Data sheet 3SU1050-3AB61-0AK0
Twin pushbutton, 22 mm, round, metal, shiny, white: I, Black: O,
pushbuttons, flat
product brand name
SIRIUS ACT
product designation
Twin pushbuttons
design of the product
Actuating/signaling element
product type designation
3SU1
product line
Metal, shiny, 22 mm
Enclosure
number of command points
1
Actuator
design of the actuating element
Flat buttons
principle of operation of the actuating element
momentary contact type
product extension optional
● light source
No
● contact module
Yes
color of the actuating element
white / black
material of the actuating element
plastic
shape of the actuating element
oval
marking of the actuating element
"I","O"
Front ring
product component front ring
Yes
design of the front ring
Standard
material of the front ring
Metal, high gloss
color of the front ring
silver
General technical data
protection class IP
IP66, IP67, IP69(IP69K)
degree of protection NEMA rating
1, 2, 3, 3R, 4, 4X, 12, 13
shock resistance
● acc. to IEC 60068-2-27
Sinusoidal half-wave 50g / 11 ms
vibration resistance
● acc. to IEC 60068-2-6
10 ... 500 Hz: 5g
operating frequency maximum
3 600 1/h
mechanical service life (switching cycles) typical
2 000 000
reference code acc. to IEC 81346-2
S
Ambient conditions
● ambient temperature during operation
-25 ... +70 °C
● ambient temperature during storage
-40 ... +80 °C
environmental category during operation acc. to IEC
60721
3M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 ... 95 %)
Miscellaneous Type Test Sp c 6 Certificates/Test Remn ul. ® Confirmation nuns hllns:/Ima\|.Induslrv.siemens.comlmalIlen/en/Calaloalnmducl’.’m\fb=SSU1050-3ABB1-0AKO him:llsuDDorl.anlomaklon.Siemens.com/WWICAXorderldefauIl,asDX?\anq=en&m\fb=SSU1050-3ABB1-0AKO hllns:/Isummrt.induslrv,siemensoomlcslwwlenlnslSSU1050-3A361-0AKO him:llwww,automalion.siemens.comlbilddb/cax de.asnx?mlfb=SSUI 050-3ABB1-0AK08nlanu=en
3SU10503AB610AK0
Page 2/3 12.19.2020 Subject to change without notice
© Copyright Siemens
Installation/ mounting/ dimensions
height
57.9 mm
width
29.9 mm
shape of the installation opening
round
mounting diameter
22.3 mm
positive tolerance of installation diameter
0.4 mm
mounting height
14.4 mm
installation width
29.9 mm
installation depth
25.7 mm
Certificates/ approvals
