610 2750 ET4
TWAE667*075BSZ0^00 660 75 0.7 12 120 10 -70 30 40 2750 ET4
TWAE687*075BEZ0^00* 680 75 0.9 11 110 10 -70 30 40 2750 ET4
TWAE757*075B#Z0^00 750 75 0.7 12 120 10 -70 30 40 3800 ET4
TWAE108*075BEZ0^00 1000 75 0.5 30 90 4.5 -70 30 60 3500 ET4
100 Volt
TWAA106M100BSZ0^00 10 100 3.5 525 190 -18 10 30 1050 AT1
TWAA156*100BSZ0000 15 100 3.5 1 5 125 -18 310 1050 AT1
TWAA156*100BEZ0^00* 15 100 5.5 735 140 -18 10 30 1050 AT1
TWAB226*100BSZ0^00 22 100 4 1 5 100 -10 815 1065 BT2
TWAB686*100BSZ0000 68 100 2.1 210 37 -30 412 1650 BT2
TWAB686*100BEZ0^00* 68 100 2.5 210 37 -30 412 1650 BT2
TWAD157*100B#Z0^00 150 100 1.6 325 22 -35 612 2100 DT3
TWAD227*100BEZ0^00 220 100 1.4 525 18 -50 10 15 2500 DT3
TWAE227*100B#Z0^00 220 100 1.2 550 15 -40 612 2750 ET4
TWAE337*100B#Z0^00 330 100 0.8 660 10 -45 720 3600 ET4
TWAE407*100B#Z0^00 400 100 0.8 10 150 10 -50 10 35 4100 ET4
TWAE477*100BSZ0^00 470 100 0.7 15 150 10 -50 10 35 4100 ET4
TWAE567*100BSZ0^00 560 100 1.0 25 200 10 -60 45 110 4100 ET4
TWAE757*100BEZ0^00 750 100 0.6 30 150 5-60 50 120 4200 ET4
125 Volt
TWAA106*125BSZ0000 10 125 5.5 1 5 175 -15 310 1050 AT1
TWAA106M125BEZ0^00* 10 125 5.5 1 5 190 -15 10 30 1050 AT1
TWAB276*125BSZ0^00 27 125 4 2 10 100 -10 815 1200 BT2
TWAB476*125B#Z0^00 47 125 2.3 210 47 -25 512 1650 BT2
TWAE826*125BSZ0^00 82 125 1.6 210 39 -24 10 20 1900 ET4
TWAD107*125B#Z0^00 100 125 1.8 325 35 -35 512 2100 DT3
TWAD127*125BEZ0^00 120 125 1.8 325 35 -35 512 2100 DT3
TWAE157*125B#Z0^00 150 125 1.6 550 20 -35 612 2750 ET4
TWAE227*125BEZ0^00 220 125 1.4 10 50 12 -40 815 3600 ET4
TWAE337*125B#Z0^00 330 125 115 150 20 -60 20 60 2500 ET4
TWAE477*125BSZ0^00 470 125 130 160 25 -70 30 70 3500 ET4
All technical data relates to an ambient temperature of +25ºC. Capacitance and DF are measured at 120Hz, 0.5RMS with DC bias of 2.2V. DCL is measured at rated voltage after 5 minutes.
NOTE: AVX reserves the rights to supply higher voltage rating in the same case size, to the same reliability standards.
*Not recommended for new designs, for new design use part number with Inspection level “S” – COTS-Plus
DF = 2πfC x (ESR)
2π = 6.28
f = 120Hz
C = Actual measured capacitance
ESR = Actual measured ESR
[AW/K /A\V/)I( |
The Important Information/Disclaimer is incorporated in these specifications
by reference and should be reviewed in full before placing any order.
IMPORTANT INFORMATION/DISCLAIMER
All product specifications, statements, information and data (collectively, the “Information”) in this datasheet or
made available on the website are subject to change. The customer is responsible for checking and verifying
the extent to which the Information contained in this publication is applicable to an order at the time the order is
placed. All Information given herein is believed to be accurate and reliable, but it is presented without guarantee,
warranty, or responsibility of any kind, expressed or implied.
Statements of suitability for certain applications are based on AVX’s knowledge of typical operating conditions
for such applications, but are not intended to constitute and AVX specifically disclaims any warranty concerning
suitability for a specific customer application or use.
ANY USE OF PRODUCT OUTSIDE OF SPECIFICATIONS OR ANY STORAGE OR INSTALLATION
INCONSISTENT WITH PRODUCT GUIDANCE VOIDS ANY WARRANTY.
The Information is intended for use only by customers who have the requisite experience and capability to
determine the correct products for their application. Any technical advice inferred from this Information or
otherwise provided by AVX with reference to the use of AVX’s products is given without regard, and AVX assumes
no obligation or liability for the advice given or results obtained.
Although AVX designs and manufactures its products to the most stringent quality and safety standards, given
the current state of the art, isolated component failures may still occur. Accordingly, customer applications
which require a high degree of reliability or safety should employ suitable designs or other safeguards (such as
installation of protective circuitry or redundancies) in order to ensure that the failure of an electrical component
does not result in a risk of personal injury or property damage.
Unless specifically agreed to in writing, AVX has not tested or certified its products, services or
deliverables for use in high risk applications including medical life support, medical device, direct physical
patient contact, water treatment, nuclear facilities, weapon systems, mass and air transportation control,
flammable environments, or any other potentially life critical uses. Customer understands and agrees
that AVX makes no assurances that the products, services or deliverables are suitable for any high-risk
uses. Under no circumstances does AVX warrant or guarantee suitability for any customer design or
manufacturing process.
Although all product–related warnings, cautions and notes must be observed, the customer should not assume
that all safety measures are indicted or that other measures may not be required.
121119
