Datenblatt für EM-4015LRW-40 Spec

soberton inc. soberton inc.
EM ELECTRET
CONDENSER
MICROPHONE
Acoustic Product Specification
Product No: EM-4015LRW-40
CONTENTS
This document contains the technical
specifications for the omni directional
electret condenser microphone.
Page 1
Electrical Characteristics
Page 2
Typical Frequency Response Curve
Measurement Circuit
Page 3
Measurement Setup Drawing
Product External and Dimensions
Page 4
Exploded Drawing
Material Table
Page 5
Accessory Drawing
Page 6
Temperature Conditions
Reliability Test
Page 7
Soldering Condition
Heat Sink
Page 8
Packing
Release | Revision: C/2019
www.soberton.com
1
Electrical Characteristics
Temperature =20±2℃ Humidity=65±5% Air pressure=86 to 106 KPa
Sensitivity
Symbol: S Unit: dB
Condition: 0dB=1V/Pa, at 1KHz
Limits: Min: -43 Center: -40 Max: -37
Output impedance
Symbol: Z out Unit: KΩ
Condition: f=1kHz
Limits: Max: 2.2
Current Consumption
Symbol: IDSS Unit: µA
Condition: VCC =2.0V, RL=2.2KΩ
Limits: Max: 500
Signal to Noise Ratio
Symbol: S/N Unit: dB
Condition: at 1kHz S.P.L=1Pa (A-Weighted Curve)
Limits: Min: 58
Decreasing Voltage
Symbol: ΔS-VS Unit: dB
Condition: VCC = 3.0V to 2.0V
Limits: Max: -3
Operating Voltage
Unit: V
Limits: Min: 1.0 Max: 10
Maximum input S.P.L
Unit: dB
Condition: THD<3% at 1kHz
Limits: Max: 110
Dimension
Ø 4.0x1.5mm + Rubber Seal : 4.6x2.3mm
Wire
50mm (UL3302/AWG32#)
IP Level
IP67
soberton inc. Relative RcsponsddB) ‘20 50 100 200 500 1000 2000 5000 10000 20000 Frequency (Hz) FET impedance ' COMM I : Tenn.1 C : , H—O Output : ECM __ ____ . R'- : unit“ C1“ “C2: Term 2 +Vs I Shield case ’ V 0 Ground soberton inc.
EM ELECTRET
CONDENSER
MICROPHONE
Acoustic Product Specification
Product No: EM-4015LRW-40
CONTENTS
This document contains the technical
specifications for the omni directional
electret condenser microphone.
Page 1
Electrical Characteristics
Page 2
Typical Frequency Response Curve
Measurement Circuit
Page 3
Measurement Setup Drawing
Product External and Dimensions
Page 4
Exploded Drawing
Material Table
Page 5
Accessory Drawing
Page 6
Temperature Conditions
Reliability Test
Page 7
Soldering Condition
Heat Sink
Page 8
Packing
Release | Revision: C/2019
www.soberton.com
2
Typical Frequency Response Curve
Frequency Response
Microphone Response Tolerance Window
Frequency(Hz) Lower Limit(dB) Upper Limit(dB)
50 -6 +3
100 -3 +3
800 -3 +3
1000 0 0
1200 -3 +3
3000 -3 +8
5000 -3 +8
10000 -8 +8
Measurement Circuit
RL = 2.2KΩ Vs = 2.0V C1 ＝ 10pF C2=33pF C = 1µF
AMPLIFER ,7 iiiiiiiiii j DO 0 I] BS<1- 9="" |®="" term.2="" ground="" soberton="" inc.="">
EM ELECTRET
CONDENSER
MICROPHONE
Acoustic Product Specification
Product No: EM-4015LRW-40
CONTENTS
This document contains the technical
specifications for the omni directional
electret condenser microphone.
Page 1
Electrical Characteristics
Page 2
Typical Frequency Response Curve
Measurement Circuit
Page 3
Measurement Setup Drawing
Product External and Dimensions
Page 4
Exploded Drawing
Material Table
Page 5
Accessory Drawing
Page 6
Temperature Conditions
Reliability Test
Page 7
Soldering Condition
Heat Sink
Page 8
Packing
Release | Revision: C/2019
www.soberton.com
3
Measurement Setup Drawing
Product External and Dimension
Unit: mm
10 .zu/ww/mw p. ....... C. .m n O .T. r 6 ID 0 S C. ,m n O ..L r 8 ID 0 S
EM ELECTRET
CONDENSER
MICROPHONE
Acoustic Product Specification
Product No: EM-4015LRW-40
CONTENTS
This document contains the technical
specifications for the omni directional
electret condenser microphone.
Page 1
Electrical Characteristics
Page 2
Typical Frequency Response Curve
Measurement Circuit
Page 3
Measurement Setup Drawing
Product External and Dimensions
Page 4
Exploded Drawing
Material Table
Page 5
Accessory Drawing
Page 6
Temperature Conditions
Reliability Test
Page 7
Soldering Condition
Heat Sink
Page 8
Packing
Release | Revision: C/2019
www.soberton.com
No. Part Name Material Quantity
1 Waterproof 1
2 Case Al-Mg alloy 1
3 Diaphragm 1
4 Spacer 1
5 Electret Plate 1
6 Chamber 1
7 Copper Ring 1
8 PCB FR-4 1
9 FET 1
10 CHIP CAPACITOR 10pF+33pF 2
Exploded Drawing and Material Table
4
sobe on inc. TOP VTEW $45101 0:4 010,2 «>20 STDE VTEW UV GTue BOTTOM VTEW 50:4 0 Tevmz Gvouwd Em Fed UL 3302 32;; AWG 30v a0 54 mm Output sobe on inc.
EM ELECTRET
CONDENSER
MICROPHONE
Acoustic Product Specification
Product No: EM-4015LRW-40
CONTENTS
This document contains the technical
specifications for the omni directional
electret condenser microphone.
Page 1
Electrical Characteristics
Page 2
Typical Frequency Response Curve
Measurement Circuit
Page 3
Measurement Setup Drawing
Product External and Dimensions
Page 4
Exploded Drawing
Material Table
Page 5
Accessory Drawing
Page 6
Temperature Conditions
Reliability Test
Page 7
Soldering Condition
Heat Sink
Page 8
Packing
Release | Revision: C/2019
www.soberton.com
5
Accessory Drawing
Unit: mm
soberton inc. soberton inc.
EM ELECTRET
CONDENSER
MICROPHONE
Acoustic Product Specification
Product No: EM-4015LRW-40
CONTENTS
This document contains the technical
specifications for the omni directional
electret condenser microphone.
Page 1
Electrical Characteristics
Page 2
Typical Frequency Response Curve
Measurement Circuit
Page 3
Measurement Setup Drawing
Product External and Dimensions
Page 4
Exploded Drawing
Material Table
Page 5
Accessory Drawing
Page 6
Temperature Conditions
Reliability Test
Page 7
Soldering Condition
Heat Sink
Page 8
Packing
Release | Revision: C/2019
www.soberton.com
Reliability Test
After each of the following tests, the sensitivity of the microphone should be within
±3dB of initial sensitivity after 3 hours of conditioning at 20℃.
Vibration Test
Frequency : 10Hz~55Hz
Amplitude: 1.52mm
Change of Frequency : 1 octave/min
2 hours in each of axis
High Temperature Test
+85℃ for 240 hours.
Low Temperature Test
-40℃ for 240 hours.
Humidity Test
90%～95%RH,+60℃ for 240 hours.
Thermal Shock Test
–40°C, 30 minutes ↔ +80°C, 30 minutes, repeated 32 cycles →
room temperature, 3 hours.
Temperature Cycles
-40℃ ↔ +20℃ ↔ +85℃ ↔ +20℃ ↔ -40℃
(2h) (0.5h) (2h) (0.5h) (2h) (0.5h) (2h) (0.5h) (2h) for 10 cycles.
Packing Drop Test
Height: 1.5m
Procedure: 5 times from each of axis
Electrostatic Discharge
Tested to IEC61000-4-2 level 3:
a) Contact Discharge: The microphone shall operate normally after 10
discharges to is 6KV DC and the discharge network is 150pF and 330Ω.
b) Air Discharge: The microphone shall operate normally after 10
discharges to is 8KV DC and the discharge network is 150pF and 330Ω
Temperature Conditions
Operating Temperature Range
-40℃~+85℃
Storage Temperature Range
-40℃~+85℃
6
soberton inc. [I “A“ soberton inc.
EM ELECTRET
CONDENSER
MICROPHONE
Acoustic Product Specification
Product No: EM-4015LRW-40
CONTENTS
This document contains the technical
specifications for the omni directional
electret condenser microphone.
Page 1
Electrical Characteristics
Page 2
Typical Frequency Response Curve
Measurement Circuit
Page 3
Measurement Setup Drawing
Product External and Dimensions
Page 4
Exploded Drawing
Material Table
Page 5
Accessory Drawing
Page 6
Temperature Conditions
Reliability Test
Page 7
Soldering Condition
Heat Sink
Page 8
Packing
Release | Revision: C/2019
www.soberton.com
Soldering Condition
We suggest using anti-static welding machine which can control soldering
temperature automatically.
Soldering temperature should be controlled under 320℃ and soldering time for
each terminal should be 1~2 seconds.
Microphone should be fixed on the metal block (heat sink), which has high radiation
effects, and heat sink shall contact with MIC tightly.
Microphone may easily be destroyed by the static electricity. The countermeasure
for eliminating the static electricity shall be by grounding the worktable and
operator.
Heat Sink
Shape of heat sink
Shape of hole at fixed part
7
soberton inc. mam —> 'J m—j moms E soberton inc.
EM ELECTRET
CONDENSER
MICROPHONE
Acoustic Product Specification
Product No: EM-4015LRW-40
CONTENTS
This document contains the technical
specifications for the omni directional
electret condenser microphone.
Page 1
Electrical Characteristics
Page 2
Typical Frequency Response Curve
Measurement Circuit
Page 3
Measurement Setup Drawing
Product External and Dimensions
Page 4
Exploded Drawing
Material Table
Page 5
Accessory Drawing
Page 6
Temperature Conditions
Reliability Test
Page 7
Soldering Condition
Heat Sink
Page 8
Packing
Release | Revision: C/2019
Packing
www.soberton.com
Details
Dimension: (length x width x height) unit:mm
Anti-Static Bag:
100 x 100 x 5mm
Small Packet:
100 x 100 x 10mm
Middle Box:
205 x 105 x 50mm
Carton Size:
550 x 230 x 235mm
Quantity and Weight
Small Box: 100 pcs
Middle Box: 1,000 pcs
Carton: 20,000 pcs
1PC: 0.1g
Net Weight: 2.0kg
Gross Weight: 5.0kg
8
20000PCS
1000PCS
100PCS
20000PCS
